For your safety and to reduce the risk of fire or an explosion, do not store or use

gasoline or other flammable vapors and liquids in the vicinity of this or any other

appliance.

W022

WARNING

-3-

802753

Safety Information

Explanation of Safety

Messages

Throughout this manual and on machine decals, you

will find precautionary statements (“DANGER,”

“WARNING,” and “CAUTION”) followed by specific

instructions. These precautions are intended for

the personal safety of the operator, user, servicer,

and those maintaining the machine.

Additional precautionary statements

(“IMPORTANT” and “NOTE”) are followed by specific

instructions.

IMPORTANT: The word “IMPORTANT” is used to

inform the reader of specific procedures where

minor machine damage will occur if the procedure

is not followed.

NOTE: The word “NOTE” is used to communicate

installation, operation, maintenance or servicing

information that is important but not hazard

related.

Important Safety Instructions

Save These Instructions

1. Read all instructions before using the washer.

2. Refer to the Grounding (Earthing) Information in

the Installation Instructions for the proper

grounding (earthing) of the washer.

3. Do not wash articles that have been previously

cleaned in, washed in, soaked in, or spotted

with gasoline, dry-cleaning solvents, or other

flammable or explosive substances as they

give off vapors that could ignite or explode.

4. Do not add gasoline, dry-cleaning solvents, or

other flammable or explosive substances to

the wash water. These substances give off

vapors that could ignite or explode.

Indicates an imminently hazardous

situation that, if not avoided, will

cause severe personal injury or death.

DANGER

Indicates a hazardous situation that, if

not avoided, could cause severe

personal injury or death.

WARNING

Indicates a hazardous situation that, if

not avoided, may cause minor or

moderate personal injury or property

damage.

CAUTION

To reduce the risk of fire, electric shock,

serious injury or death to persons when

using your washer, follow these basic

precautions:

W023

WARNING

transmitted in any form or by any means without the expressed written consent

of the publisher.

-4-

802753

5. Under certain conditions, hydrogen gas may

be produced in a hot water system that has

not been used for two weeks or more.

HYDROGEN GAS IS EXPLOSIVE. If the hot

water system has not been used for such a

period, before using a washing machine or

combination washer-dryer, turn on all hot

water faucets and let the water flow from

each for several minutes. This will release any

accumulated hydrogen gas. THE GAS IS

FLAMMABLE. DO NOT SMOKE OR USE AN

OPEN FLAME DURING THIS TIME.

6. Do not allow children to play on or in the

washer. Close supervision of children is

necessary when the washer is used near

children. This is a safety rule for all appliances.

This appliance is not intended for use by young

children or infirm persons without supervision.

Young children should be supervised to ensure

that they do not play with the appliance.

7. Before the washer is removed from service or

discarded, remove the door to the washing

compartment.

8. Do not reach into the washer if the wash drum

is moving.

9. Do not install or store the washer where it will

be exposed to water and/or weather.

10. Do not tamper with the controls.

11. Do not repair or replace any part of the

washer, or attempt any servicing unless

specifically recommended in the user-

maintenance instructions or in published user-

repair instructions that you understand and

have the skills to carry out.

12. To reduce the risk of an electric shock or fire,

DO NOT use an extension cord or an adapter

to connect the washer to the electrical power

source.

13. Use your washer only for its intended purpose,

washing clothes.

14. ALWAYS disconnect the washer from

electrical supply before attempting any

service. Disconnect the power cord by

grasping the plug, not the cord.

15. Install the washer according to the

Installation Instructions. All connections for

water, drain, electrical power and grounding

(earthing) must comply with local codes and

be made by licensed personnel when required.

Do not do it yourself unless you know how!

16. To reduce the risk of fire, clothes which have

traces of any flammable substances such as

vegetable oil, cooking oil, machine oil, flammable

chemicals, thinner, etc. or anything containing

wax or chemicals such as in mops and cleaning

cloths, must not be put into the washer. These

flammable substances may cause the fabric

to catch on fire by itself.

17. Do not use fabric softeners or products to

eliminate static unless recommended by the

manufacturer of the fabric softener or

product.

18. Keep your washer in good condition. Bumping

or dropping the washer can damage safety

features. If this occurs, have your washer

checked by a qualified service person.

19. Replace worn power cords and/or loose plugs.

20. Be sure water connections have a shut-off

valve and that fill hose connections are tight.

CLOSE the shut-off valves at the end of each

wash day.

21. Loading door MUST BE CLOSED any time the

washer is to fill, tumble or spin. DO NOT by-

pass the loading door by permitting the

washer to operate with the loading door open.

22. Check washer for water leaks after each use. If

water is found, turn off the water supply and

call for service immediately. Don’t use washer

until it is repaired by an authorized service

agent.

23. If the washer’s volume or type of sound

changes from what is normally heard, call an

authorized service agent immediately to

prevent possible damage to other

components.

24. Never start a cycle and leave the property

without first checking to make sure the wash

cycle is complete.

-5-

802753

25. Always read and follow manufacturer’s

instructions on packages of laundry and

cleaning aids. Heed all warnings or

precautions. To reduce the risk of poisoning or

chemical burns, keep them out of the reach of

children at all times (preferably in a locked

cabinet).

26. Always follow the fabric care instructions

supplied by the garment manufacturer.

27. Never operate the washer with any guards

and/or panels removed.

28. DO NOT operate the washer with missing or

broken parts.

29. DO NOT by-pass any safety devices.

30. Failure to install, maintain, and/or operate this

machine according to the manufacturer's

instructions may result in conditions which

can produce bodily injury and/or property

damage.

31. Replace washer fill hoses every five years.

32. If unit is a stacked washer and dryer, do not

operate washer and dryer if the units have

been separated.

NOTE: The WARNING and Important Safety

Instructions appearing in this manual are not

meant to cover all possible conditions and

situations that may occur. Observe and be aware

of other labels and precautions that are located

on the machine. They are intended to provide

instructions for safe use of the machine. Common

sense, caution and care must be exercised when

installing, maintaining, or operating the washer.

Always contact your dealer, distributor or service

agent about any problems or conditions you do not

understand.

-6-

802753

Operation

Before Washing

Prepare Wash Load

Empty Pockets and Cuffs

Make sure all pockets are empty and turn them

inside out. One bobby pin, metal or plastic toy, nail

or sharp object in a load can catch laundry, cause

tears and plug the pump. Facial tissue left in a

pocket will produce extreme “lint”. A crayon or

lipstick in a wash load may cause stains that

cannot be removed. Roll down cuffs and shake out

grass, sand and gravel.

Mend Rips and Tears

Little holes can become bigger in the washer. Mend

holes and tears before placing garments in the

washer.

Close Zipper and Fasten Hooks

These can catch on garments in a wash load and

tear them. Tie belts and sashes so they won’t wind

around clothes.

Put Small Items in Bag

Small items such as baby socks may get stuck

around the door. Put them inside a mesh garment

bag.

Check For Colorfastness

Squeeze a portion of garment in warm or hot sudsy

water. If the color bleeds or runs, wash the item

separately in cold water.

Sorting Items

Different items use different wash cycles and

temperatures. Always follow the manufacturer’s

care label. Proper sorting is easy if you follow a few

guidelines:

1. Sort by Color:

Separate items into loads of

whites, darks, lights and non-

colorfast.

2. Sort by Fabric and Construction:

Separate items into loads of

cottons/linens, permanent press,

synthetics/blends/poly knits, and

delicates.

3. Sort by Temperature:

Separate items into loads

that can be washed in cold,

warm or hot water.

4. Sort by Type and Amount of Soil:

Heavily soiled clothes will need extra

treatment. Lightly soiled clothes can become

dingy if washed with heavily soiled items.

5. Sort Lint “Shedders” From Lint “Receivers”:

Some fabrics attract lint and should not be

washed with lint-shedding loads. Lint

shedders are cottons, terry towels, chenille

bedspreads, rugs and clothes that have been

heavily bleached.

Lint receivers are synthetics, permanent or

durable press, knits (including socks),

corduroy, and other smooth fabrics.

Pretreat

Pretreat shirt collars and cuffs with a pretreat

product or liquid detergent when placing them in

the washer. Before washing, treat special stains

individually. Refer to Stain Removal section for

procedures on treating specific stains.

Whites

TLW1991

TLW1991N

TLW1990N

Cottons

TLW1991

TLW1991N

Cold

TLW1991N

-7-

802753

Loading the Washer

Load Articles

•Load items by the amount of space they take up,

not by their weight. Mix large and small items in a

load to get the best washing results.

•Load items loosely into the wash drum. The bulk of

the clothes rather than the weight will determine

load size.

Bulky Items

•Use the HANDWASH/DELICATE cycle for bulky

items such as blankets and comforters. The cycle

includes gentle agitation to clean items delicately

and thoroughly. The extra rinse cycle may be

selected to ensure complete removal of soap

residue. A final spin extracts the moisture at a low

speed to maintain the load’s balance and minimize

wear to the articles.

Load Sizes

•Load sizes vary. Small and large items should be

washed together to create a balanced load. If

washing a large item, two bath towels should be

added to even the load.

•Smaller loads can create an unbalanced condition

and cause premature wear on the washer. Do not

hesitate to fill the entire inner drum of the washer.

The load will compress a great deal when wet. This

allows room for proper tumbling.

Water Level

•The washer will automatically adjust the water

level to the type and size of the load during any fill.

Wash Temperature

Boosted Hot Water (on select models only)

The Boosted Hot Wash will boost the water

temperature in the tub to 140°F (60°C) and is

useful for improved cleaning of some loads. The red

HEATING light will light up when heating. The cycle

will not advance until 140°F (60°C) has been

reached.

The time needed to reach this temperature may

add an additional 30 to 60 minutes to the cycle

time. Hot water is the most effective for cleaning

but it is not recommended for all fabric types (read

labels).

NOTE: The Boosted Hot Wash can be turned off by

changing the cycle selector knob to OFF and

restarting a cycle with a different water

temperature setting.

Hot Water

The Hot Wash temperature is determined by the

actual temperature of the hot water supplied to

the washer. For models with Boosted Hot Wash,

the heater element will not be on. Hot water is the

most effective for cleaning, but it is not

recommended for all fabric types (read labels).

Warm Water

The Warm Wash is useful for providing a thorough

cleaning on lightly soiled clothing without damaging

fabric or adding to color fading.

The Warm Rinse (select models only) is useful in

preventing wrinkles on certain fabrics. Check labels

for fabric manufacturer’s recommendations.

Do not wash or dry items soiled with

vegetable or cooking oils. Some oils may

remain after washing and may cause the

fabric to catch on fire by itself.

W527

WARNING

-8-

802753

Cold Water

The Cold Wash is ideal for delicate items. Although

its cleaning abilities are not as great with hot or

warm water, it is useful for colors that bleed easily

and for sensitive fabrics.

The Cold Rinse is optional in every cycle and is the

most beneficial for fabrics. Cold rinses reduce

wrinkling and color fading. In addition, cold rinses

will save money and energy.

NOTE: In wash temperatures colder than 60

(16

C), detergents do not dissolve well. This may

cause ineffective cleaning, or lint and residue to

form.

NOTE: Always follow manufacturer’s care labels.

Wash Temperature Guide

Energy

You can save energy when washing by following a few

guidelines:

1. Heating water accounts for the greatest

energy expense when washing. Save on heating

water by using warm or cold washes as well as

cold rinses.

2. Wash full loads, but do not overload.

Water Temperature Use Comments

BOOSTED HOT

(select models only)

(approximately 140°F [60°C])

•

Sturdy whites and colorfast items

•

Work clothes

•

Heavily soiled items

•

Diapers

•

Best cleaning for heavily soiled

items

•

Best for sanitizing

HOT

(approximately 120°F [49°C]

or as determined by outside hot

water supply)

•

Sturdy whites and colorfast items

•

Work clothes

•

Soiled items

•

Diapers

•

Best cleaning for soiled items

•

Good for sanitizing

WARM

(approximately 100º F [38°C])

•

Rinsing of some items

•

Light and moderately soiled items

•

Non-colorfast or dark colors

•

Permanent press

•

Silks, woolens, nylon, acrylic

•

Reduces wrinkling in permanent

press fabrics

•

Less fading

•

Reduces shrinking in knits

COLD

(approximately 60º F [16°C])

•

Rinsing of most items

•

Non-colorfast fabrics

•

Extra delicate clothing

•

Saves energy

•

Reduces color fading

•

Reduces wrinkling

•

Reduces shrinking

120

(49

100

(38

(16

HOT

WARM

COLD

TLW1994N

-9-

802753

Operating Your Washer

NOTE: Always follow manufacturer’s care labels.

Determine Proper Cycle

NOTE: The cycle times might be longer if a

Boosted Hot Wash, if available, is selected.

Regular Cycle

Use for sturdy items, like play or work clothes,

towels, T-shirts, etc. This cycle includes a wash

tumble and two rinses with an optional third rinse.

The final spin starts with a medium spin and

finishes with a high spin.

Permanent Press Cycle

Use for permanent press items and synthetics.

This cycle includes a wash tumble and two rinses

with an optional third rinse. The final spin starts

with a medium spin and finishes with a high spin.

Delicate Cycle

Wash delicate items usually washed by hand on this

cycle. The cycle includes a wash tumble and two

rinses with an optional third rinse. The final spin

extracts moisture at a low spin.

Rinse & Spin Cycle

Use to quickly rinse items. The rinse is followed by a

high spin.

Spin Only Cycle

Use to extract water from wet items. This cycle

uses the high spin.

OFF

Use to stop a cycle or change cycles.

Extra Rinse

This optional setting is useful for detergent

sensitive skin. By pressing the “EXTRA RINSE”

button to “ON,” the REGULAR, PERMANENT

PRESS and DELICATE cycles will each provide an

additional rinse.

WARNING

To reduce the risk of fire, electric shock,

serious injury or death to persons, read

the Safety Information section before

operating your washer.

W522

-10-

802753

To Wash Clothes

IMPORTANT: Before using your new washer, make

sure the washer cord is plugged into an

appropriate electrical outlet that has the proper

grounding (earthing) and polarity. Refer to the

washer nameplate and Installation Instructions for

proper voltage and Hertz the washer is designed

to operate on. Refer to Contact Information

section for nameplate location. Make sure the

washer hoses are connected to the hot and cold

water faucets, and that the faucets are turned

on. Be sure the drain hose is not kinked and is

inserted into a drain. Refer to the INSTALLATION

INSTRUCTIONS for details of proper washer

installation.

IMPORTANT: Prior to first wash, use an all

purpose cleaner, or a detergent and water

solution, and a damp cloth to remove shipping

dust from inside of wash drum.

1. Get the clothes ready for washing. Empty

pockets and cuffs. Sort items into separate

loads. Pretreat stains and heavily soiled areas.

IMPORTANT: Remove all sharp objects from

laundry to avoid tears and rips to items

during normal machine operation.

2. Measure and add low sudsing, high efficiency

(HE) detergent, fabric softener and bleach to

the dispenser drawer. Refer to section on

Using Your Dispenser Drawer. Follow

instructions on detergent package for

amount to use.

NOTE: High efficiency (HE)

detergents are designed

especially for frontload washers

to reduce oversudsing and

maximize cleaning results. Look

for the HE logo or “high efficiency” on the

detergent’s label.

IMPORTANT: If using non-HE detergent, avoid

oversudsing by using only 1/2 of the detergent

manufacturer's recommended amount.

3. Load clothes into wash drum. Refer to section

on Load Sizes.

NOTE: Small items such as baby socks may get

caught around the door. Place these articles

inside a mesh garment bag.

TLW1991N

FLW2169N

FLW2170N

Indice

Altri manuali Alliance Laundry Systems Rondella

Alliance Laundry Systems

Alliance Laundry Systems Hardmount Coin and OPL Manuale di installazione e funzionamento

Alliance Laundry Systems

Alliance Laundry Systems H236I Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems NetMaster HC18NC2 Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems HC18 Guida alla manutenzione e all'assistenza

Alliance Laundry Systems

Alliance Laundry Systems AFNE9BSP113TN01 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems Cygnus Ultra Pro Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems HC18MC2 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 801529 Manuale di servizio

Alliance Laundry Systems

Alliance Laundry Systems HWFB61WN1102 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems HWF261*E Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems UCN020HN2 Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems CCN020HNF Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems FTS90A*N Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems DRY2033N Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems TC5102WN Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems FTS90A*N Istruzioni per il montaggio

Alliance Laundry Systems

Alliance Laundry Systems AFBE9BSP303NN29 Istruzioni operative

Alliance Laundry Systems

Alliance Laundry Systems Speed Queen TC5000WN Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems CHM1772C Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems HCL020HDF Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems AFB50RSP111TW01 Istruzioni operative

Alliance Laundry Systems

Alliance Laundry Systems TLW12C_SVG Guida

Alliance Laundry Systems

Alliance Laundry Systems FLW1548C SVG Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems BWNBC2PP113TW01 Manuale di installazione

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
