Aluratek ADMPF214B Manuale utente
mnl M10423 Copyright © 2017 Aluratek, Inc. All Rights Reserved.
aluratek.com
model ADMPF214B
Instructional Manual
14” Digital Photo Frame
04
06
07
08
08
09
10
11
13
14
15
16
Table of Contents
Frame Features .............................................................................................................
Frame Control Close-up ...............................................................................................
Remote Control Close-up ..............................................................................................
Package Contents .........................................................................................................
Getting Started ...............................................................................................................
Operating Instructions
Viewing Photos .........................................................................................................
Transferring Files from your PC / Mac to the Frame’s Internal Memory....................
Photo Function
Photo Set-up .............................................................................................................
Video Function
Video Set-up .............................................................................................................
Music Function
Music Set-up .............................................................................................................
System Function
System Set-up ..........................................................................................................
Calendar Function
Calendar Set-up ........................................................................................................
17
18
19
Table of Contents
Technical Support ..........................................................................................................
Radio and TV Interference Statement ...........................................................................
Warranty ........................................................................................................................
1
2
14” LCD Screen
Black Matte Frame
Remote Sensor
White Matte
SD/SDHC Card Slot
Headphone Jack
3
4
5
7
8
9
10
13
14
AConnect a USB hard drive, USB flash drive or SD/SDHC card to easily access
and share your favorite pictures / video / music.
Transfer and store files quickly and easily from your personal computer to the
frame's 4GB built-in memory with hi-speed USB 2.0.
USB 2.0 Port
Mini USB Port
Power Adapter Port
Menu Button
Directional Keypad
Power Button
Wall Mount Holes
Speakers
Frame Stand
Security Lock
1
2
A
3
4
B
B
6
5
12
7
13
14
89
11
15
16
10
6
11
12
15
16
Frame Features
4
1
2
14” LCD Screen
Black Matte Frame
Remote Sensor
White Matte
SD/SDHC Card Slot
Headphone Jack
3
4
5
7
8
9
10
13
14
AConnect a USB hard drive, USB flash drive or SD/SDHC card to easily access
and share your favorite pictures / video / music.
Transfer and store files quickly and easily from your personal computer to the
frame's 4GB built-in memory with hi-speed USB 2.0.
USB 2.0 Port
Mini USB Port
Power Adapter Port
Menu Button
Directional Keypad
Power Button
Wall Mount Holes
Speakers
Frame Stand
Security Lock
1
2
A
3
4
B
B
6
5
12
7
13
14
89
11
15
16
10
6
11
12
15
16
5
6
Frame Control Close-Up
1 - Power On / O
2- Menu
(a) Press to return to previous screen
(b) Press & hold to return to Main Menu
3 - ►║ Play / Pause
(a) Press to select option on Main Menu
(b) Press to pause slideshow, music or video
4 - |◄◄ Up Arrow
(a) Press to navigate UP when selecting options
(b) Press to select Previous le (Photo & Music mode)
(c) Press & hold to Fast Forward
5 - ►►| Down Arrow
(a) Press to navigate DOWN when selecting options
(b) Press to select Next le (Photo & Music mode)
(c) Press & hold to Scan Backward
6 - Left Arrow
(a) Press to navigate LEFT when selecting options
(b) Press & hold to lower volume
7 - Right Arrow
(a) Press to navigate RIGHT when selection options
(b) Press & hold to increase volume
MENU
1
2
4
3
7
5
6
7
1
POWER
SETUP
VOL -
MENU
ZOOM
ROTATE
MUTE
RETURN
VOL +
BGM
OK
Remote Control Close-Up
2
311
512
4
6
13
1. BGM - Start slideshow with background music
(If there are music les on the same memory media)
2. Power
3. Menu - Takes you to the main menu
4. Up, Down, Left, Right Arrows - Use arrow keys
to navigate your way through various menus
5. OK
6. Setup - Takes you to the setup menu
7. Volume + / Volume -
8. Advance to Previous
9. Advance to Next
10. Mute
11. Return
12. Play / Pause
13. Zoom
14. Rotate
10
7
14
8
9
Getting Started
Plug in the power adapter and press the to power on the photo frame.
8
Package Contents
Your order has been carefully packaged and inspected. The following accessories should
be included in your package. Please inspect the contents of the package to ensure that
you have received all items and that nothing has been damaged. If you discover a problem,
please contact us immediately for assistance.
• Power Adapter
• Remote Control
• USB 2.0 Cable
• Stand de Cadre
• Registration Card
9
Operating Instructions
Viewing Photos
• Please insert your memory card (SDHC,SD) at this time.
• The frame will start slideshow automatically when the card is inserted.
• The slideshow can be stopped by pressing the “►||” button on the frame. You can
then press the “◄” or “►” button to see the next or previous picture.
10
Operating Instructions
Transferring Files from your PC / Mac to the Frame’s Internal Memory
• A USB cable is included with your digital frame to connect it to your PC/ MAC. Connect
the small connector to your digital frame and the larger connector to your PC / MAC.
• Once connected, the frame will display a USB connector on the screen. On a PC, the
frame’s internal memory will appear as a removable drive when viewed in My Computer.
On a Mac, the frame will appear as a drive icon on the desktop.
• Copy your photo, video and music les from your PC / MAC into the icon representing
the frame’s internal memory. When nished disconnect the USB cable from the PC or
MAC. (Note: For a Mac, eject the drive icon before disconnecting the USB cable.)
• The frame will return to normal operation once it is disconnected from your PC / MAC.
