AmazonBasics B07P897S54 Manuale utente
B07P897S54, B07P89796B, B07PCLV36K, B07PCM39CK,
B07P74YSYM, B07P8973C1
Standard Towel Bar - 18 & 24-Inch
Barre à Serviettes Standard - 45,7cm et 61,0cm
Standard-Handtuchhalter – 45,7cm und 61,0cm
Portasciugamani Standard - 45,7 e 61,0cm
Toallero de Barra Estándar - 45,7 y 61,0cm
スタンダードタオルバー– 45.7 & 61.0 cm
Standardowy drążek na ręcznik - 45,7cm i 61,0cm
Standard handdukstång - 45,7cm och 61,0cm
English ..................................... 3
Français ................................... 9
Deutsch.................................. 15
Italiano................................... 21
Español.................................. 27
日本語 ..................................... 33
Polski..................................... 39
Svenska ................................. 45
3
Welcome Guide •English
Contents:
Before getting started, ensure the package contains the following components:
Part
• One (1) Bathroom Towel Bar
• Four (4) Plastic Anchors
• Four (4) Drywall Screws
• Two (2) Mounting Brackets
• Paper Mounting Template
Recommended Tools:
• Power Drill
• 1/4” (6.35mm) Drill Bit
• Level
• Cross-head Screwdriver
• Hammer
• 1/8” (3.3mm) Slotted Screwdriver
• Pencil
• Tape Measure
• Safety Glasses
• Tape
WARNING Maximum load: 22 lbs (10 kg).
4
Installation
Step 1: Determine Mounting Location
•
Determine where you would like to mount your bathroom hardware fixture by placing it on the wall.
• Mark the location with tape or a pencil.
• Tape your mounting template to the wall, covering the desired location.
NOTICE Ensure that the template is straight by aligning a level with the center line of the
template.
Step 2: Mounting Brackets to Wall
• Using a drill and 1/4” (6.35mm) drill bit, drill two vertical holes for each mounting bracket in the
location specified on the template paper.
5
Installation
Step 3: Mounting Brackets to Wall
• Remove the mounting template from the wall and insert plastic drywall anchors into all 4drilled
holes. Lightly tap with hammer until anchors are flush with wall.
Step 4: Attaching Brackets to Wall
• Position mounting bracket against anchor holes and thread screws until secure.
NOTICE When securing the mounting bracket to the wall, make sure the flat side of the
bracket is against the wall.
6
Installation
Step 5: Attaching Fixture to Mounting Bracket
• Using a 1/8” (3.3mm) slotted screwdriver, loosen the metal set screw located at the base of
each fixture.
• Loosen screw until fixture is able to rest flush over mounting bracket.
Screw clockwise
• Place one fixture over top the mounting bracket with set screws facing down. With the fixture
resting on the wall, use a 1/8” (3.3mm) slotted screwdriver again to tighten the fixture onto the
mounting bracket.
• Make sure the fixture is secured to the wall by gently moving the post from side to side.
7
Installation
Step 6: Insert Towel Bar Into Fixtures
• Insert one end of the towel bar into the fixture you have already installed onto the wall.
• Insert the other end of the towel bar into the fixture that has not been mounted to the wall.
• Place the fixture over top the mounting bracket with set screws facing down.
• With the fixture resting on the wall, use a 1/8” (3.3mm) slotted screwdriver again to tighten the
fixture onto the mounting bracket.
• Make sure the fixture is secured to the wall by gently moving the post from side to side.
8
Warranty Information
To obtain a copy of the warranty for this product:
For US - Visit amazon.com/AmazonBasics/Warranty
For UK - Visit amazon.co.uk/basics-warranty
— or —
Contact Customer Service at 1-866-216-1072
Feedback
Love it? Hate it?
Let us know with a customer review.
AmazonBasics is committed to delivering customer-driven products that live up to your high
standards. We encourage you to write a review sharing your experiences with the product.
Please visit: amazon.com/review/review-your-purchases#
For further services:
Visit amazon.com/gp/help/customer/contact-us
— or —
Contact Customer Service at 1-866-216-1072
9
Guide de Démarrage •Français
Contenu:
Avant de commencer, veuillez vous assurer que l’emballage contient les composants suivants:
Composant
• Une (1) barre à serviettes de salle de bain
• Quatre (4) chevilles plastique
• Quatre (4) vis à cloison sèche
• Deux (2) supports de fixation
• Gabarit de montage en papier
Outils recommandés:
• Perceuse électrique
• Foret de 6,35mm (1/4”)
• Niveau
• Tournevis cruciforme
• Marteau
• Tournevis plat de 3,3mm (1/8”)
• Crayon
• Mètre-ruban
• Lunettes de protection
• Ruban adhésif
AVERTISSEMENT
Charge maximale: 10kg.
10
Installation
Étape1: Sélection de l’Emplacement du Montage
•
Déterminez l’endroit où vous souhaitez monter votre fixation pour salle de bain en la plaçant
sur le mur.
• Marquez l'emplacement à l’aide de ruban adhésif ou d’un crayon.
• Collez votre gabarit de montage au mur de telle sorte qu’il couvre l’emplacement choisi.
REMARQUE Assurez-vous que le gabarit est à niveau en alignant un niveau sur le segment
central du gabarit.
Étape2: Montage Des Supports Sur le Mur
• À l'aide d'une perceuse et d'une mèche de 6,35mm (1/4”), percez deux trous verticaux pour
chaque support de fixation à l'endroit désigné par le gabarit.
