Ameriwood HOME 5318500EBL Manuale utente

5318500EBL

4DrawerDresser



‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B345318500EBL1

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

ABC

GF H

LeftPanel

35318341010

RightPanel

35318341020

Bottom

35318341041

Top

35318337031

RearMolding

35318341081

RightFrontMolding

35318341070

LeftFrontMolding

35318341060

Support

35318000050

DrawerFront

35318341091

DrawerBottom

K531833160

DrawerSide

39991167346200C

DWR

BOTTOM

DWR

SIDE

5

ameriwoodhome.com

BoardIdentification

Notactualsize

Thispieceispaperboard

construction.Itisnotmade

fromwood,butisrequiredfor

theassemblyofyourunit.

DrawerBack

39991167063390B

BackPanel

K531800001

Drawersidesanddrawerbacksare

labeledwithpartdescription.

DWR

BACK

DWR

BACK

DWR

SIDE

DWR

SIDE

DWR

BOTTOM

BACK

PANEL

BACK

PANEL

6

ameriwoodhome.com

PartList

ActualSize

NotActualSize

(x6)

#A22620

camlock

(x6)

#A22610

cambolt

(x6)

#A22900

connector

(x6)

#A22910

connector bolt

(x4)

#A21660

wood dowel (x4)

#A23030

confirmatscrew

(x40)

#A11080

7/16"flathead

(x40)

#A12120

7/16"panhead

(x28)

#A21110

nail

(x14)

#A12930

1‐1/8"panhead

(x16)

#A21970

drivefastener

(x8)

#A17030

5/16"bolt

13d

13c

13b

13a

LeftCabinetMember

RightCabinetMember

LeftDrawerMember

RightDrawerMember

(x4)

#A56770

DrawerSlideKit

14b

14a 14c

14d

(x1)

#A84050

SafetyBracketKit

(x8)

#A54520

DrawerBracket

(x4)

#A50408

handle

(x4)

#A44420

foot

456

789

11 12

15 16

Note that your unit may contain extra hardware

(x4)

#A54900

drawer brace

7

ameriwoodhome.com

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x2)

#A22620

(x1)

#A22610

(x3)

#A22900

(x1)

#A21660

Youwillneedtotaptheconnector

(3)withahammertofullyinsert.

Besuretheconnectorispositioned

asshownbeforepushingintohole.

8

ameriwoodhome.com

STEP2

Marked with a "L".

Attachfourleftcabinetmembers(13a)totheleftpanel(A)withscrews(7)asshown.

(x4)

#A56770

LeftCabinetMember

(x12)

#A11080

13a

9

ameriwoodhome.com

STEP3

(x3)

#A12930

Attachtherearmolding(H)totheleftpanel(A)withthreescrews(9)asshown.

Note: You will screw into the groove of the rear molding (H).

Besurethetopedgeoftheleftpanel(A)and

rearmolding(H)areflushwitheachother.

10

ameriwoodhome.com

STEP4

Proper orientation of CAM LOCK

Tip

Assembly

Quick

235

(x2)

#A22620

(x1)

#A22610

(x3)

#A22900

(x1)

#A21660

Youwillneedtotaptheconnector

(3)withahammertofullyinsert.

Besuretheconnectorispositioned

asshownbeforepushingintohole.
