BreezeACCESS II CX
Extending Your Reach
We're on your wavelength.
Product Highlights
The BreezeACCESS CX Cell Extender incorporates the features of a mini base
station, backhaul and subscriber unit into an integrated, eas -to-deplo
package. Featuring:
The BreezeACCESS CX Cell Extender, designed to re-distribute broadband coverage from a primar wireless
base station while also serving as a local subscriber, can connect users who were previousl unreachable due
to obstructions such as foliage or hills. This eliminates the need to deplo costl new backhauls and base
stations to connect lucrative pockets of subscribers, significantl improving the economics of wireless
broadband deplo ments.
The CX uses a two-piece intermediate frequency (IF) architecture with both components designed to
be installed completely outdoors. This design permits a high degree of installation flexibility and
eliminates the need for expensive runs of large LMR or Heliax cables. The CX accommodates all
antennas currently certified with BreezeACCESS II.
Configured as a local subscriber that also creates a microcell connection to customers who are
not within the base station's line of site, the CX can be deployed in minutes, usually without
requiring a re-occurring site lease. This unique feature set enables cost efficient access to more
revenue per base station.
Using the same firmware and antenna choices as the rest of the industry-leading BreezeACCESS II
family of wireless broadband products, the CX Cell integrates into existing BreezeACCESS II
infrastructure.
BreezeCOM and Floware unite
Two-piece IF architecture for implicity, peak power and low co t cabling
Integrated Ethernet for local ub criber acqui ition
100% outdoor in tallable for mounting flexibility
Full LED diagno tic for quick antenna alignment and a ociation count
Remote telnet or SNMP, or local erial port, for ea y management
Integrated 16 dBi antenna on backhaul radio for fa ter deployment
Support external antenna on Acce Unit for cu tom coverage
213369 rev.a
© Copyright 2001 Alvarion, Ltd. All rights reserved.
Alvarion, BreezeCOM, Floware, WALKair, WALKnet, BreezeNET, BreezeMANAGE, BreezeNET PRO, BreezeNET DS, BreezeACCESS, BreezeLINK, BreezeVIEW and/or other
products and/or services referenced herein are either registered trademarks, trademarks or service marks of Alvarion, Ltd. or Alvarion, Inc..
All other names are or may be the trademarks of their respective owners.
We're on your wavelength.
www.alvarion.com
International Corporate Headquarters
Tel: +972 3 645 6262
Fax:+972 3 645 6222
Email: [email protected]
North America Headquarters
Tel: (760) 517 3100
Fax: (760) 517 3200
Email: [email protected]
Alvarion Worldwide Offices:
Latin America & Caribbean
Tel: +1 954 764 7420
Fax:+1 954 746 9332
Email: [email protected]
Asia acific
Tel: +852 2786 9996
Fax:+852 2310 0062
Email: far[email protected]
China
Tel: +86 10 6510 2800
Fax:+86 10 6510 2803
Email: [email protected]
Japan
Tel: +81 3 3506 7616
Fax:+81 3 3506 7616
E-mail: [email protected]
France
Tel: +33 1 34 38 54 30
Fax:+33 1 34 38 54 39
Email: [email protected]
Germany
Tel: +49 89 90405 923
Fax:+49 89 90405 922
Email: [email protected]
U.K. & Ireland
Tel: +44 845 450 1414
Fax:+44 845 450 1455
Email: [email protected]
Czech Republic
Tel: +420 222 191 233
Fax:+420 222 191 200
Email: [email protected]
Brazil
Tel: +55 11 3815 6225
Fax:+55 11 3813 0467
Email: [email protected]
Uruguay
Tel: +598 2 712 3210
Fax:+598 2 712 3211
Email: [email protected]
Russia
Tel: +7 (095) 737-88-06
Fax: +7 (095) 287-9899
Email: [email protected]
Romania
Tel: +40 1 335 7631
Fax:+40 1 335 7634
Email: [email protected]
Specifications
Specifications
Radio Frequency 2.400-2.4835 GHz ISM band
Operating Mode Time Division Duplex
Radio Access Method FH-CDMA
Standard Compliance FCC Part 15.247
Channel Bandwidth 1 MHz
Antenna (SU-RA) [downlink] 16 dBi, 20°x 20°, VPOL, EN 301 525 Class TS 2 compliant
Antenna Port (AU-RE) [mirco-cell] N-Type Connector, 50 ohm
Output Power (at antenna port) 26 dBm typical. Control Range 20 dB typical
Maximum RX Input Power -20 dBm
Gross Bit Rate at sensitivity, typical 1 Mbps -87 dBm
(dBm at antenna port, BER 10E-6) 2 Mbps -81 dBm
3 Mbps -73 dBm
Modulation 2, 4, 8 level GFSK modulation (1, 2, 3 bits / symbol).
IF Communication Interface
IF Frequency 440 MHz
IF cable Impedance 50 ohm
Maximum IF cable Attenuation 15 dB
Maximum IF cable DC Resistance 1.5 ohm
Interface
Interface SU-RA AU-RE Interface Unit
IF TNC jack, lightning TNC jack, lightning TNC jack, lightning protected
protected protected
ANT N-Type jack, lightning protected
Ethernet & 10Base-T (RJ-45) in a sealed Physical Media ENSR 1FB5
Monitor Receptacle that mates with ENSAM315 field
attachable connector
Power 12 VDC from Interface 12 VDC from Interface UL/CSA listed power cable through
Unit via the IF cables Unit via the IF cables a Heyco-Flex Straight Connector
Electrical, Mechanical and Environmental
AU-RE SU-RA Interface Unit
Electrical 12 VDC from 12 VDC from Interface 110-240 VAC, 50-60Hz, 1.4A max
Unit via the IF cable Unit via the IF cables
Mechanical 12 x 4.7 x 1.8 in, 3.5 lbs 12 x 12 x 2.8 in, 5.5 lbs 11 x 9 x 4.3 in, 13 lbs
30.6 x 12 x 4.7 cm, 1.6 kg 30.6 x 30.6 x 7.2 cm, 2.5 kg 28 x 23 x 11cm, 5.9 kg
Operating Temperature -40°F to 131°F -40°F to 131°F14°F to 131°F
-40°C to 55°C -40°C to 55°C -10°C to 55°C
Operating Humidity 100% RH Condensing 100% RH Condensing 100% RH Condensing
Standards Compliance, General
EMC FCC Part 15.247, 15.207, 15.209
Safety IEC 60 950 US/C (TUV), FCC 1.1307
Environmental ETS 300 019 part 2-4 class 4.1E
Radio FCC Part 15.247
