ALORAIR STORM PRO Manuale utente

STORM PRO

INSTALLATION AND OPERATIONS MANUAL

- READ AND SAVE THESE INSTRUCTIONS -

User’s Manual

AlorAir SolutionslNC.

Add: 2048 E.Francis st Ontario Ca91761

Tel: 1-888-990-7469

E-mail: sales@alorair.com

STORM ULTRA

DEHUMIDIFIER

Note: as we keep upgrading our product, we reserve the right to modify the product without notice in advance.

Safety Notes

The Storm Pro / Storm Ultra dehumidifier must always be connected using a grounded elect-

rical connection as required for all electrical appliances. The warranty is voided and all respon-

sibility for the operation transfers to the owner if non-grounded wiring is utilized.

Your Storm Series dehumidifier must be maintained and serviced by qualified technicians.

Storm dehumidifiers are intended for use only when the unit is installed in a level and

upright position. Operating the unit in any other position could cause water to come in

contact with the electrical components.

Before moving the dehumidifier, turn off the unit and allow the pump reservoir to empty (if

unit is already o ff, press "PURGE" button to confirm drain reservoir is empty). After the pump

has

finished operation, unplug the power cord and relocate the unit to the desired position.

If the inside of the machine has gotten wet for any reason, the unit should be opened and

allowed to dry thoroughly before reconnecting it to electric and restarting.

For proper operation, neither the inlet or discharge should be positioned against a wall. A

minimum of 8" clearance between the Storm and any obstruction is required.

Do not insert any objects or fingers into the inlet or discharge.

All work on the machine should be done with the unit off and unplugged.

Do not spray water or cleaner directly on the exterior of the unit. Only use a damp cloth

to clean the exterior and always unplug the unit first.

Do not use unit as shelf or device to hang clothes as this could cause damage to unit.

Do not stand on the machine.

Table of Contents

Introduction.....................................................................................

..................................................................................

.......................................................................

.................................................................

.......................................................................

..................................................................

...............................................................................

.........................................................................................

Unit Overview

LCD Display Introduction

Preparing the Unit for Use

Maintenance & Repair

Storing Your Dehumidifier

Troubleshooting

Warranty

sales@alorair.com

Introduction

Identification

Congratulations on purchasing a Storm Pro / Storm Ultra dehumidifier! The Storm Pro / Storm

Ultra comes with an extensive warranty plan. To ensure you are eligible, be sure to note the

serial number and date of purchase. The serial number can be found on the data on the back

of the unit.

Model Name: Storm Pro

Serial Number:

Date of Purchase:

Customer Service

For additional questions concerning the operation fo your dehumidifier, please

Contact your installing contractor.

Contact AlorAir Solutions: 1-888-990-7469

Features

● Storm Pro:85 pints per day at AHAM

● Storm Ultra:90 pints per day at AHAM

● Only 58 dBA

● Automatic Humidistat

● Built-in Pump with Overflow Protection

● Self Monitoring System

● Eco-Friendly R410A Refrigerant

● Easy Access to Internal Components

● Auto Restart After a Power Outage.

● The Unit can be Ducted on the Supply/Outlet, if Necessary

Storm Ultra

240

How Your Storm Dehumidifier Works

Electrical Supply

WARNING Volts may cause serious injury from electric shock.

Power Supply:

Outlet Requirement:

Circuit Protector:

115V, 60 Hz AC Only 1 Phase

3-Prong, GFI

15 Amp Time D elay F use o r Circuit Breaker

1. Disconnect electrical power before servicing 3. Do not use an extension cord

2. Only plug unit into grounded electrical outlet 4. Do not use a plug adapter

WARNING

Installation

Place the Pro in your desired location. The inlet of the machine should be at least 8"

from any obstructions. If the unit has been transported in a horizontal position, allow it to

sit in an upright position for at least 30 minutes before operating.

Do not use dehumidifier in an environment where corrosive or high VOC materials are applied.

The Storm Pro dehumidifier /The Storm Ultra dehumidifier utilize its integral humidistat to

monitor the conditioned space. Once conditions are outside the desired setpoint, the

compressor energizes and air is drawn across an evaporator coil. The evaporator coil is cooler

than the dew point of the air so water vapor will turns into liquid condensation. The air is then

reheated through the condenser coil and distributed back into the room.

Unit Overview

Front View Rear View

Storm Pro Dehumidifier

Storm Ultra Dehumidifier

Air Inlet

Air Filter

Handle

Wheel

Front Cover

Air Outlet LCD Display

Air Inlet

Air Filter

Handle

Wheel

Front Cover

Air Outlet

Drain Tube

Connection

LCD Display

Tubing &

Cord Rack

Power Cord

LCD Display Instructions

1. When the machine is powered on but not working:

Boot display: The LOGO interface

will disappear after 2 seconds. Enter

the following interface

The machine displays when it is not

working. (Power off state but have

electricity)

2. Main interface display of dehumidification state:

The following information is displayed when the machine is working:

Refers to the working time, which is defined as the time from

starting up to shutting down, including the defrost time during

the period, and the standby time after the humidity. The

submenu has a reset function. If not, the working time shall

be accumulated.

Total time 9999 hours, the largest cumulative to the largest

automatically reset after restart, and display units for hours.

(round off).

000 JOB HRS:

(After power on, the buzzer makes a sound)

PURGE

000 LIFE HRS:

Refers to the total working time, i.e. the total working time (hours), which is in hours. (Press the mode key +

select the confirmation key, and the total working time will be cleaned after 3 seconds.)

IN/OUT 00℉ 00% 00 gr / lb:

Indicates the temperature, humidity and moisture content of the air inlet and outlet

{GPP - grain per pound (gr/lb)}.

Indicates set humidity.

Set 00%:

If the main interface does not operate for 10 minutes, the screen will go out.Press any key to

wake up.

Other icons light up or flicker when opened

The total working time is the accumulation of each working time (hours) in hours. (Press the

mode key + select to confirmation key, and the total working time will be cleaned after 3 seconds.

3.Dehumidification status submenu interface display

3.1

Device name displayed on the screen:

You can change the device name on the APP

application

“Indicates”:Do I need to clear out this time?",

press ">"if you need to clear. When the operation

is completed, the working time of the main

interface and the working time of this interface

will be reset and started to be instant again.

After accumulation (9999), clean up and round.

3.2

3.3

“Coil Temp 000℃ ”: Used to display the current

temperature of the coil.When it is below zero,

the "-" symbol is displayed in front. "-" is not

required on zero.
