Alliance Laundry Systems NetMaster HC18NC2 Manuale utente

Programming

NetMaster

Washer-Extractors

Cabinet Hardmount Basic Programming Guide

Refer to Page 5 for Model Numbers

C872I

Part No. F232151R2

April 2002

Keep These Instructions for Future Reference.

(If this machine changes ownership, this manual must accompany machine.)

F232151 1

NOTE: The WARNING and IMPORTANT

instructions appearing in this manual are not meant

to cover all possible conditions and situations that

may occur. It must be understood that common

sense, caution and carefulness are factors which

cannot be built into these washer-extractors. These

factors MUST BE supplied by the person(s)

installing, maintaining or operating the washer-

extractor.

Always contact the distributor, service agent or the

manufacturer about any problems or conditions you do

not understand.

WARNING

Failure to install, maintain, and/or operate

this machine according to the

manufacturer’s instructions may result in

conditions which can produce bodily

injury and/or property damage.

W030

2F232151

Notes

means without the expressed written consent of the publisher.

F232151 3

Table of

Contents

Introduction......................................................................................... 5

Model Identification ............................................................................. 5

Preliminary Information.................................................................... 7

About the Control ................................................................................. 7

Glossary of Terms................................................................................. 7

Power Failure Recovery ....................................................................... 7

Communications................................................................................... 8

NetMaster Identification .................................................................... 9

Select Cycle Pads.................................................................................. 9

Select Wash Temp Pads........................................................................ 9

VFD Display Identification ................................................................ 11

Light Emitting Diodes (LEDs) ............................................................. 11

Washer-Extractor Operation ............................................................ 13

Start Up................................................................................................. 13

Ready Mode.......................................................................................... 13

Cycle Sequence..................................................................................... 13

Closing Washer-Extractor Door ........................................................... 13

Signals................................................................................................... 14

Changing Cycles................................................................................... 14

NetMaster Special Features ............................................................... 15

Programming NetMaster ...................................................................... 15

Collecting Audit Information ............................................................... 15

Testing Machine and NetMaster Functions.......................................... 15

Sales Floor Feature ............................................................................... 15

Rapid Advance Feature......................................................................... 15

Clearing the NetMaster Vend Feature .................................................. 15

Communications Mode......................................................................... 15

Dual Coin Drop..................................................................................... 15

Start Pulse Operation ............................................................................ 16

Access Panel and Coin Vault Openings ............................................... 16

Break-In Alarm..................................................................................... 16

Special Vend......................................................................................... 16

Lucky Cycle.......................................................................................... 16

Site Code Pricing .................................................................................. 16

Special Cycle ........................................................................................ 16

Auto-Flush Feature ............................................................................... 16

Opening the Access Panel .................................................................. 17

Entering the Manual Mode................................................................ 19

Programming NetMaster ................................................................... 21

What Can Be Programmed? ................................................................. 21

Programmable Options Available......................................................... 22

Collecting Audit Information ............................................................ 107

Manual Reset....................................................................................... 109

Testing Machine and NetMaster Functions ..................................... 111

Sales Floor Feature ............................................................................. 121

Rapid Advance Feature...................................................................... 123

Clear Vend Feature ............................................................................ 125

Communications Mode ...................................................................... 127

Power Fail Recovery........................................................................... 129

Default Washer-Extractor Settings................................................... 131

4F232151

Notes

F232151 © Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT

Introduction

Model Identification

Information in this manual is applicable to these

models:

HC18NC2 HC25NX2 NC25NR2 SC25NC2 SC80NRV

HC25NC2 HC27NX2 NC27NR2 SC27NC2 SC18NX2

HC27NC2 HC35NX2 NC35NR2 SC30NC2 SC20NX2

HC35NC2 HC40NX2 NC40NR2 SC35NC2 SC25NX2

HC40NC2 HC50NX2 NC50NR2 SC40NC2 SC27NX2

HC50NC2 HC80NXV NC80NRV SC50NC2 SC30NX2

HC80NCV NC18NC2 NC18NX2 SC80NCV SC35NX2

HC18NR2 NC25NC2 NC25NX2 SC18NR2 SC40NX2

HC25NR2 NC27NC2 NC27NX2 SC20NR2 SC50NX2

HC27NR2 NC35NC2 NC35NX2 SC25NR2 SC80NXV

HC35NR2 NC40NC2 NC40NX2 SC27NR2

HC40NR2 NC50NC2 NC50NX2 SC30NR2

HC50NR2 NC80NCV NC80NXV SC35NR2

HC80NRV HC25NX2 SC18NC2 SC40NR2

HC18NX2 NC18NR2 SC20NC2 SC50NR2

F232151

6© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT

Notes

F232151 © Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT

Preliminary Information

About the Control

NetMaster on the washer-extractor is an advanced,

programmable computer that lets the owner control

most machine features by pressing a sequence of

SELECT CYCLE and SELECT WASH TEMP pads.

Refer to Figure 1.

NetMaster allows the owner to program custom

cycles, set vend prices, retrieve audit information,

program and run diagnostic cycles, and program

special vend features. Washer-extractors shipped from

the factory have a default cycle and wash temperature

setting of PERM PRESS, WARM built in. However,

the owner can change the default cycle, or any cycle,

as needs permit.

IMPORTANT: In the event of a power failure,

NetMaster will not have to be reprogrammed. It is

designed with a memory system that will remember

how it was programmed (for a minimum of six

years) until the electrical power is restored.

IMPORTANT: It is extremely important that the

washer-extractor has a positive ground and that all

mechanical and electrical connections to NetMaster

are made before applying power to or operating the

washer-extractor.

Glossary of Terms

The following are a few terms and abbreviations to

learn. These are referred to throughout the instructions.

VFD - Vacuum Fluorescent Display.

This term refers to the window area of the

control that displays words and values.

LED - Light Emitting Diode.

This term refers to the lights on the keypads

and status words of the control.

Power Failure Recovery

If a cycle is in progress and the power fails, cycle

status is saved in memory (for a minimum of six years)

without power being applied.

If power resumes within one minute and 30 seconds,

the previously active cycle will continue without

having to press START.

If the control was in a fill cycle step and if the pre-

programmed pressure switch is not satisfied, the

control will start the Fill/Tumble step from the

beginning.

If the control was in an intermediate extract step, the

rest of the extract step is lost and the control will

resume in the next cycle step. However, if in the

intermediate extract step prior to the final extract or in

the final extract, the control will resume the cycle from

the beginning of the previous Drain/Tumble step.

The owner may program a special feature called Power

Fail Reset which sets a maximum power failure

duration. To program this feature, refer to

Programming NetMaster in the Enhanced

Programming Guide, available at extra cost.

If power resumes anytime after one minute and

30 seconds and less than or equal to the time

programmed by the owner for the Power Fail Reset, or

if the Power Fail Reset feature is disabled, the control

will enter into the Start Mode at the beginning of the

cycle step where the power failed.

If power resumes anytime after the time programmed

by the owner, the control will revert to the Ready

Mode.

For more information, refer to Power Fail Recovery.

Preliminary Information

F232151

8© Copyright, Alliance Laundry Systems LLC –DO NOT COPY or TRANSMIT

BDEF G

KLMN

OPQRSTU

VWXYZ

ENTER

123

SHIFTSPACE

BKSPCLEAR

F1F2F3F4

MODE

MICRO-WANDIIIE

LIGHTBKSP

C100I

Communications

NetMaster may be programmed manually, by

Micro-Wand IIIE, by the Card Reader or by the

Network.

Infra-red Communications (Optional)

The Micro-Wand allows the owner to program and

retrieve information from NetMaster without touching

the keypad. The Micro-Wand greatly expands

the programming options available to the

owner. However, the Micro-Wand is not

required to program and operate the

washer-extractor. The operation of the

Micro-Wand and the advanced features

available are covered separately in the Micro-Wand

IIIE instruction manual.

Smart Card Reader Communications

The control will accept communication with a Card

Reader in order to perform vending transactions when

a card is inserted to pay for cycles. The card reader can

also allow the owner to program and collect audit

information.

For detailed information on the Smart Card Reader

Communications, refer to the Smart Card setup

module in the NetMaster Smart Card Suite software

package.

Network Communications

The control will also accept communication with a

Network Interface Board which allows the control to

be linked to a personal computer. This network link

allows an owner to program, collect data, and run

diagnostics on any machine.

For detailed information on Network Communications,

refer to the Network instruction manual.

MICRO-WAND IIIE

C100

BDEF G

KLMN

OPQRSTU

VWXYZ

ENTER

123

SHIFTSPACE

BKSPCLEAR

F1F2F3F4

MODE

MICRO-WANDIIIE

LIGHTBKSP

C100I

Altri manuali per NetMaster HC18NC2

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Alliance Laundry Systems Rondella

Alliance Laundry Systems

Alliance Laundry Systems UW100AV Guida alla risoluzione dei problemi

Alliance Laundry Systems

Alliance Laundry Systems Speed Queen LWN311SP101NW22 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems LWS45M series Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems Speed Queen TR5003WN Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems F232198R4 Guida alla risoluzione dei problemi

Alliance Laundry Systems

Alliance Laundry Systems 9002062R3 Guida all'installazione

Alliance Laundry Systems

Alliance Laundry Systems HF455 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 802734R6 Guida

Alliance Laundry Systems

Alliance Laundry Systems FTS90A*N Istruzioni per il montaggio

Alliance Laundry Systems

Alliance Laundry Systems W446I Guida

Alliance Laundry Systems

Alliance Laundry Systems D1627ENR5 Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems CHM1772C Guida alla risoluzione dei problemi

Alliance Laundry Systems

Alliance Laundry Systems HFNNERSP116CW01 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems HFNKCASG113TN01 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems UCN020HN2 Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems A Series Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems Dishwasher Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems C003292ENR1 Manuale del proprietario

Alliance Laundry Systems

Alliance Laundry Systems SF18VNV Guida alla manutenzione e all'assistenza

Alliance Laundry Systems

Alliance Laundry Systems POCKET HARDMOUNT UW50P4 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems AWNA62 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems W001C Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems H2641 Guida

Alliance Laundry Systems

Alliance Laundry Systems TR7104WN Manuale utente

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
