American DJ Verti-Pro Manuale utente

SPECIFICATIONS: MODEL -Verti-Pro™

Weight: 8 lbs.

Size: 14"H x 12"W

Lamp: 120V 300W

Fuse: 7A

Supply Voltage: 120V

Working Position: Any Safe position

Duty Cycle: 10 min. ON, 10 min. OFF

Colors: Multiple Colored

Optional: ZB-ADJ300 120V 300W 150 hr. Long Life lamp

also available

American DJ®

CAUTION!

Read instructions before

installing or plugging

unit in.

OPERATING INSTRUCTIONS:

Unit is ready to be hung or set on flat surface. Unit will react to bass sound of music via its internal microphone, and not

lightly tapping on the case. Adjust the sensitivity knob on the unit to music sensitivity. Unit will Master/ Slave by setting dip

switch on back of unit and connecting via XLR Cables. All Dip switches off is Master, #1 on is for Slave. These settings must

be done before plugging in to power because dip switch settings can not change once unit is on. If no sound is detected

by unit for 3 seconds lights will turn off. Be sure sensitivity is up, do not to obstruct cooling vents and keep in a well ventilated

area. For best results, fog or special effects smoke must be used in order to see the beams of light.

The 1/4” phone plug on the control is not for audio input, it is for a blackout control, if you connect audio into this it will

burnout the circuit board.

CAUTION: Front part of fixture will get extremely hot if operated for long periods. For optimum performance, use a 10 min

ON 10 min OFF duty cycle. Let unit cool before handling or replacement. Caution! Never open unit when in use. Always dis-

connect main power before serving or replacing lamp. Remember always replace same lamp and fuses.

Lamp replacement: Remove top cover of unit. Remove and replace lamps with the same wattage and

voltage.

For service contact your American DJ Dealer.

HALOGEN LAMP WARNING!

This fixture is fitted with halogen

lamps which are highly susceptible

to damage if improperly handled.

Never touch lamp with bare fingers

as the oil from your hands will

shorten lamp life. Also, never move

fixture until lamp has had ample

time to cool. Remember, lamps are

not covered under warranty

conditions.

Built in programs

Master slave

capabilities

VERTI-Pro

™

User Instructions

Affordable Quality Lighting Products from American DJ® Los Angeles, CA. 90058 USA
