Allied Telesis AT-SPLX40/1550 Manuale utente

Datasheet | Multi-Rate Pluggable Transceivers

AT-SPLX40/1550

40km 1000LX SFP

Industry Standard

The AT-SP series offers the latest industry

standard in flexible, full-duplex Gigabit Ethernet

connectivity.These hot-swappable, fiber

interfaces simply plug into a SFP slot on Allied

Telesis SFP compatible products. Configurations

can be optimized to meet varied distance and

service requirements.

Options

The AT-SP series offers short-haul and long-haul

solutions. From the inexpensive AT-SPSX to the

far-reaching AT-SPZX80, you have the option to

extend your network to the distances that meet

your performance needs.The CWDM version

allows you to takeadvantage of the CWDM

technology in an existing network infrastructure,

maximizing fiber efficiency. Multi-rate versions

allow technologies other than just Gigabit

Ethernet to be transmitted over single-mode

fiber.

Product Compatibility

The AT-SP series SFPs are compatible with all

the Allied Telesis range of products that support

SFP uplink connections.

Technical Specifications

Media Type SMF

Wavelength 1550nm

Maximum Data Rate 1.25Gbps

Distance 40km

Digital Diagnostics Yes

Transmit Power (min) -5dBm

Transmit Power (typ) -2.5dBm

Transmit Power (max) 0dBm

Receive Sensitivity (typ) -26dBm

Receive Sensitivity (max) -24dBm

Power Budget 19dBm

Fiber Connector: LC

Standard Data Rates Supported

Optical Gigabit Ethernet

Environmental Specifications

Operating Temp. -5°C to 70°C

Operating Humidity 0% to 85% (non-condensing)

Storage Temperature -40°C to 85°C

Storage Humidity 0% to 85% (non-condensing)

Key Features

•Copper and fiber solutions

•Connect up to 80km

•Compact size

•Flexible architecture

•Plug & Play ease-of-use

•Self-locking mechanism

•‘Colored’ wavelength for CWDM use

•Data: Support for fiber channel and 2x fiber

channel

•Telecom: support for OC3/STM-1,

OC12/STM-4, and OC48/STM-16

•Two year warranty

Ordering Information

AT-SPLX40/1550

40km 1000LX SFP, 9 Micron SMF (1550nm)

AT-SPLX40/1550

Small Form Pluggable (SFP) Modules

©2007 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000127 Rev C
