Amana MBVB Series Manuale utente

SS-AMBVC www.amana-hac.com 10/23

Amana® is a trademark of Maytag Corporaon or its related companies and used under license to Goodman Company, L.P., Houston, Texas.

* Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the

10-Year Parts Limited Warranty, online registraon must be completed within 60 days of installaon. Online

registraon is not required in California or Québec. The duraon of warranty coverage in Texas and Florida diers

in some cases.

MBVB

Multi-position, Variable speed

ECM-based, Modular Blower

ComfortbridgeTM Compatible

Contents

Air Handler Nomenclature ....................2

Heater Kit Nomenclature.......................2

Product Specicaons ...........................3

Airow Data ............................................4

Heat Kit Data...........................................5

Dimensions ............................................6

Wiring Diagram.......................................7

Accessories .............................................8

Product Features Cabinet Features

• Variable-speed ECM blower motor

• Integrated communicang

ComfortBridge™ Technology

• Commissioning and diagnoscs via

on board Bluetooth with the CoolCloud™

phone and tablet applicaon

• Advanced conguraon of the airow

and tonnage in communicang mode

• Provides constant CFM over a wide

range of stac pressure condions

independent of duct system

• CFM indicator

• Fault recall of six most recent faults

• Provides adjustable low CFM for ecient

fan-only operaon

• Improved humidity and comfort control

• Built-in compability with mul-stage heat

pump and cooling applicaons

• UL 60335 2-40 Compliant

• AHRI cered; ETL listed

• Blower secon usable as electric heater

• Horizontal or vercal conguraon capabilies

• 21” depth for easier ac access

• Foil-faced insulaon covers the internal

casing to reduce cabinet condensaon

• Galvanized, leather grain-embossed nish

• Cabinet air leakage less than 2% at

1.0 inch H₂0 when tested in accordance

with ASHRE standard 193

• Cabinet air leakage less than 1.4% at

0.5 inch H₂0 when tested in accordance

with ASHRE standard 193

• Field Installed 3 kW – 20 kW electric

heater kits available

2www.amana-hac.com SS-AMBVC SS-AMBVC www.amana-hac.com 3

Nomenclature

M B V B 1 2 B P 1 X 0 0 A A

1 2 3 4 5 6 7 8 9 10 11 12 13 14



 A











 





 

 

 

 



 

B- 17.5"

C- 21.0"

D - 24.5"

  T A 2 5 1

1 2 3 4 5 67 8 9

Unit Type 











 



 

 





3 3.00 kW 6 6.00 kW 10 10.00 kW

5 5.00 kW 8 7.00 kW 15 15.00 kW

20 20.00 KW

2www.amana-hac.com SS-AMBVC SS-AMBVC www.amana-hac.com 3

Product Specifications

 MBVB12BP1X00 MBVB16CP1X00 



Diameter 10" 10" 11"

Width 8" 8" 10"



Voltage (V) 208/230 208/230 208/230

MCA (A) 4.9 6.5 6.5

MOP (A) 15

 ½¾¾



Width 17½" 21" 24½"

Depth 21" 21" 21"

Height 26" 30" 30"

 67 80 86

• Minimum Circuit Ampacity and Maximum Overcurrent Protecon Device (MOD) for blower without supplemental heat installed.

Refer to unit nameplate for these specicaons with approved accessory heaters installed.

• Condensate management kits are available for units installed in high temperature and high humidity areas. Kit number MBK0002

has been developed to resolve condensate issues in the eld and is available from the Service Parts Department. Refer to IO-849

for installaon instrucons.

4www.amana-hac.com SS-AMBVC SS-AMBVC www.amana-hac.com 5

Airflow Data

           

MBVB12

BP1X00A*

ALow 420 415 400 400 395 390 390 390 380

BLow 550 545 540 540 535 530 530 525 520

CLow 680 675 670 665 660 655 655 650 640

DLow 810 805 800 800 800 795 790 785 785

AHigh 615 605 600 600 595 590 590 585 580

BHigh 805 805 800 800 800 795 790 785 780

CHigh 1010 1005 1000 1000 995 995 990 985 975

DHigh 1210 1205 1200 1200 1200 1195 1195 1190 1180

MBVB16

CP1X00A*

ALow 690 680 670 665 660 655 625 595 575

BLow 850 830 800 795 790 785 775 750 725

CLow 980 970 940 935 930 910 890 865 860

DLow 1110 1085 1070 1055 1045 1025 1000 990 975

AHigh 1045 1015 1000 990 975 950 935 920 900

BHigh 1245 1215 1200 1180 1175 1165 1150 1130 1115

CHigh 1415 1410 1400 1365 1360 1350 1340 1330 1320

DHigh 1605 1600 1600 1540 1530 1520 1510 1500 1490

MBVB20

DP1X00A*

ALow 835 815 800 800 795 795 790 775 750

BLow 1075 1070 1070 1065 1050 1045 1045 1040 1035

CLow 1210 1205 1200 1200 1195 1190 1190 1185 1175

DLow 1345 1340 1340 1320 1320 1315 1315 1305 1305

AHigh 1210 1205 1200 1195 1150 1150 1145 1135 1115

BHigh 1610 1605 1600 1540 1535 1535 1530 1520 1510

CHigh 1830 1805 1800 1785 1760 1760 1755 1750 1715

DHigh 2020 2010 2000 1995 1995 1970 1970 1965 1955



   MBVB12BP1X00



MBVB16CP1X00







o o A600 1000 1200

on o B800 1200 1600

o on C1000 1400 1800

on on D1200 1600 2000

 

S3 S4 Trim Value S5 S6

o o 0o o A

on o 10% on o B

o on -10% o on C

on on 0on on D



    MBVB12BP1X00



MBVB16CP1X00







o o on 20 NA NA 2000

o on o 15 1400 1500 1500

o on on 10 1000 1000 1200

on o o 8740 1000 1000

on o on 6635 800 800

4www.amana-hac.com SS-AMBVC SS-AMBVC www.amana-hac.com 5



  

 MCA¹ MOP²  MCA¹ MOP² MCA¹ MOP²

MBVB12BP1X00AB

HKTAN031

HKTA*051

HKTAN061

HKTA*081

HKTA*101

HKTAD151

0/0

10.8/12.5

18.1/20.8

21.7/25.0

25.3/29.2

36.1/41.7

4.9/4.9

18.4/20.5

27.4/30.9

32.0/36.1

36.5/41.3

50.0/57.0

15/15

20/25

30/35

35/40

40/45

50/60

---

18/20.8

---

22.5/26.0

---

25/30

---

72.6/83.0

---

80/90

MBVB16CP1X00AB

HKTAN031

HKTA*051

HKTAN061

HKTA*081

HKTA*101

HKTAD151

0/0

10.8/12.5

18.1/20.8

21.7/25.0

25.3/29.2

36.1/41.7

6.5/6.5

20.0/22.1

29.1/32.5

33.6/37.8

38.1/43.0

51.6/58.6

15/15

20/25

30/35

35/40

40/45

60/60

---

18/20.8

---

22.5/26.0

---

25/30

---

74.2/84.6

---

80 / 90

MBVB20DP1X00AB

HKTAN031

HKTA*051

HKTAN061

HKTA*081

HKTA*101

HKTAD151

HKTAD201

0/0

10.8/12.5

18.1/20.8

21.7/25.0

25.3/29.2

36.1/41.7

6.5/6.5

20.0/22.1

29.1/32.5

33.6/37.8

38.1/43.0

51.6/58.6

15/15

20/25

30/35

35/40

40/45

60/60

---

18/20.8

36.1/41.7

---

22.5/26.0

45.2/52.1

---

25/30

50/60

---

74.2/84.6

96.8/111

---

80/90

100/125

All ampacies noted above include air handler motor amps

Circuit 1: Single-phase for Air Handlers / Circuit 2: Three-phase for HKR3 Heater Kits

¹ Minimum Circuit Ampacity (Heater Amps + Motor Amps) X 1.25

² Maximum Overcurrent Protecon = 2.25 X Motor Amps + Heater Amps

* Revision level that may or may not be designated

C = Circuit Breaker Opon

--- indicates Not Required

• Only applicable when HKA kits are included in table

HKA meets the new UL1995 requirements for 15 and 20KW heaters

• MBVC and MBR models

Heat Kit Data

Heating kW Correction Factor

 240 230 220 210 208

 1.00 0.92 0.84 0.77 0.75

Mulply the 240-volt heang capacity by correcon factors.

6www.amana-hac.com SS-AMBVC SS-AMBVC www.amana-hac.com 7

Dimensions

Top View

Side and Front Views





  

MBVB12BP1X00 17½" 21" 26"

MBVB16CP1X00 21" 21" 30"

MBVB20DP1X00 24½" 21" 30"

MBVC_TOP_VIEWS

987654321

11.3"

11.1"

20.0"

10.9"

16.5"

10.3"

13.2"

11.3"

23.5"

SPECIAL CHARACTERISTICS: (REFER MSP 822-01 FOR DETAILS)

= CRITICAL CHARACTERISTIC REQUIRES AN INITIAL CPK OF 1.33 AND USE OF STATISTICAL PROCESS CONTROL.

= SIGNIFICANT CHARACTERISTIC REQUIRES AN INITIAL CPK OF 1.00 AND USE OF STATISTICAL PROCESS CONTROL.

INABILITY TO MEET THE REQUIRED INITIAL CPK VALUE WILL REQUIRE 100% INSPECTION.

COMPONENTS AND MATERIALS SPECIFIED HEREIN WILL ALSO CONFORM TO THE APPLICABLE SECTION OF GOODMAN MSP

860-01 WORKMANSHIP STANDARD.

CONFIDENTIAL PROPERTY OF GOODMAN MANUFACTURING COMPANY, L.P. OR ITS AFFILIATES NOT TO BE DISCLOSED TO

OTHERS, COPIED, OR USED FOR ANY PURPOSE EXCEPT AS AUTHORIZED IN WRITING. MUST BE RETURNED UPON DEMAND,

ON COMPLETION OF ORDER, OR OTHER PURPOSE FOR WHICH IT WAS LENT

GOODMAN MANUFACTURING COMPANY,L.P.

DRAWING TO BE INTERPRETED IN

ACCORDANCE WITH ASME Y14.100

TITLE

MBVC_DIMENSIONS

DIMENSIONS ARE IN INCHES

UNLESS OTHERWISE NOTED.

TOLERANCES UNLESS

OTHERWISE NOTED

ANGLES 1.5

.X .1

.XX .03

.XXX .015

HOLES : .005

TUBE CUT LG: .063

DWN: HCL-BS ENG: SCALE: NTS

DATE: CHK: SHEET: 1 OF 1

DWG.

NO. MBVC_TOP_VIEWS

21"

17½" 24½"

10.9"

16.5"

4.0 (10.6 cm)

2.5" (6.35 cm) 2.5" (6.35 cm)

4.0 (10.6 cm)

10.3

5.8" (14.73 cm)

7.3" (18.54 cm)

17½"

4.0" (10.6 cm)

5.8" (14.73 cm)

7.3" (18.54 cm)

2.5" (6.35 cm)16.1" (40.89 cm)

11.3"

11.1"

20.0"

4.0" (10.6 cm)

21"

4.0" (10.6 cm)

5.8" (14.73 cm)

7.3" (18.54 cm)

2.5" (6.35 cm)19.6" (49.78 cm)

4.0" (10.6 cm)

13.2"

11.3"

23.5"

24½"

6www.amana-hac.com SS-AMBVC SS-AMBVC www.amana-hac.com 7

Wiring Diagram – Air Handler

TB3

TB4 TB7

DH/

GR CY

R1 2C

CIRCULATOR BLOW ER

CIRCULATOR

MICRO

AUX IN

AIR

230 VAC

PL1

SEE

NOTE 7

DEHUM

24 VAC

BLWR

AIR

40 VA

40 VA TRANSFORMER, SEE NOTES 1 AND 14

INDOOR

24 VAC

PL2

FUSE 3 A

208/230 VAC

GRND

ECM MOTOR

HARNESS

GRND

COM

INTEGRATED CONTROL MODULE

24V THERMOSTAT CONNECTIONS

COM

DISCONNECT

TR2

GRND (4)

INDOOR

TH2

+VDC (1)

208 VAC

RX (2)

GRND

EH1

TX (3)

GRND

ELECTRIC STAGE 2

TRANSFORMER

ELECTRIC HEAT STAGE 1

BLWR

EQUIPMENT GRND

TERMINAL

PLUG CONNECTION

LOW VOLTAGE FIELD

HI VOLTAGE FIELD

JUNCTION

HI VOLTAGE (230V)

PROT. DEVICE

INTEGRATED CONTROL

LOW VOLTAGE (24V)

FIELD SPLICE

INTERNAL TO

FIELD GRND

OVERCURRENT

0140A01418-A

CONDENSATE SWITCH

AUX OUT

EH2

RESISTOR

432

SEE NOTE 9

4 - GND

SEE NOTE 6

GY PU WH GR BL RD BL RD GY BK

THERMOSTAT OUTDOOR UNIT

(SEE NOTE 13)

NOTES:

1. PLACE RED WIRES ON TRANSFORMER TERMINAL 2 FOR 208 VAC OPERATION.

2. MANUFACTURER'S SPECIFIED REPLACEMENT PARTS MUST BE USED WHEN SERVICING.

3. IF ANY OF THE ORIGINAL WIRES AS SUPPLIED WITH THIS UNIT MUST BE REPLACED, IT MUST BE REPLACED WITH WIRING MATERIAL

HAVING A TEMPERATURE RATING OF AT LEAST 105°C. USE COPPER CONDUCTORS ONLY.

4. UNIT MUST BE PERMANENTLY GROUNDED AND CONFORM TO N.E.C AND LOCAL CODES.

5. TO RECALL THE LAST 6 FAULTS, DEPRESS THE RIGHT PUSH BUTTON FROM STATUS MENU ONCE AND THEN USE THE LEFT OR RIGHT

BUTTON TO REVIEW ALL THE FAULTS HISTORY.

6. 2 GREEN LEDS INDICATES CLIMATE TALK AND DATA AC NETWORK TRAFFIC STATUS. USE LEARN MENU FOR CLIMATE TALK NETWORK

RESET.

7. DISCARD CONNECTOR PL1 WHEN INSTALLING OPTIONAL HEAT KIT.

8. THE CONDENSATE ALARM SWITCH (AUX) TERMINALS CAN ONLY BE UTILIZED WITH COMMUNICATING MODE SETUPS AND MUST BE

ENABLED WITH COMMUNICATING THERMOSTAT. THIS FEATURE IS NOT OPERATIONAL WITH NON COMMUNICATING SYSTEMS.

9. USE N.E.C CLASS 2 WIRE.

10. SEE MANUAL FOR PUSH BUTTON OPERATION.

11. SEE MANUAL FOR 7-SEGMENT DISPLAY DIAGNOSTIC CODES AND MENU CODES.

12. SEE MANUAL FOR LEDS FUNCTIONALITY

13. R AND C TERMINALS (USED FOR 24VAC OUTDOOR CONTROL VOLTAGE) ARE OPTIONAL FOR 2 STAGE COMMUNICATING AIR

CONDITIONERS. R AND C TERMINALS ARE NOT TO BE USED FOR 2 STAGE COMMUNICATING HEAT PUMP APPLICATIONS.

FOR COMMUNICATING HEAT PUMP OR IF ONLY TWO THERMOSTAT WIRES ARE AVAILABLE, A SEPARATE TRANSFORMER MUST BE

INSTALLED IN THE OUTDOOR UNIT FOR CONTROL BOARD POWER.

1 AND 2 WIRES ARE REQUIRED FOR ALL APPLICATIONS. SEE INSTALLATION MANUAL FOR FULL SYSTEM WIRING EXAMPLES.

14. LOW VOLTAGE TRANSFORMER RATED 24VAC OUTPUT 40VA @AMP 1.67A

BL ---- BLUE

PK ---- PINK

GY ---- GRAY

WH ----WHITE

BR ---- BROWN

COLOR CODES:

OR ---- ORANGE

RD ---- RED

PU ---- PURPLE

YL ---- YELLOW

GN ---- GREEN

BK ---- BLACK

208 / 230 VAC

III

READ THE INSTRUCTIONS

CLASS III

III

SEE NOTES 1 AND 14

⚠Warning High Voltage: Disconnect all power before servicing or installing this unit. Mulple power

sources may be present. Failure to do so may cause property damage, personal injury, or death. ⚡

Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.

8www.amana-hac.com SS-AMBVC

Our connuing commitment to quality products may mean a change in specicaons without noce.

Accessories

Single Point Kit

 

 X X

Can only be installed along with the above heat kits. This kit will t any MBVK blower as long

as a compable heat kit is installed in the unit.

MBVB Blower Performance Data Dipswitch Summary

  

S1 - S2* Cooling / HP Airow

A/B/C/D Airow D

S3 - S4* Cooling / HP / Aux Trim

(-10%, 0, +10%) No Trim

S5 - S6* Cooling Prole

A,B,C,D Prole 1

S7* Dehum

(on/o) O

S8 Unused On

S9 - S11 Heater Kit Kw O/O/O

* Valid only if the system is wired in legacy mode. If system is wired in the 4-wire communicang

mode, these funcons are selected via the user menu in the CTK01AA T-STAT.

Heat Kit Selection

 MBVB12BP1X00 MBVB16CP1X00 

 X X X

 X X X

 X X X

 X X X

 X X X

 X X X

 X X X

 X X X

 X X X

 --- --- X





Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Amana Soffiatore

Amana

Amana MBVC Series Guida rapida

Manuali Soffiatore popolari di altre marche

Weed Eater

Weed Eater VS2000BV Manuale utente

KRAUSMANN

KRAUSMANN U37020-00 Manuale utente

Bosch

Bosch ALB 36 LI Manuale utente

Cub Cadet

Cub Cadet HB425 Manuale utente

GreenWorks Pro

GreenWorks Pro BLB482 Manuale utente

ARIETE

ARIETE 2768 Manuale utente

NuTone

NuTone 331H Manuale utente

GÜDE

GÜDE GLB 200 18 Li-Ion Manuale utente

I.VA.CO.

I.VA.CO. SC Series Istruzioni operative

DeWalt

DeWalt DCE100 Manuale utente

Becker

Becker SV 7.330 Manuale utente

Metabo

Metabo AG 18 Pro Manuale utente

Desa

Desa GA3650TB Manuale utente

Echo

Echo Power Blower PB-230LN Manuale utente

Echo

Echo PB-413H Manuale utente

Black & Decker

Black & Decker BV3100 Manuale utente

Ryobi

Ryobi RY08570 Manuale utente

Haaga

Haaga 355 Manuale utente
