Alera ALE-CM6615PY Manuale utente
Please Retain Instructions for Future Reference
READ THIS FIRST:
PK-2780812
Welded Space Saver Storage Cabinet
•BEFORE discarding carton, check all contents for
damage or missing parts.
•CABINET KEYS are attached with a zip-tie to the
inside of the cabinet right door.
•For fastest and damage-free installation, please
carefully read and follow the assembly instructions.
•Do not use power tools on product.
•For product returns, parts and support, please call
1 (800) 733-4000.
Model Number: ALE-CM6615PY
CAUTION: Use caution when handling and assembling metal parts. Metal may have sharp edges or corners.
Manufacturer recommends the use of protective gloves while making adjustments to the product.
• This unit should be installed on a level surface.
• Do not use this unit as a step ladder. Do not climb on the unit.
• Do not exceed the manufacturer's recommended weight capacity of 150 lbs. / 68 kg. on each shelf for 18"d and 200 lbs. / 90 kg. on each shelf for 24"d.
• Always distribute weight evenly on shelves.
• The manufacturer recommends the storage of heavier items on bottom shelves.
All assembly instructions must be followed exactly or the unit may not be assembled correctly and may not be stable. Install the unit on a level surface.
Safety Instuctions
Manufactured for/Hecho para/Fabriqué pour Alera®/USSCo, 1 Pkwy North, Ste 100, Deerfield, IL 60015 ©2012 USSCo
REPLACEMENT PARTS
TO OBTAIN PROPER REPLACEMENT PARTS, PLEASE PROVIDE THE FOLLOWING INFORMATION:
Model Number Was item missing, or was it damaged?
Description of part(s) needed and part Purchase Date
number(s) as shown in Parts List (above) Your company name
Color (Champagne Putty, Light Grey, Black) Contact person's name
USSCo, 1 Pkwy North, Ste 100, Deerfield, IL 60015 Customer Service: (800) 733-4000
If requesting parts by telephone, ask for customer service and have as much of the above information ready as possible.
Shelf 303
Left Door SMLD
Right Door SMRD
Hinge Pin 944HP
Locking Handle (for right door) RH-1
Cam (included with RH-1 handle) LC-1
Cam Retainer Clip (included with RH-1 handle) 944CR
Lock Bar SMLB
Lock Bar Guide Insert (QTY 2) 944GI
PART DESCRIPTION
ALE-CM6615PY
Putty (30"w x 15"d)
•
•
•
•
•
•
•
60" Tall Cabinets
Shelf Adjustment
1. Using a flat-head screwdriver,
gently pull the dimpled tab away
from the hole in the shelf edge.
This will allow the shelf to be
released and lifted from the tab.
2. Place the shelf at the desired
level.
3. Insert the shelf edges into the
tabs at the new location. Be sure
that the shelf is securely fitted
into the tabs at all points of
contact.
View from beneath
shelf
