Amazone Cenio 3000 Istruzioni per l'installazione

Original operating manual

Mounted cultivator

Cenio 3000

Cenio 3500

Cenio 4000

SmartLearning

www.amazone.de

Please enter the identication data of the implement. The identication data can be found on

the rating plate.

TABLE OF CONTENTS

1 About this operating manual 1

1.1 Diagrams 1

1.1.1 Warnings and signal words 1

1.1.2 Further instructions 1

1.1.3 Instructions 2

1.1.4 Lists 3

1.1.5 Item numbers in figures 3

1.2 Other applicable documents 4

1.3 Your opinion is important 4

2Safety and responsibility 5

2.1 Basic safety instructions 5

2.1.1 Meaning of the operating manual 5

2.1.2 Safe operating organisation 5

2.1.3 Knowing and preventing dangers 10

2.1.4 Safe operation and handling of the

machine 11

2.1.5 Safe maintenance and modification 13

2.2 Safety routines 17

3Intended use 19

4 Product description 20

4.1 Implement overview 20

4.1.1 Overview of the implement with

compression spring overload safety 20

4.1.2 Overview of the implement with

shear bolt overload safety 21

4.2 Function of the implement 21

4.3 Special equipment 21

4.4 Protective equipment 22

4.4.1 Road safety bars 22

4.5 Warning symbols 23

4.5.1 Positions of the warning symbols 23

4.5.2 Layout of the warning symbols 23

4.5.3 Description of the warning symbols 24

4.6 Rear lighting and identification 27

4.7 Rating plate on the implement 27

4.8 Soil tillage tools 28

4.8.1 Tine 28

4.8.2 Coulters 29

4.9 GreenDrill pack top seed drill 36

4.10 Threaded cartridge 36

5 Technical data 37

5.1 Dimensions 37

5.2 Soil tillage tool 37

5.3 Permitted mounting categories 37

5.4 Optimal working speed 37

5.5 Performance characteristics of

the tractor 38

5.6 Noise development data 38

5.7 Drivable slope inclination 38

6Preparing the machine 40

6.1 Calculating the required tractor

characteristics 40

6.2 Coupling the implement 43

6.2.1 Adjusting the 3-point mounting frame 43

6.2.2 Attaching the backstop profiles for

the lower links 43

6.2.3 Attaching the ball sleeve for the top

link 44

6.2.4 Driving the tractor towards the

implement 44

6.2.5 Coupling the hydraulic hose lines 44

6.2.6 Coupling the power supply 46

6.2.7 Coupling the 3-point mounting frame 46

6.2.8 Aligning the implement horizontally 46

6.3 Preparing the implement for

operation 47

6.3.1 Adjusting the working depth of the

coulters 47

TABLE OF CONTENTS

MG6806-EN-GB | Q.1 | 26.07.2022 | © AMAZONE I

6.3.2 Adjusting the working depth of the

levelling 48

6.3.3 Preparing the spring steel closer for

operation 50

6.3.4 Preparing the edge levelling discs

for operation 50

6.3.5 Adjusting the scraper to the roller 51

6.3.6 Removing the road safety bars 52

6.3.7 Adjusting the trailing elements 52

6.4 Preparing the machine for road

travel 54

6.4.1 Preparing the side elements for

road travel 54

6.4.2 Putting on the road safety bars 54

6.4.3 Reducing the implement width to

the permitted transport width 54

6.5 Calculating the permissible

payload 55

7 Using the machine 56

7.1 Using the implement 56

7.2 Turning on the headlands 56

8Eliminating faults 57

9Parking the machine 59

9.1 Uncoupling the 3-point mounting

frame 59

9.2 Driving the tractor away from the

implement 60

9.3 Uncoupling the power supply 60

9.4 Disconnecting the hydraulic

hose lines 61

10 Repairing the implement 62

10.1 Maintaining the implement 62

10.1.1 Maintenance schedule 62

10.1.2 Replacing tines with compression

spring overload safety 63

10.1.3 Replacing tines with shear bolt

overload safety 63

10.1.4 Replacing C-Mix-3 coulters 64

10.1.5 Replacing the C-Mix-3 Clip coulter 65

10.1.6 Replacing the discs 65

10.1.7 Checking the levelling connection 66

10.1.8 Checking the rollers 67

10.1.9 Checking the top link pin and lower

link pin 67

10.1.10 Checking the hydraulic hose lines 67

10.2 Lubricating the implement 69

10.2.1 Overview of lubrication points 70

10.3 Cleaning the implement 71

11 Loading the implement 72

11.1 Loading the implement with a

crane 72

12 Appendix 73

12.1 Bolt tightening torques 73

12.2 Other applicable documents 74

13 Directories 75

13.1 Glossary 75

13.2 Index 76

TABLE OF CONTENTS

MG6806-EN-GB | Q.1 | 26.07.2022 | © AMAZONE

About this operating manual 1

1.1 Diagrams

1.1.1 Warnings and signal words

Warnings are marked with a vertical bar with a

triangular safety symbol and the signal word. The

signal words "DANGER", "WARNING" or "CAUTION"

describe the severity of the potential danger and have

the following meanings:

DANGER

Indicates a direct threat with high risk for

severe physical injury, such as loss of

limbs or death.

WARNING

Indicates a possible threat with moderate

risk for severe physical injury or death.

CAUTION

Indicates a threat with low risk for light or

moderately severe physical injuries.

1.1.2 Further instructions

IMPORTANT

Indicates a risk for damage to the

implement.

CMS-T-00000081-D.1

CMS-T-005676-C.1

CMS-T-00002415-A.1

CMS-T-00002416-A.1

1 | About this operating manual

MG6806-EN-GB | Q.1 | 26.07.2022 | © AMAZONE 1

ENVIRONMENTAL INFORMATION

Indicates a risk for environmental damage.

NOTE

Indicates application tips and instructions for

optimal use.

1.1.3 Instructions

Numbered instructions

Actions that have to be performed in a specific

sequence are represented as numbered instructions.

The specified sequence of the actions must be

observed.

Example:

1. Instruction 1

2. Instruction 2

1.1.3.1 Instructions and responses

Reactions to instructions are marked with an arrow.

Example:

1. Instruction 1

Reaction to instruction 1

2. Instruction 2

1.1.3.2 Alternative instructions

Alternative instructions are introduced with the word

"or".

CMS-T-00000473-B.1

CMS-T-005217-B.1

CMS-T-005678-B.1

CMS-T-00000110-B.1

1 | About this operating manual

Diagrams

MG6806-EN-GB | Q.1 | 26.07.2022 | © AMAZONE

Example:

1. Instruction 1

Alternative instruction

2. Instruction 2

Instructions with only one action

Instructions with only one action are not numbered,

but rather shown with a arrow.

Example:

Instruction

Instructions without sequence

Instructions that do not require a specific sequence

are shown as a list with arrows.

Example:

Instruction

1.1.4 Lists

Lists without an essential order are shown as a list

with bullets.

Example:

Point 1

Point 2

1.1.5 Item numbers in figures

A framed number in the text, e.g. a

, indicates an

item number in an adjacent figure.

CMS-T-005211-C.1

CMS-T-005214-C.1

CMS-T-000024-A.1

CMS-T-000023-B.1

1 | About this operating manual

Diagrams

MG6806-EN-GB | Q.1 | 26.07.2022 | © AMAZONE 3

1.2 Other applicable documents

A list of other applicable documents can be found in

the Appendix.

1.3 Your opinion is important

Dear reader, our operating manuals are updated

regularly. Your suggestions for improvement help us

to create ever more user-friendly operating manuals.

Please send us your suggestions by post, fax or

email.

Fax: +49 (0) 5405 501-234

Postfach 51

AMAZONEN-WERKE H. Dreyer SE & Co. KG

Technische Redaktion

D-49202 Hasbergen

E-Mail: [email protected]

CMS-T-00000616-B.1

CMS-T-000059-C.1

1 | About this operating manual

Other applicable documents

MG6806-EN-GB | Q.1 | 26.07.2022 | © AMAZONE

Safety and responsibility 2

2.1 Basic safety instructions

2.1.1 Meaning of the operating manual

Observe the operating manual

The operating manual is an important document and a part of the implement. It is intended for the user and

contains safety-related information. Only the instructions provided in the operating manual are reliable. If

the operating manual is not observed, it can result in serious injury or death.

The safety section must be completely read and observed before initial operation of the implement.

Before starting work, also read and observe each section of the operating manual.

Keep the operating manual in a safe place.

Keep the operating manual available.

Hand over the operating manual to the subsequent user.

2.1.2 Safe operating organisation

2.1.2.1 Personnel qualification

2.1.2.1.1 Requirements for all persons working with the machine

If the machine is used improperly, people can

be injured or killed. To prevent accidents due

to improper use, every person who works with

CMS-T-00002298-K.1

CMS-T-00002301-K.1

CMS-T-00006180-A.1

CMS-T-00002302-C.1

CMS-T-00002306-A.1

CMS-T-00002310-A.1

2 | Safety and responsibility

MG6806-EN-GB | Q.1 | 26.07.2022 | © AMAZONE 5

the machine must meet the following minimum

requirements:

The person is physically and mentally capable of

controlling the machine.

The person can safely perform work with the

machine within the scope of this operating

manual.

The person understands the functioning of the

machine within the scope of their work and can

recognise and prevent dangers arising during

operation.

The person head understood the operating

manual and can implement the information that is

conveyed in the operating manual.

The person must be familiar with safe driving of

vehicles.

For road travel, the person knows the relevant

road traffic regulations and has the prescribed

driving permit.

2.1.2.1.2 Qualification levels

For working with the machine, the following

qualification levels are provided:

Farmer

Agricultural helper

As a matter of principle, the activities described in this

operating manual can be performed by persons with

the qualification level "Agricultural helper".

2.1.2.1.3 Farmer

Farmers use agricultural implement to cultivate fields.

They decide on the use of an implement for a specific

purpose.

Farmers are basically familiar with working with

agricultural implements and can instruct agricultural

helpers in how to use the implements if necessary.

They can perform odd tasks and simple maintenance

and repair work on agricultural implements

themselves.

CMS-T-00002311-A.1

CMS-T-00002312-A.1

2 | Safety and responsibility

Basic safety instructions

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Amazone Timone

Amazone

Amazone KG 4001-2 Manuale utente

Amazone

Amazone Cobra 6000-2TX Istruzioni per l'installazione

Amazone

Amazone Catros 3002-T Manuale utente

Amazone

Amazone Cenius 3002-T Manuale utente

Amazone

Amazone Centaur 4001-2 Series Manuale utente

Amazone

Amazone KG 6002-2 Istruzioni per l'installazione

Amazone

Amazone Limiter X Manuale utente

Amazone

Amazone Cenius 4003-2T Special Manuale utente

Amazone

Amazone Catros 12003-2TS Manuale utente

Amazone

Amazone CatrosXL 4003-2 Manuale utente

Amazone

Amazone Catros 4002-2TS Manuale utente

Amazone

Amazone KE 3 Manuale utente

Amazone

Amazone Cenius 3001 special Manuale utente

Amazone

Amazone CatrosXL 3003 Manuale utente

Amazone

Amazone Ceus 4000-2TX Manuale utente

Amazone

Amazone Catros 3001 Manuale utente

Amazone

Amazone KG 4002-2 Guida rapida

Amazone

Amazone Catros 4001-2TS Manuale utente

Amazone

Amazone Cenius 4002-2 Super Manuale utente

Amazone

Amazone Cenius 4003-2TX Manuale utente

Manuali Timone popolari di altre marche

MTD

MTD 410R Manuale utente

Craftsman

Craftsman 247.29931 Manuale utente

MTD

MTD FRT Series Manuale utente

Craftsman

Craftsman 917.298353 Manuale utente

Troy-Bilt

Troy-Bilt Colt FT Manuale utente

Ryobi

Ryobi 510r Manuale utente

MTD

MTD OHV Series Manuale utente

YAT

YAT YT5601-01 Manuale di manutenzione

Craftsman

Craftsman 917.296010 Manuale utente

Troy-Bilt

Troy-Bilt OEM-290-260 Manuale utente

Scheppach

Scheppach MTP560 Istruzioni per il montaggio

GARDEN WAY

GARDEN WAY 12194 Manuale utente

Classen

Classen STAND-AER SA-25 Istruzioni di installazione e manutenzione

Craftsman

Craftsman 850 Series Manuale utente

DR PILOT 2 Guida rapida

Altrad

Altrad ATIKA BH 1400 N Guida

WIL-RICH

WIL-RICH 2500 Manuale utente

Viking

Viking HB 685 Manuale utente
