American Dynamics 61

IP Video Encoders

IP Encoders allow you to

transform analog video into high

quality IP video streams.

American Dynamics 62

IP ENCODERS COMPARISON TABLE

8-Channel 4-Channel

Number of channels Eight composite video inputs Four composite video inputs

Resolution D1, 2CIF, CIF

Via Intellex IP:

704 x 480, 704 x 240, 352 x 240

Via Browser:

See list above; also

640 x 480, 640 x 240, 320 x 240

Compression (Model) H.264 (ADEIP8H)

MPEG-4, MJPEG (ADEIP8M) Active Content Compression (ACC)

Frame Rate 1-30 ips on each channel + dual encode 4CIF NTSC up to 30 ips per channel

Connector type Eight BNC Four BNC

Network Interface Ethernet 10/100/1000 Base-T Ethernet 10/100 Base-T

Supported Recording Devices VideoEdge NVR, Intellex IP, HDVR HTTP, TCP, DHCP, (client)

Supported Protocols RTP, RTSP, HTTP, UDP, TCP/IP HTTP, TCP, DHCP (client)

Supported Camera Protocols

American Dynamics RS422

BBV Star Card

Cyberscan1

Pelco D

Pelco P

Phillips TC7560

RS422 Dome

American Dynamics

Pelco P

Pelco D,

Bosch,

BBV Star Card

Dimensions 141 x 439.5 x 43.6 mm

(5.55 x 17.3 x 1.71 in)

221 x 113 x 43 mm

(8.7 x 4.4 x 1.7 in)

Weight 2.4 kg (5.3 lbs) 0.6 kg (1.3 lb)

Operating Temperature 0°C - 50°C (32°F -122°F) 0° to 50°C (32° to 122°F)

Certifications UL, FCC, CE

USA: FCC part 15 Class A

Canada: ICES-003/NMB-003 Class A

Europe: EN55022 Class A, EN50130-4

Australia/New Zealand: AS/NZS CISPR22

UL: UL60950-1, CSA C22.2 No. 60950-1

TUVGS: EN60950-1

CB: IEC60950-1

Encoders

American Dynamics 63

Preserve your investment in

Sensornet with our add-on

USB module.

8-Channel:

t Video streaming over IP network

t Supports two-way audio to enable

audio streaming applications

t Easy-to-use built-in web interface

lets you control all aspects of video

encoding

t A wide range of PTZ camera

protocols is supported and an

open API is included for application

integration and future support of

other formats

t 8 analog video sources

t 1U 19 in rack mount

t H.264 and MPEG-4/MJPEG models

available

t 30 ips on every channel at D1

t Dual streaming

t Built-in de-interlacing

t Gigabit Ethernet

t 8 audio in/out

t RS232 + RS422/485 for PTZ control

t Compatible with VideoEdge NVR

MODEL NUMBERS

ADEIP8M

MPEG-4, MJPEG

ADEIP8H-US

H.264

SNETH-US

Add on USB module to enable

Sensornet (for ADEIPH only)

IP Encoders

American Dynamics 64

Preserving Your Camera

Investment

Keep your analog cameras as you

migrate to an IP solution. Easily

transform analog video into high quality

IP video streams.

4-Channel:

t Developed to leverage Active

Content Compression (ACC)

technology

t Power over Ethernet

t Manage network bandwidth

usage through individual stream

configuration

t Compatible with Intellex IP and the

Intellex Management Suite (Network

Client, Intellex Policy Manager,

Intellex Archive Manager, and

Browser Client)

t 30 ips NTSC/25 ips PAL at 4CIF

t Access and control the IP encoder

from a web browser or Intellex IP

user interface

t Watchdog system monitoring with

auto-reset

t Video loss detection

t Camera PTZ, focus, aperture

adjustment, preset, and pattern

controls for selected cameras

t Text stream input

t Multi-level password protected user

access

t 10Base-T/100Base-TX network

support

t 1U form factor for shelf, wall, or rack

mounting

MODEL NUMBERS

ADEIP4

4-Channel IP encoder

ADEIP4PS

4-Channel IP encoder with power supply

Accessories

ADEIP4RM

Rack mount kit

ADEIP4WM

Wall mount kit

ADEIP4PWRS

12V DC Power supply kit

ADEIP4RS232

RS-232 Cable Adapter

IP Encoders
