FEATURES

Rendering bright images in stunning detail,

American Dynamics plasma monitors are the

perfect choice for video security and public

display. At less than four inches deep, they

install easily on any wall and require minimal

space.

These large screens yield bigger images from

quads, multiplexers and digital video recorders

(DVRs), making it easier to closely observe

footage from multiple cameras simultaneously.

Use the Digital Video Interface (DVI) input to

feed video from advanced DVRs such as an

Intellex Digital Video Management System for

pictures with unmatched clarity.

Each plasma monitor features a 16:9 aspect

ratio, auto pixel rotation and multiple inputs.

Choose from High Definition (HD) and

Enhanced Definition (ED) resolution models

for color-rich video with wide viewing angles.

Mounting options include a ceiling mount, a

wall flush-mount and a wall mount with

articulating arms.

Due to the size of the monitors and the

limitations of plasma technology, these

monitors offer a 12-month on-site warranty

with toll free support 1-800-827-2850 (ext. 216).

Unlike LCD or CRT displays, all plasma

monitors have shorter lifetimes and are sensitive

to high elevations (typically above 7,000 feet).

Plasma Monitors

42, 46 & 50-INCH

•Large format displays

•High image detail

•Excellent video quality

•Brilliant colors

•High resolutions (HD and

ED)

•Larger multi-screen

images

•High (800:1) contrast

ratio

•Bright (300+ cd/m)

screens

•Picture in Picture (PIP)

viewing flexibility

•Digital Video Interface

(DVI) for Intellex and

other advanced DVRs

•Adjustable image shift

controls prevent screen

burn-in

•Switchable wide-screen

16:9 to 4:3 format

•Auto image scaling and

wide 160+º viewing angles

•Shallow profile (less than

4”)

•Desktop base included

•Analog PC input

•D-Sub 15 pin or digital PC

(DVI) input

•S-Video and RCA

composite video inputs

•Looping BNC composite

output (46” model only)

•Remote control included

•Amplified outputs for

optional external speakers

•On-screen display in 9

languages

•Optional wall flush-

mount or wall mount

with swing-arm

•Optional TV tuner

www.americandynamics.net

Front side – Single sheet – Letter size – print 4/c

42 & 50- inch design

46- inch design

PlasmaMonitors_VS353.qxd 7/18/05 10:07 AM Page 1

SPECIFICATIONS

Model Numbers

ADMNPLASMA42 . . . . . . . .42-inch Plasma Monitor

ADMNPLASMA46 . . . . . . . .46-inch Plasma Monitor

ADMNPLASMA50 . . . . . . . .50-inch Plasma Monitor

Accessories

ADMMTPLASMAW . . . . . . .Wall flush mount for all models

ADMMTPLASMAP . . . . . . . .Ceiling mount (adjustable height) for all

models

Electrical

Resolution

ADMNPLASMA42 . . . . . . . .852 x 480 (WVGA)

ADMNPLASMA46 . . . . . . . .852 x 480 (WVGA)

ADMNPLASMA50 . . . . . . . .1366 x 768 (WXGA)

Brightness

ADMNPLASMA42 . . . . . . . .375 (cd/m) (w/o filter: 750)

ADMNPLASMA46 . . . . . . . .300 (cd/m) (w/o filter: 700)

ADMNPLASMA50 . . . . . . . .400 (cd/m)

Power Consumption

ADMNPLASMA42 . . . . . . . .AC 100-240V, 50-60Hz, 340 watts

ADMNPLASMA46 . . . . . . . .AC 100-240V, 50-60Hz, 330 watts

ADMNPLASMA50 . . . . . . . .AC 100-240V, 50-60Hz, 370 watts

Viewing Angle . . . . . . . . . . . . . .Over +/- 160º

Mechanical

Dimensions (H x W x D)

ADMNPLASMA42 . . . . . . . .640 x 1033 x 82 mm

(22.5 x 40.6 x 3.2 in)

ADMNPLASMA46 . . . . . . . .686 x 1134 x 98 mm

(27.0 x 44.6 x 3.8 in)

ADMNPLASMA50 . . . . . . . .843 x 1282 x 99 mm

(33.2 x 50.5 x 3.9 in)

Unit Weight

ADMNPLASMA42 . . . . . . . .37.8 kg (83.0 lbs)

ADMNPLASMA46 . . . . . . . .42.0 kg (92.0 lbs)

ADMNPLASMA50 . . . . . . . .52.3 kg (115.0 lbs)

Shipping Information

Dimensions (H x W x D)

ADMNPLASMA42 . . . . . . . .762 x 1194 x 165 mm

(30.0 x 47.0 x 6.5 in)

ADMNPLASMA46 . . . . . . . .940 x 1296 x 216 mm

(37.0 x 51.0 x 8.5 in)

ADMNPLASMA50 . . . . . . . .1067 x 1473 x 229 mm

(42.0 x 58.0 x 9.0 in)

Unit Weight

ADMNPLASMA42 . . . . . . . .41.4 kg (91.0 lbs)

ADMNPLASMA46 . . . . . . . .46.4 kg 102.0 lbs)

ADMNPLASMA50 . . . . . . . .57.8 kg (127.0 lbs)

Inputs/Outputs

One each: PC (D-Sub 15 pin), DVI, S-Video (SVHS), RCA video and audio,

Component video

Regulatory

Emissions . . . . . . . . . . . . . . . . . .FCC: Part 15, Class B

SubPart B: 2002

ICES-003

Safety . . . . . . . . . . . . . . . . . . . . . .UL60950

CSA C22.2

AD PLASMA MONITORS 42, 46 & 50-INCH

Product specifications and availability subject to

change without notice.

Certain product names mentioned herein may be trade

names and/or registered trademarks of other companies.

VS353-03 07/05 L

Back side – Single sheet – Letter size – print b/w

Warranty Support Procedure:

Please call the manufacturer’s toll free number: 1-800-827-2850, extension 216. Also, an additional 12 month warranty extension is available from the manufacturer, at this number.

PlasmaMonitors_VS353.qxd 7/18/05 10:07 AM Page 2
