Altinex SIDEKICKER DA103-110 Manuale utente

DISTRIBUTION AMPLIFIERS

MANUAL PART NUMBER: 400-0449-005

DA103

107 & DA103

110

DA103-110 DA103-107

SIDEKICKER

WITH 2 VIDEO OUTPUTS

USER’S GUIDE

DISTRIBUTION AMPLIFIERS

400-0449-0051

TABLE OF CONTENTS

Page

PRECAUTIONS / SAFETY WARNINGS................ 2

GENERAL..........................................................2

INSTALLATION..................................................2

CLEANING.........................................................2

FCC NOTICE .....................................................2

ABOUT YOUR DA103-107/110............................... 3

TECHNICAL SPECIFICATIONS ............................ 3

PRODUCT DESCRIPTION ...................................... 4

APPLICATION DIAGRAMS...................................... 5

DIAGRAM1: TYPICAL SETUP ..........................5

DIAGRAM2: INTERNAL VIEW..........................6

INSTALLING YOUR DA103-107/110...................... 7

OPERATION............................................................... 7

TROUBLESHOOTING GUIDE................................. 7

THE LED IS NOT RED. ......................................7

THERE ARE NO REMOTE IMAGES..................8

ALTINEX POLICIES.................................................. 8

LIMITEDWARRANTY/RETURN POLICIES.......8

CONTACT INFORMATION................................8

DISTRIBUTION AMPLIFIERS

400-0449-0052

PRECAUTIONS / SAFETY WARNINGS 1

Please read this manual carefully before using your

DA103-107/110. Keep this manual handy for future

reference. These safety instructions are to ensure

the long life of your DA103-107/110 and to prevent

fire and shock hazards. Please read them carefully

and heed all warnings.

1.1 GENERAL

•Qualified ALTINEX service personnel or their

authorized representatives must perform all

service.

1.2 INSTALLATION

•To prevent fire and shock, do not expose this

unit to water or moisture. Do not place the

DA103-107/110 in direct sunlight, near heaters

or heat-radiating appliances, or near any liquid.

Exposure to direct sunlight, smoke, or steam can

harm internal components.

•Handle the DA103-107/110 carefully. Dropping

or jarring can damage the unit.

•Do not pull any cables that are attached to the

DA103-107/110.

1.3 CLEANING

•Clean only with a dry cloth. Never use strong

detergents or solvents, such as alcohol or

thinner. Do not use a wet cloth or water to clean

the unit. Do not open the unit to clean.

1.4 FCC NOTICE

•This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause

harmful interference, and (2) this device must

accept any interference received, including

interference that may cause undesired

operation.

•This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when the

equipment is operated in a commercial

environment. This equipment generates, uses,

and can radiate radio frequency energy and, if

not installed and used in accordance with the

instructions found herein, may cause harmful

interference to radio communications. Operation

of this equipment in a residential area is likely to

cause harmful interference in which case the

user will be required to correct the interference

at his own expense.

•Any changes or modifications to the unit not

expressly approved by ALTINEX, Inc. could void

the user’s authority to operate the equipment.

DISTRIBUTION AMPLIFIERS

400-0449-0053

ABOUT YOUR DA103-107/110 2

DA103-107/110

SIDEKICKER WITH 2 VIDEO

OUTPUTS

The DA103-107/110 provides a means of

transmitting computer or component video to two

different displays from a single computer.

The DA103-107/110 is compact and easy to use.

It offers a female 15-pin HD input and 2female

15-pin HD output connectors.

The Sidekicker is capable of being powered from

one of three different sources. The first uses the

+5V on pin 9 of the computer’s 15-pin HD video

connector (VESA standard). If the computer or

video cable does not provide power to the

DA103-107/110, then the second option obtains

power from the computer’s USB port if available.

The video cable provided with the DA103-107/110

has a USB connector on one end for use with this

option. If there is no USB port available, the third

option is to use the +9V adapter.

TECHNICAL SPECIFICATIONS 3

Specifications are subject to change.

See www.altinex.com for up-to-date information.

FEATURES/

DESCRIPTION DA103-107/110

Inputs

Video 15-pin HD female (1)

Power 2.5mm DC jack (1)

Outputs

RGBHV/YPbPr 15-pin HD female (2)

Compatibility

Video Signal

Resolutions VGA through UXGA,

480p through 1080i

Max. Cable Length

(using ALTINEX cable

CB37200MR)

VGA:640x480@60Hz

250 ft (76 m)

UXGA:1600x1200@60Hz

200 ft (61 m)

Table 1. DA103-107/110 General

MECHANICALDA103-107/110

DA103-107

Material/Color Steel/Silver

Height 0.78 in (20 mm)

Width 4.23 in (107 mm)

Depth 1.74 in (44 mm)

Weight 0.38 lb (0.17 kg)

DA103-110

Material/Color ABS Plastic/Black

Height 0.92 in (23.4 mm)

Width 4.25 in (108 mm)

Depth 1.68 in (42.7 mm)

Weight 0.16 lb (0.07 kg)

DA103-107/110

T°Operating (T°Max) 10°C-35°C(50°C)

Humidity 90%non-condensing

MTBF (calculations) 40,000 hrs

Table 2. DA103-107/110 Mechanical

ELECTRICALDA103-107/110

Input Video Signal

Analog Signal Level 1.0 Vp-p max

Impedance 75Ω

Input Sync Signal

H & V SYNC TTL

Impedance 10 kΩ

Output Video Signals

Analog Signal Level 0dB +/-0.3dB

Impedance 75Ω

Output Sync Signals

H&V Sync Levels TTL

Impedance 75Ω

Power

Computer/USB Port (+5VDC) 140 mA (0.7 W)

+9V Adapter 150 mA (1.35 W)

Accessories Included

Video Cable with USB 2ft (0.61 m)

Power Adapter 9 VDC, 1 A

6ft (2 m) min.

Table 3. DA103-107/110 Electrical

DISTRIBUTION AMPLIFIERS

400-0449-0054

DA103-110

POWER/SIGNAL PRESENTPOWER 9V, 1A

VIDEO OUTPUT 2

VIDEO INPUT VIDEO OUTPUT 1

RED = POWER

GREEN = SIGNAL PRESENT

PRODUCT DESCRIPTION 4

DA103-107

POWER 9V, 1A

GREEN = SIGNAL PRESENT

POWER/SIGNAL PRESENT

RED = POWER

VIDEO INPUT VIDEO OUTPUT 1

VIDEO OUTPUT 2

DISTRIBUTION AMPLIFIERS

400-0449-0055

APPLICATION DIAGRAMS 5

DIAGRAM 1: TYPICAL SETUP

The DA103-107 is shown in the diagram below, but

both the DA103-110 and DA103-107 have the save

functionality.

DISTRIBUTION AMPLIFIERS

400-0449-0056

DIAGRAM 2: INTERNAL VIEW

The block diagram for both the DA103-107 and the

DA103-110 is shown below.

POWER

SIGNAL

PLUG AND PLAY

VIDEO

15-PIN HD

OUTPUT 2

VIDEO

15-PIN HD

OUTPUT 1

VIDEO

15-PIN HD

INPUT

POWER

2.5mm

9V, 1A DETECT

DISTRIBUTION AMPLIFIERS

400-0449-0057

INSTALLING YOUR DA103-107/110 6

Step 1. Connect the input of the DA103-107/110

to the video output of the computer using

the cable provided. The Signal Present

LED should be on. The LED will be red if

there is power and green if a video signal

is present.

NOTE: The DA103-107/110 derives

power from the video output

connector of the computer. If the

computer does not supply power

at the video connector, it is

necessary to connect the USB

connector (from the video cable

provided)to an unused USB port

on the computer. If there is no

USB port available, proceed to

Step 2 and use the external

adapter.

Step 2. Skip this step if the LED is on.

Connect the DA103-107/110’s power jack

to an AC power adapter and plug the

adapter into a working outlet.

Step 3. If the power is on, the LED on the

DA103-107/110 should be on and red;

green if a signal is present.

Step 4. Connect VGA-type cablesfrom the

15-pin HD output connectors on the

DA103-107/110 to the display devices.

Step 5. The DA103-107/110 is now operational.

Verify the picture quality on the receiving

monitor is equivalent to the quality as

displayed on the local monitor.

OPERATION 7

The DA103-107/110 requires no adjustments for

proper performance. Once set-up, the

DA103-107/110 will work trouble-free without user

intervention.

TROUBLESHOOTING GUIDE 8

We have carefully tested and found no problems in

the supplied DA103-107/110.However, we would

like to offer suggestions for the following:

8.1 THE LED IS NOT RED.

Cause 1: There is no power.

Solution: Verify the DA103-107/110 is

connected to the proper power

adapter or USB port.

Solution 2: Make sure the adapter is plugged

into a working outlet and that power

is on.

Cause 2: The cables are loose.

Solution: Verify the power plug from the AC

adapter is plugged all the way into

the DA103-107/110.

Cause 3: The DA103-107/110 has a

problem.

Solution: If there is still no power, the

DA103-107/110 may require

service. Please call ALTINEX at

(714) 990-2300.

DISTRIBUTION AMPLIFIERS

400-0449-0058

8.2 THERE ARE NO REMOTE IMAGES.

Cause 1:The source has a problem.

Solution: Connect the output of the computer

directly to each monitor and verify

the quality is good. If the imagesare

good, see Cause 2.

Cause 2: Cable connections are wrong.

Solution: Verify the input of the

DA103-107/110 is connected to the

output of the computer using the

cable provided.

Solution 2: Verify that the Signal Present LED

on the DA103-107/110 is on and

green. If the LED is on and green,

check the connections from the

receiver to the displays.

Solution 3: If the LED on the DA103-107/110 is

red, there may be a problem. Please

call ALTINEX at (714) 990-2300.

ALTINEX POLICIES 9

9.1 LIMITED WARRANTY/RETURN POLICIES

Please see the ALTINEX website at

www.altinex.com for details on warranty and

return policies.

9.2 CONTACT INFORMATION

ALTINEX, Inc.

592 Apollo Street

Brea, CA 92821 USA

TEL: 714 990-2300

TOLL FREE: 1-800-ALTINEX

WEB: www.altinex.com

E-MAIL: [email protected]

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Altinex Amplificatore

Altinex

Altinex DA1226AT Manuale utente

Altinex

Altinex DA1902SX Manuale utente

Altinex

Altinex MULTITASKER MT113-100 Manuale utente

Altinex

Altinex SIDEKICKER DA103-107 Manuale utente

Altinex

Altinex DA1906SX Manuale utente

Altinex

Altinex SK2002DA Manuale utente

Altinex

Altinex Cat-5 Computer Video Receiver DA1921SX Manuale utente

Altinex

Altinex Distribution Amplifier DA1322AT Manuale utente

Altinex

Altinex SIGNAL MANAGEMENT SOLUTIONS DA1907LX Manuale utente

Altinex

Altinex DAA0106-V0A2 Manuale utente

Altinex

Altinex DITTO-AMP Manuale utente

Altinex

Altinex Video and S-Video Distribution Amplifier Cards... Manuale utente

Altinex

Altinex DA1222AT Manuale utente

Altinex

Altinex DA1706SV Manuale utente

Altinex

Altinex Distribution Amplifier DA1506RT Manuale utente

Altinex

Altinex Distribution Amplifier DA1506RT Manuale utente

Altinex

Altinex Multi-Tasker MT103-104 Manuale utente

Altinex

Altinex MULTI-TASKER MT108-102 Manuale utente

Altinex

Altinex DA1206RM Manuale utente

Altinex

Altinex DA1913GL Manuale utente

Altinex

Altinex 1-In 2-Out VGA Distribution Amplifier... Manuale utente

Altinex

Altinex DA1912SX Manuale utente

Altinex

Altinex DA1804NT Manuale utente

Altinex

Altinex DA1904SX Manuale utente

Manuali Amplificatore popolari di altre marche

ASTRO

ASTRO HVO V40 P Manuale utente

Marantz

Marantz SUPERSCOPE BLA-545 Istruzioni per il montaggio

NAD

NAD CI980 Manuale utente

Technics

Technics SE-CH770 Manuale utente

Harman Kardon

Harman Kardon HK6300 Manuale utente

NAD

NAD T975 Manuale utente

McIntosh

McIntosh MA6850 Manuale utente

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuale utente

Viatron

Viatron Autrix Manuale utente

GME

GME GA9800 Manuale utente

Atlas

Atlas CP700 Manuale utente

Roland

Roland KC-1000 Manuale utente

Pyle

Pyle PFMRA350BW Manuale utente

Advantage

Advantage S-250 Manuale utente

IRT Electronics

IRT Electronics DVA-3007 Manuale utente

Dimavery

Dimavery BA-100 Series Manuale utente

Sony

Sony XM-S400D Manuale utente

Schertler

Schertler ROY X Manuale utente
