ALDI LIGHTWAY 872-S-S Manuale utente
Scope of delivery
3
5
6 6
A
®
®
®
®
17 18
5
1
2 3
4
67
8
9
10
11
12
16
14 13
15
SOLAR-POWERED
SPOTLIGHT
Contents
YEAR
WARRANTY
3
AFTER SALES SUPPORT
MODEL:
872-S-S, 872-S-G, 872-S-W 03/2021
GB
803287
01909 517672
Great care has gone into the manufacture of this product and it should
therefore provide you with years of good service when used properly. In
the event of product failure within its intended use over the course of the
first 3 years after date of purchase, we will remedy the problem as quickly
as possible once it has been brought to our attention. In the unlikely event
of such an occurrence, or if you require any information about the product,
please contact us via our helpline support services, details of which are to
be found both in this manual and on the product itself.
IEGB
PRODUCED IN CHINA FOR:
ALDI STORES LTD. PO BOX 26, ATHERSTONE
WARWICKSHIRE, CV9 2SH
ALDI STORES (IRELAND) LTD.
PO BOX 726, NAAS, CO. KILDARE.
Visit us at www.aldi.com
012 475 437
IE
Scope of delivery
User Manual
General information ................................................................. 7
Reading and storing the user manual.......................................7
Proper use.......................................................................................7
Explanation of symbols ............................................................... 8
Safety.........................................................................................9
Explanation of notes .................................................................... 9
General safety notes ...................................................................10
First use ................................................................................... 15
Checking the product and scope of delivery .........................15
Charging the rechargeable batteries for the first time ........16
Selecting the installation location............................................ 17
Assembly ................................................................................. 18
Mounting the spot light..............................................................19
Mounting the solar panel...........................................................19
Operation ................................................................................20
Configuring the sensor area..................................................... 20
Setting the lighting duration .................................................... 21
Setting the sensitivity................................................................. 21
Adjusting the spotlight heads...................................................22
Aligning the solar panel .............................................................22
Switching the product on and off.......................................... 22
Troubleshooting ..................................................................... 23
Cleaning................................................................................... 26
Storage .................................................................................... 27
Technical data ......................................................................... 27
Declaration of conformity ......................................................28
Disposal ................................................................................... 29
Disposing of the packaging...................................................... 29
Disposing of the product........................................................... 29
6-872-IM-Cover_Außenstrahler-Solar_WuK2020-1-PRINT.indd 1-5 15.09.20 10:36
Scope of delivery
6
Scope of delivery
5
Scope of delivery
4
B
C
G
E
F
D
2 - 2,5 m 12 m
90°60°
90°
8
13
16
1
6
6
Components
1Tab 9Charging slot
2LUX controller 10 Sensor housing
3SENS controller 11 Motion sensor
4TIME controller 12 Spotlight head, 2×
5Power switch 13 Wall bracket (spotlight)
6Fixing screw 14 Plug with charging cable
7Spotlight 15 Solar panel
8Rear panel 16 Wall bracket (solar panel)
Connecting elements supplied
17 Wall plug, 4× 18 Screw, 4×
Required tools (not included)
19 Electric drill
19
20 Cross-head
screwdriver
20
21 Garantie Card
6-872-IM-Cover_Außenstrahler-Solar_WuK2020-1-PRINT.indd 6-10 15.09.20 10:36
General information
7
General information
Reading and storing the user manual
This user manual accompanies this solar-powered
spotlight (referred to below only as the ‘product’).
It contains important information on start-up and
handling.
Before using the product, read the user manual carefully. This
particularly applies to the safety instructions. Failure to follow
this user manual may result in serious injury or damage to the
product.
The user manual is based on the standards and rules in force
in the European Union. When abroad, you must also observe
country-specific guidelines and laws.
Store the user manual for future use. Make sure to include this
user manual when passing the product on to third parties.
Proper use
The product is designed for permanent installation in a
location protected against rain and is intended only for
temporary lighting outdoors, e.g. to light building entrances,
garages or pathways and as a deterrent against burglary.
Do not use it for indoor lighting or for accent lighting. It is only
intended for private use and is not suitable for commercial
purposes.
Use the product only as described in this user manual. Any
other use is considered improper and may result in damage to
property.
The manufacturer or vendor accepts no liability for damage
caused by improper or incorrect use.
General information
8
Explanation of symbols
The following symbols are used in this user manual, on the
product or on the packaging.
This symbol provides you with useful
additional information about start-up or
operation.
Declaration of conformity (see chapter
“Declaration of conformity”): Products
marked with this symbol meet all applicable
Community regulations for the European
Economic Area.
IP44
The product’s type of protection is IP44. This
means it is protected against splashing water
and against ingress of solid foreign objects
with a diameter of more than 1 mm.
This symbol identifies electric devices
corresponding to protection class III. This
means the product operates at low voltage
and is operated with a safety extra low voltage
(SELV).
Any cracked protective cover must be
replaced.
Safety
9
Safety
Explanation of notes
The following symbols and signal words are used in this user
manual.
WARNING!
This signal symbol/word designates a hazard with moderate
degree of risk which may lead to death or severe injury if not
avoided.
CAUTION!
This signal symbol/word designates a hazard with low risk
that, if not avoided, may result in minor or moderate injury.
NOTICE!
This signal word warns against potential damages to property.
Safety
10
General safety notes
WARNING!
Risk of explosion and fire!
Improper handling of the product can cause
an explosion or a fire.
− Keep children away from the product.
− Keep the product away from water, other
liquids, open flames and hot surfaces.
− Do not hang any objects over the product
and do not cover it. Maintain a distance
of 1m between the spot light and easily
flammable materials.
− Do not use the product anymore if it
exhibits damages. Only replace damaged
parts with corresponding original spare
parts.
− Do not open the housing and do not
make any modifications to the product.
Have only qualified professionals perform
repairs.
− Do not position the product over bathtubs,
sinks or other objects filled with water.
Safety
11
− Only charge the rechargeable batteries
using the solar panel supplied.
− Protect the rechargeable batteries against
mechanical damage.
− Do not throw rechargeable batteries in
fire. They could explode or release toxic
vapours.
− Do not expose rechargeable batteries to
unrestricted sunshine or heat. Increased
risk of leaking!
− Do not take rechargeable batteries apart
and do not short-circuit them. Danger of
explosion!
− The non-replaceable rechargeable
batteries are located inside the housing.
WARNING!
Risk of chemical burns!
Leaked fluid from the rechargeable batteries
could cause burns if it comes into contact
with skin or other body parts. Swallowing
rechargeable batteries may result in severe
internal injuries or even death.
Safety
12
− If battery acid leaks out, avoid contact with
skin, eyes and mucus membranes. In the
event of contact, immediately rinse the
affected areas with plenty of clean water
and consult a physician.
− In the event that battery acid leaks out,
protective gloves must be worn and
the leaked acid removed using a dry,
absorbent cloth.
− Store both new and used rechargeable
batteries so that they are not accessible to
children.
− If you are no longer able to securely close
the battery compartment, do not use
the product. Remove the rechargeable
batteries and store them in a location that
is inaccessible to children.
− If you suspect that a rechargeable battery
has been swallowed or has otherwise
entered the body, promptly consult a
physician.
Safety
13
CAUTION!
Risk of injury!
The light emitted by the LEDs is very bright
and can damage the eyes if looked at directly.
− Never look directly into the light of the
product’s LEDs.
− Ensure not to shine the light into the eyes
of people or animals when inspecting or
assembling/installing the product.
WARNING!
Danger for children and persons with
impaired physical, sensory or mental
capacities (e.g. partially disabled
persons, older persons with reduced
physical and mental capacities) or lack
of experience and knowledge (e.g. older
children).
− This product may be used by persons
with impaired physical, sensory or mental
capacities or those lacking experience and
knowledge if they are supervised or have
Safety
14
been instructed in how to safely use the
product and have understood the risks
associated with operating it. Children may
not play with the product.
− Cleaning and user maintenance must not
be performed by children.
− Keep children away from the product.
− Do not let children play with the
packaging wrapper. Children may get
caught in it when playing and suffocate.
NOTICE!
Risk of damage!
Improper handling of the product can
damage the product.
− Protect the product against drastic
temperature fluctuations, e.g. those near
ventilators, air conditioning units and
heaters.
− The LEDs are permanently installed and
cannot be replaced. Once the light source
has reached the end of its service life, the
entire product has to be replaced.
Questo manuale è adatto per i seguenti modelli
2
Indice
Altri manuali ALDI Riflettore
Manuali Riflettore popolari di altre marche
Guangzhou Yinhe Lighting&Sound Equipment Factory
Guangzhou Yinhe Lighting&Sound Equipment Factory NE-204 Manuale utente
LIVARNO home
LIVARNO home 375304 2101 Istruzioni originali
Cameo
Cameo CLQS40WW Manuale utente
Leviton
Leviton Ellipsoid 5/50 Manuale utente
Monacor
Monacor img Stage Line PARL-56PDX/CR Manuale utente
Vector
Vector SL3AKV Manuale utente
EuroLite
EuroLite Akku flat light 1 Manuale utente
Commercial Electric
Commercial Electric SPTM-1401 Manuale utente
Vision & Control
Vision & Control SLB-500-W5K7-P-SL Manuale utente
Teknik
Teknik FLEXI Manuale utente
Craftsman
Craftsman CMXLSB10 Manuale utente
EuroLite
EuroLite LED SLS-144 UV Floor Spot Manuale utente
