Algoma Hardwoods PC-7 FD Manuale utente
1001 Perry Street • Algoma, Wisconsin 54201
920.487.5221 • 1.800.678.8910 • FAX 920.487.3636
www.algomahardwoods.com • sales@algomahardwoods.com Door 23
8/10/08
Algoma Hardwoods, Inc. PC-7 is a
commercial door made with
particleboard core and skins.
Solid lumber outer stiles along
with Structural Composite
Lumber (SCL) rails and inner
stiles, are glued to the core prior
to cold pressing a 3-ply skin each side
of the core at ambient air temperature.
Algoma Hardwoods, Inc uses
only the better of two grades of
door core particleboard
conforming to ANSI Standard A208.1-
1989, Grade LD-1.
Algoma Hardwoods, Inc. uses
only skins with face veneers at
least .020” (0.5mm) thick at
12% moisture content.
Thickness 13⁄4" (44mm) available FD 1⁄3 hour labeled.
Maximum size Available prefit up to 4'0" x 8'0" (1219 x 2743mm), 8'0" x 8'0" pairs.
Stiles (Edge bands) 13⁄8" (35mm) prior to factory trimming, glued to core. Alternates: ME–matching edges or CE–compatible edges.
Top & bottom rails 13⁄8" (35mm) prior to factory trimming, glued to core; Structural Composite Lumber (SCL).
Core Conforms to ANSI A208.1-1989, GRADE LD-1 covering mat-formed particleboard.
Faces Skins 0.10" (2.5mm) of several veneer species. Faces shall be a minimum of .020" (0.5mm) at 12% moisture content.
Adhesives Type II (interior).
Veneer matching Available in pairs.
Details Standard lites and louvers available not to exceed 40% of door area or 54" (1372mm) in length. Maximum glass opening on FD
1⁄3 hour doors is 1,296 sq. in. (0836m2) with wood beads and clips or metal vision panels. Applied mouldings also available.
Machining Available with hinge and lock machining as well as other hardware.
Finishing Available in 8 standard colors, and clear.
Warranty For interior, limited lifetime warranty. Exterior not warranted.
Standards met or exceeded WDMA I.S. 1-A Series, WOOD FLUSH DOORS, AWI Section 1300.
PC-7 FD 1⁄3Hour Door
Product Features
1001 Perry Street • Algoma, Wisconsin 54201
920.487.5221 • 1.800.678.8910 • FAX 920.487.3636
www.algomahardwoods.com • sales@algomahardwoods.com Door 24
8/10/08
FEATURE WHI LABEL
Maximum opening size Singles: 4'0" x 8'0" (1219 x 2438mm). Pairs: 8'0" x 8'0" (2438 x 2438mm).
Faces Rotary Natural Birch, Sliced Red Oak, Paint Grade Birch, Rotary White Birch
Stiles (Vertical Edges) and rails 13⁄8" (35mm) mill option stiles. All doors have either matching or mill option outers. Up to 121⁄2" (318mm) bottom rails allowed.
Maximum wood veneered 1296 sq. inches (0.836m2). Maximums: 30” (762mm) width, 54” (1372mm) length
beaded lite
Maximum metal vision panel 1296 sq. inches (0.836m2). Maximums: 30” (762mm) width, 54” (1372mm) length
(Visible lite)
Maximum fusible link louver size Not allowed.
(Not allowed with vision panel
or exit devices)
Hinges Ball bearing steel mortised, half or full surfaced 41⁄2” x 41⁄2” x .134” (114.3 x 114.3 x 3.4mm) to 10’0” (3048mm). UL listed
spring hinges 41⁄2” x 41⁄2” x .134”
Locksets
Alllistedcylindrical,mortised,unit,andhospitalpush/pullto5”(127mm)backset.Unitlocksonlyavailablewith2
3
⁄
4
”(70mm)backset.
Pivots Top, intermediate & bottom must be listed offset. Rixon’s #180, 280, 380, 480, FM19, 219, T117, T1171⁄4, or equal. Others as
approved.
Closers UL listed surface type.
Fire Exit Hardware Singles: Mortised, rim or surface vertical rods. Pairs: Rim (with mullion) or surface vertical rods. Double egress allowed.
(Allowed with vision panel if
non-interfering)
Other pair hardware Listed surface or mortised door bolts. Manual, self-latching or automatic as codes allow.
Maximum trim: 3⁄4" (19mm) in the field.
Additional trim:
Can be up to 11
1
⁄
2
”
(292mm) if door is ordered with 12
1
⁄
2
”
(318mm) bottom rail. Maximum undercut,
3
⁄
4
”
(19mm).
Door Bottoms: Any listed surface or concealed.
Viewers: WHI up to 1” (25mm); UL up to 1⁄2” (12.7mm).
Astragals and edge guards: Must be supplied and cut for hardware under label service.
Wood Frames: FD 1⁄3Hour doors can be installed with 1⁄3hour wood frames.
Electric Raceway: Available with label on all doors.
PC-7 FD 1⁄3Hour Door
