Altec Lansing POWER DUO ABT385 Manuale utente

ITEM NO.: ABT385 Quick Start Guide

WHAT’S INCLUDED

Remote Control

Quick Start Guide

ABT385

Power Duo Bluetooth Tower Speakers

Satellite Speaker Main Speaker

ITEMNO.: ABT385 QuickStart Guide

LIGHTS

ASSEMBLY

Satellite Speaker

Output Port

Light Port

Main Speaker

(rear view)

Main Speaker

(rear view)

Power Cable

Connect the satellite speaker to the main speaker.

The cable attached to your satellite speaker has two plugs. These plugs

connect to the output port and the light port on the main speaker.

Once your speakers are connected properly, you can insert

the power cable on your main speaker into an available power

outlet in your home.

AUDIO INPUT

ARC: HDMI Audio Return

Channel Input from a TV

OPTICAL: Optical Digital Audio Input

from a TV, DVD Player, CD Player. etc.

SRC 1: For line level or headphone

output from audio sources

SRC 2: For line level or headphone

output from audio sources

Plug external audio devices into the various ports on on the main speaker.

USING THE REMOTE

Power ON/

Power OFF (Standby)

LIGHTS

(Press repeatedly to

toggle through

the various

light settings)

BT ARC OPT

(Choose to play

Bluetooth audio,

or from devices

connected to the

ARC or OPT ports.)

SRC 1

(Choose to play

audio

from devices

connected to the

SRC1 port.)

SRC 2

(Choose to play

audio

from devices

connected to the

SRC2 port.)

MUTE

Decrease Volume

Next TrackLast Track

Play/Pause

LIGHTS

SRC1 SRC2

TONE

BT ARC OPT

MUTE

VOL +

VOL -

TONE

(Press repeatedly to toggle between

the Bass or Treble setting options.

Use the Vol + and Vol - to increase or

decrease the selected setting. )

FRONT CONTROL PANEL

SIDE CONTROL PANEL

SPEAKER CONTROLS

–

Power/Play/Pause

Select Source

(BT, ARC, OPT, SRC1 or SRC 2.

Press & hold to disconnect

Bluetooth connection)

Increase Volume

Decrease Volume

Microphones (not

included) can be

plugged into the Mic1

and Mic2 input jacks so

that you can sing along

while your favorite songs

are playing.

Rotate the ECHO knob to

add more vocal eect to

your voice.

Rotate the Mic1 and

Mic2 volume knobs to

increase or lower the

volume on each

microphone.

BLUETOOTH PAIRING

ABT385

LIGHTS

SRC1 SRC2

TONE

BT ARC OPT

MUTE

VOL +

VOL -

Press the Power ON

button on your remote

control to power on

your speakers.

LIGHTS

SRC1 SRC2

TONE

BT ARC OPT

MUTE

VOL +

VOL -

Press the BT button on

your remote control to

enter Bluetooth mode.

Go to the Bluetooth settings menu on your phone. Make sure that Bluetooth

is turned on. Connect to the device listed as “ABT385.”

SPEAKER PLACEMENT

For best results you should place one speaker directly to the left of a TV or

computer monitor, and the other speaker placed directly to the right of a TV

or computer monitor (see below).

SAFETY PRECAUTIONS

FCC STATEMENT

SPECIFICATIONS

10.

Changes or modiﬁcations not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment o and on, the

user is encouraged to try to correct the interference by one or more of the

following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit dierent from that to which

the receiver is connected.

-- Consult the dealer or an experienced radio/TV technician for help.

Power Audio: 120W (RMS) 2.0 Channel

240 W (PMPO) Total

Driver Units:5.25”*4+2.25”*4

Frequency Response: Satellite:120Hz-20KHz

Subwoofer: 20Hz-170Hz

Separation:≥40dB

S/N:≥70dB

Distortion:≤0.5%（1K,1W)

Power Supply:~120V/60HZ

Dimensions: Subwoofer: W172xH830xD343(mm)

Satellite: W172xH830xD343(mm)
