Amica 60311 Manuale utente

IO-HOO-0790

(06.2019)

Kitchen extractor hood / kaminhaube /

kuchyňského odsavače / kuchynského odsávača

/ Hotte aspirante / Afzuigkap / Kuhinjska napa /

Kuhinjska napa

60311 / 60301

OPERATING INSTRUCTIONS EN

GEBRAUCHSANWEISUNG DE

NÁVOD K OBSLUZE CS

NÁVOD NA OBSLUHU SK

NOTICE D’UTILISATION FR

GEBRUIKSAANWIJZING NL

UPUTE ZA UPORABU HR

NAVODILA ZA UPORABO SL

- 2 -

NOTES ON SAFETY 6

UNPACKING 9

DISPOSAL OF OLD APPLIANCE 9

OPERATION 10

KITCHEN HOOD CONTROLS 10

OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 11

CLEANING AND MAINTENANCE 12

MAINTENANCE 12

GREASE FILTER 12

ACTIVATED CHARCOAL FILTER 12

LIGHT 12

WARRANTY AND AFTER SALES SERVICE 13

WARRANTY 13

SICHERHEITSHINWEISE 15

AUSPACKEN 19

ENTSORGUNG VON ALTGERÄTEN 19

BEDIENUNG 20

STEUERUNG DER DUNSTABZUGSHAUBE 20

ANDERE WICHTIGE INFORMATIONEN ZUR BEDIENUNG DER DUNSTABZUGSHAUBE 21

REINIGUNG UND WARTUNG 21

WARTUNG 21

FETTFILTER 22

AKTIVKOHLEFILTER 22

BELEUCHTUNG 22

GARANTIE, NACHVERKAUF-SERVICE 23

GARANTIE 23

EN- Table of contents

DE- Inhaltsverzeichnis

BEZPEČNOSTNÍ POKYNY 25

VYBALENÍ 28

LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 28

OBSLUHA 29

OVLÁDÁNÍ ODSAVAČE 29

JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 30

ČIŠTĚNÍ A ÚDRŽBA 31

ÚDRŽBA 31

PROTITUKOVÝ FILTR 31

UHLÍKOVÝ FILTR 31

OSVĚTLENÍ 31

ZÁRUKA, POPRODEJNÍ SERVIS 32

ZÁRUKA 32

CS- Obsah

- 3 -

BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 34

ROZBALENIE 38

LIKVIDÁCIA ZARIADENÍ 38

OBSLUHA 39

OVLÁDANIE ODSÁVAČA 39

INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 40

ČISTENIE A ÚDRŽBA 41

KONZERVÁCIA 41

PROTITUKOVÝ FILTER 41

UHLÍKOVÝ FILTER 41

OSVETLENIE 41

ZÁRUKA, POPREDAJNÝ SERVIS 42

ZÁRUKA 42

INDICATIONS CONCERNANT LA SÉCURITÉ D'UTILISATION 44

DÉBALLAGE 48

ÉLIMINATION DES APPAREILS USAGÉS 48

UTILISATION 49

COMMANDE DE LA HOTTE 49

AUTRES INFORMATIONS IMPORTANTES RELATIVES À L’UTILISATION DE LA HOTTE 50

NETTOYAGE ET ENTRETIEN 51

ENTRETIEN 51

FILTRE À GRAISSE 51

FILTRE À CHARBON 51

ÉCLAIRAGE 51

GARANTIE, SERVICE APRÈS-VENTE 52

GARANTIE 52

AANWIJZINGEN VOOR VEILIG GEBRUIK 54

UITPAKKEN 58

VERWIJDERING VAN GEBRUIKTE APPARATUUR 58

BEDIENING 59

BEDIENING VAN DE AFZUIGKAP 59

ANDERE BELANGRIJK INFORMATIE OVER DE BEDIENING VAN DE AFZUIGKAP 60

REINIGING EN ONDERHOUD 61

ONDERHOUD 61

ANTIVETFILTER 61

ACTIEVE KOOLFILTER 61

VERLICHTING 61

GARANTIE, SERVICE 62

GARANTIE 62

SK- Obsah

FR- Table des matières

NL- Inhoudsopgave

- 4 -

HR- Kazalo

SL- Sadržaj

SIGURNOSNE NAPOMENE 64

UKLANJANJE PAKIRANJA 67

ZBRINJAVANJE POTROŠENIH UREĐAJA 67

UPORABA 68

UPRAVLJANJE NAPOM 68

OSTALE VAŽNE INFORMACIJE O UPORABI NAPE 69

ČIŠĆENJE I ODRŽAVANJE 70

ODRŽAVANJE 70

FILTER PROTIV MASNOĆE 70

UGLJENI FILTER 70

RASVJETA 70

JAMSTVO, POSLIJEPRODAJNE AKTIVNOSTI 71

JAMSTVO 71

NAVODILA ZA ZAGOTAVLJANJE VARNOSTI UPORABE 73

RAZPAKIRANJE 76

ODSTRANJEVANJE IZRABLJENIH NAPRAV 76

UPORABA 77

UPRAVLJANJE S KUHINJSKO NAPO 77

DRUGE POMEMBNE INFORMACIJE GLEDE NAVODIL ZA UPORABO NAPE 78

ČIŠČENJE IN VZDRŽEVANJE 79

VZDRŽEVANJE 79

MAŠČOBNI FILTER 79

OGLENI FILTER 79

OSVETLITEV 79

GARANCIJA, POPRODAJNE STORITVE 80

GARANCIJA 80

- 5 -

Dear customer,

From now on, your daily housework will be easier

than ever before. Your appliance is excepon-

ally easy to use and extremely ecient. Aer reading

these Operang Instrucons, operang the appliance

will be easy.

Before being packaged and leaving the manufacturer,

the appliance was thoroughly checked with regard to

safety and funconality.

Before using the appliance, please carefully read

these Operang Instrucons. By following these

instrucons carefully you will be able to avoid any

problems in using the appliance. It is important to

keep these Operang Instrucons and store them in a

safe place so that they can be consulted at any me.

Follow these instrucons carefully in order to avoid

possible accidents.

Sincerely,

- 6 -

NOTES ON SAFETY

• Before using the appliance, please carefully read

this manual!

• The appliance is designed for household use only.

• The manufacturer reserves the right to introduce

changes, which do not aect operation of the ap-

pliance.

• The manufacturer shall not be liable for any dam-

age or re caused by the appliance resulting from

failure to follow instructions in this manual.

• Cooker hood is designed to remove cooking

odours. Do not use cooker hood for other pur-

poses.

• Connect the cooker hood operating in extraction

mode to a suitable ventilation duct (do NOT con-

nect the cooker to smoke or ue gas ducts, which

are in use). It requires installation of the air ex-

traction duct to the outside. The length of the

duct (usually a pipe of Ø 120 or 150 mm) should

not be longer than 4-5 m. An air extraction duct

is also required for telescopic and furniture hoods

in absorption mode.

• Cooker hood operating in air recirculation mode

requires the installation of an activated charcoal

lter. In this case, installing an extractor duct is

not required, however it is recommended to in-

stall an air guide vane (Mainly in chimney cooker

hoods).

• The cooker hood features independent lighting

and exhaust fan that can be operated at one of

several speeds.

• Depending on the type, the hood is designed to

be permanently attached to a vertical wall over

a gas or electric stove (chimney and universal

hoods); on the ceiling over a gas or electric stove

(island hoods); on the vertical built in furniture

over a gas or electric stove (telescopic and built-

in hoods). Before installing, make sure that the

- 7 -

wall/ceiling structure is strong enough to suspend

the hood. Some hoods are very heavy.

• For details of the installation distance above an

electric hob please refer to product technical

sheet If the installation instructions of the gas

cooker specify a greater distance, this must be

taken into account (Fig. 1).

• Do not leave an open ame under the hood.

When the pots are removed from the burner, set

the minimum ame. Always make sure that the

ame does not extend outside the pot, because it

causes unwanted loss of energy and a dangerous

concentration of heat.

• When cooking on fat, supervise the pans con-

stantly, because overheated fat can ignite.

• Unplug the appliance before any cleaning, replac-

ing the lter or repair work.

• Cooker hood grease lter should be cleaned at

least once a month, because the lter saturated

with fat is ammable.

• Ensure adequate ventilation (air ow) if other

equipment such as liquid fuel stoves or heaters

are operated in the room in addition the cooker

hood. When the cooker hood is simultaneously

operated with burning appliances requiring ade-

quate fresh air from the room to work properly,

their safe operation is possible if under pressure

around these appliances is a maximum of 0.004

mbar (this does not apply when the cooker hood

is used as an odour lter)

• Do not lean on the hood.

• The hood should be cleaned regularly both inside

and out (AT LEAST ONCE A MONTH, following the

indications concerning maintenance provided in

this manual)..Failure to adhere to the rules con-

cerning cleaning the hood and replacing lters

results in a re risk.

• If the power cord is damaged it should be re-

placed by a specialised service centre.

• Ensure that it is possible to disconnect the ap-

- 8 -

pliance from the mains by removing the plug or

switching o the bi-polar switch.

• This appliance is not intended for use by persons

(including children) with physical, mental or sen-

sory handicaps, or by persons inexperienced or

unfamiliar with the appliance, unless under su-

pervision or in accordance with the instructions

as communicated to them by persons responsible

for their safety.

• Particular attention should be paid not to allow

unaccompanied children to use the appliance.

• Make sure voltage indicated on the nameplate

corresponds to the local mains supply voltage.

• Before use, extend and straighten the power cord.

• Packaging materials (bags, polyethylene, poly-

styrene, etc.) should be kept away from children

during unpacking.

• Before connecting the hood to the mains power

supply always check that the power cord is prop-

erly installed and is not trapped by the appliance.

Do not connect the appliance to the mains until

assembly is complete.

• Do not operate your kitchen hood without the al-

uminium grease lters.

• It is strictly forbidden to cook dishes under on an

open ame (ambé) under your kitchen hood.

• Always strictly adhere to regulations issued by the

competent local authorities regarding the techni-

cal and safety requirements for fume extraction.

• Failing to tighten bolts and fasteners in accord-

ance with these instructions may endanger life

and health.

• Hanging kitchen hoods operate only in air circu-

lation / odour absorber mode

• WARNING! Failure to install the screws or xing

device in accordance with these instructions may

result in electrical hazards.

- 9 -

UNPACKING

During transportation, protective

packaging was used to protect the

appliance against any damage. Af-

ter unpacking, please dispose of all

elements of packaging in a way that

will not cause damage to the environ-

ment.

All materials used for packaging the

appliance are environmentally friendly; they are

100% recyclable and are marked with the appropri-

ate symbol.

Important! Packaging materials (bags, polyethyl-

ene, polystyrene, etc.) should be kept away from

children during unpacking.

DISPOSAL OF OLD APPLIANCE

In accordance with European Directive

2012/19/EU and local legislation re-

garding used electrical and electronic

goods, this appliance is marked with

the symbol of the crossed-out waste

container. This marking indicates that

the appliance must not be disposed of

together with other household waste

after it has been used.

The user is obliged to hand it over to waste collec-

tion centre collecting used electrical and electron-

ic goods. The collectors, including local collection

points, shops and local authority departments pro-

vide recycling schemes.

Proper handling of used electrical and electronic

goods helps avoid environmental and health haz-

ards resulting from the presence of dangerous com-

ponents and the inappropriate storage and process-

ing of such goods.

- 10 -

OPERATION

Kitchen hood controls

Control Panel is shown in Figure 4, for reference it is also shown below:

The control panel is equipped with buttons (isostat switch).

To turn on the kitchen hood, press one of the button to select the de-

sired speed:

1- Low speed. Use this speed when cooking a little food with hardly any

fumes.

2- Medium speed. Use this speed when cooking multiple dishes at the

same time with moderate amount of fumes.

3- High speed. Use this speed when frying or grilling, with large

amount of fumes.

4- Turn o the appliance

Press to turn the lighting on/o. The lighting operates independently

of hood fan.

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Amica Cappa di ventilazione

Amica

Amica KHF 666 600 S Manuale utente

Amica

Amica OKS6543S Manuale utente

Amica

Amica KH17390S Manuale utente

Amica

Amica OMP6241BI Manuale utente

Amica

Amica OKP9321GUK Series Manuale utente

Amica

Amica SKZ 62BB Manuale utente

Amica

Amica OWC 952 G Manuale utente

Amica

Amica OTP6241I Manuale utente

Amica

Amica KH 17402 S Manuale utente

Amica

Amica AEP60BL Manuale utente

Amica

Amica OKC IN 900 BT Manuale utente

Amica

Amica KH 17119 E Manuale utente

Amica

Amica OKP6321T Manuale utente

Amica

Amica KH 17128-3 E Manuale utente

Amica

Amica IH 17025 E Manuale utente

Amica

Amica BK313.3 Manuale utente

Amica

Amica OTS 645 IOTS 625 IOTS 625 WOTS 615 IOTS 615 WOTS 515 IOTS 515 WOTS 635 IOTS 935 IFH 17231 EOTS 6425 IOTS 6521... Manuale utente

Amica

Amica KH 17196 E Manuale utente

Amica

Amica KH 17390-2 S Manuale utente

Amica

Amica OKC954S Manuale utente

Amica

Amica OKC6751TB HC Manuale utente

Amica

Amica OWC4241 Series Manuale utente

Amica

Amica OSC6212B Manuale utente

Amica

Amica AH5014 Manuale utente

Manuali Cappa di ventilazione popolari di altre marche

emmeti

emmeti RECUPA MED A-140 Guida

Nibe

Nibe F135 Manuale utente

Kuppersberg

Kuppersberg INTRO 60 Istruzioni di installazione e manutenzione

Zephyr

Zephyr Spruce AK9834BS Guida all'installazione

Hisense

Hisense MH6INBG Manuale utente

Miele

Miele DA 1255 Manuale utente

Broan

Broan 46000 Manuale utente

GE Profile PV977 Istruzioni originali

FALMEC

FALMEC FFRIA24W5FS Manuale utente

Whirlpool

Whirlpool RH2600XL-1 SERIES Manuale utente

Küppersbusch

Küppersbusch DX ISLA Manuale utente

ETNA

ETNA AV360RVS Manuale utente

JUNO

JUNO JDF603E6 Manuale utente

Miele

Miele DA 6708 D Manuale utente

Tricity Bendix

Tricity Bendix LE 150 Manuale

AEG

AEG X68163BV1 Manuale utente

AEG

AEG 125 D Manuale utente

Smeg

Smeg KSEV97X Manuale utente
