Amica KH 17179 E Manuale utente
IO-HOO-0236/1
(12.2019)
Kitchen extractor hood / kaminhaube /
kuchyňského odsavače / kuchynského odsávača
/ Hotte aspirante / Afzuigkap / Kuhinjska napa /
Kuhinjska napa
KH 17179 E / KH 17178 E /
KHF 683 600 Gy
OPERATING INSTRUCTIONS EN
GEBRAUCHSANWEISUNG DE
NÁVOD K OBSLUZE CS
NÁVOD NA OBSLUHU SK
NOTICE D’UTILISATION FR
GEBRUIKSAANWIJZING NL
UPUTE ZA UPORABU HR
NAVODILA ZA UPORABO SL
- 3 -
NOTES ON SAFETY 7
UNPACKING 10
DISPOSAL OF OLD APPLIANCE 10
OPERATION 11
COOKER HOOD CONTROLS 11
CONTROL PANEL 11
OFF TIMER 11
CHILD LOCK 11
OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 12
CLEANING AND MAINTENANCE 13
MAINTENANCE 13
GREASE FILTER 13
ACTIVATED CHARCOAL FILTER 13
LIGHT 13
WARRANTY AND AFTER SALES SERVICE 14
WARRANTY 14
SICHERHEITSHINWEISE 16
AUSPACKEN 20
ENTSORGUNG VON ALTGERÄTEN 20
BEDIENUNG 21
STEUERUNG DER DUNSTABZUGSHAUBE 21
BEDIENFELD 21
TIMER (AUSSCHALTVERZÖGERUNG) 21
CHILD LOCK (KINDERSICHERUNG) 21
ANDERE WICHTIGE INFORMATIONEN ZUR BEDIENUNG DER DUNSTABZUGSHAUBE 22
REINIGUNG UND WARTUNG 22
WARTUNG 22
FETTFILTER 23
AKTIVKOHLEFILTER 23
BELEUCHTUNG 23
GARANTIE, NACHVERKAUF-SERVICE 24
GARANTIE 24
EN- Table of contents
DE- Inhaltsverzeichnis
BEZPEČNOSTNÍ POKYNY 26
VYBALENÍ 29
LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 29
OBSLUHA 30
OVLÁDÁNÍ ODSAVAČE 30
OVLÁDACÍ PANEL 30
ČASOVAČ (OPOŽDĚNÉ VYPNUTÍ MOTORU ODSAVAČE) 30
CHILD LOCK (RODIČOVSKÁ POJISTKA) 30
JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 31
ČIŠTĚNÍ A ÚDRŽBA 32
ÚDRŽBA 32
PROTITUKOVÝ FILTR 32
UHLÍKOVÝ FILTR 32
OSVĚTLENÍ 32
ZÁRUKA, POPRODEJNÍ SERVIS 33
ZÁRUKA 33
CS- Obsah
- 4 -
BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 35
ROZBALENIE 39
LIKVIDÁCIA ZARIADENÍ 39
OBSLUHA 40
OVLÁDANIE ODSÁVAČA 40
OVLÁDACÍ PANEL 40
ČASOVAČ (ONESKORENÉ VYPNUTIE MOTORA ODSÁVAČA) 40
DETSKÁ ZÁMKA (ANGL. CHILD LOCK) 40
INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 41
ČISTENIE A ÚDRŽBA 42
KONZERVÁCIA 42
PROTITUKOVÝ FILTER 42
UHLÍKOVÝ FILTER 42
OSVETLENIE 42
ZÁRUKA, POPREDAJNÝ SERVIS 43
ZÁRUKA 43
INDICATIONS CONCERNANT LA SÉCURITÉ D'UTILISATION 45
DÉBALLAGE 49
ÉLIMINATION DES APPAREILS USAGÉS 49
EXPLOITATION 50
COMMANDE DE LA HOTTE 50
PANNEAU DE COMMANDE 50
TIMER (ARRÊT DIFFÉRÉ DU VENTILATEUR DE LA HOTTE) 50
CHILD LOCK (VERROUILLAGE PARENTAL) 50
AUTRES INFORMATIONS IMPORTANTES RELATIVES À L’UTILISATION DE LA HOTTE 51
NETTOYAGE ET ENTRETIEN 52
ENTRETIEN 52
FILTRE À GRAISSE 52
FILTRE À CHARBON 52
ÉCLAIRAGE 52
GARANTIE, SERVICE APRÈS-VENTE 53
GARANTIE 53
AANWIJZINGEN VOOR VEILIG GEBRUIK 55
UITPAKKEN 59
VERWIJDERING VAN GEBRUIKTE APPARATUUR 59
BEDIENING 60
BEDIENING VAN DE AFZUIGKAP 60
BEDIENINGSPANEEL 60
TIMER (UITGESTELDE UITSCHAKELING VAN DE MOTOR VAN DE AFZUIGKAP) 60
CHILD LOCK (KINDERSLOT) 60
ANDERE BELANGRIJK INFORMATIE OVER DE BEDIENING VAN DE AFZUIGKAP 61
REINIGING EN ONDERHOUD 62
ONDERHOUD 62
ANTIVETFILTER 62
ACTIEVE KOOLFILTER 62
VERLICHTING 62
GARANTIE, SERVICE 63
GARANTIE 63
SK- Obsah
FR- Table des matières
NL- Inhoudsopgave
- 5 -
HR- Kazalo
SL- Sadržaj
SIGURNOSNE NAPOMENE 65
UKLANJANJE PAKIRANJA 68
ZBRINJAVANJE POTROŠENIH UREĐAJA 68
UPORABA 69
UPRAVLJANJE NAPOM 69
UPRAVLJAČKA PLOČA 69
TIMER (ODGODA ISKLJUČENJA VENTILATORA NAPE) 69
CHILD LOCK (BLOKADA ZA DJECU) 69
OSTALE VAŽNE INFORMACIJE O UPORABI NAPE 70
ČIŠĆENJE I ODRŽAVANJE 71
ODRŽAVANJE 71
FILTER PROTIV MASNOĆE 71
UGLJENI FILTER 71
RASVJETA 71
JAMSTVO, POSLIJEPRODAJNE AKTIVNOSTI 72
JAMSTVO 72
NAVODILA ZA ZAGOTAVLJANJE VARNOSTI UPORABE 74
RAZPAKIRANJE 77
ODSTRANJEVANJE IZRABLJENIH NAPRAV 77
UPORABA 78
UPRAVLJANJE S KUHINJSKO NAPO 78
PANEL ZA UPRAVLJANJE 78
TIMER (ZAKASNITEV IZKLOPA HITROSTI NAPE) 78
CHILD LOCK (STARŠEVSKA BLOKADA) 78
DRUGE POMEMBNE INFORMACIJE GLEDE NAVODIL ZA UPORABO NAPE 79
ČIŠČENJE IN VZDRŽEVANJE 80
VZDRŽEVANJE 80
MAŠČOBNI FILTER 80
OGLENI FILTER 80
OSVETLITEV 80
GARANCIJA, POPRODAJNE STORITVE 81
GARANCIJA 81
- 6 -
Dear customer,
From now on, your daily housework will be easier
than ever before. Your appliance is excepon-
ally easy to use and extremely ecient. Aer reading
these Operang Instrucons, operang the appliance
will be easy.
Before being packaged and leaving the manufacturer,
the appliance was thoroughly checked with regard to
safety and funconality.
Before using the appliance, please carefully read
these Operang Instrucons. By following these
instrucons carefully you will be able to avoid any
problems in using the appliance. It is important to
keep these Operang Instrucons and store them in a
safe place so that they can be consulted at any me.
Follow these instrucons carefully in order to avoid
possible accidents.
Sincerely,
- 7 -
NOTES ON SAFETY
• Before using the appliance, please carefully read
this manual!
• The appliance is designed for household use only.
• The manufacturer reserves the right to introduce
changes, which do not aect operation of the ap-
pliance.
• The manufacturer shall not be liable for any dam-
age or re caused by the appliance resulting from
failure to follow instructions in this manual.
• Cooker hood is designed to remove cooking
odours. Do not use cooker hood for other pur-
poses.
• Connect the cooker hood operating in extraction
mode to a suitable ventilation duct (do NOT con-
nect the cooker to smoke or ue gas ducts, which
are in use). It requires installation of the air ex-
traction duct to the outside. The length of the
duct (usually a pipe of Ø 120 or 150 mm) should
not be longer than 4-5 m. An air extraction duct
is also required for telescopic and furniture hoods
in absorption mode.
• Cooker hood operating in air recirculation mode
requires the installation of an activated charcoal
lter. In this case, installing an extractor duct is
not required, however it is recommended to in-
stall an air guide vane (Mainly in chimney cooker
hoods).
• The cooker hood features independent lighting
and exhaust fan that can be operated at one of
several speeds.
• Depending on the type, the hood is designed to
be permanently attached to a vertical wall over
a gas or electric stove (chimney and universal
hoods); on the ceiling over a gas or electric stove
(island hoods); on the vertical built in furniture
over a gas or electric stove (telescopic and built-
in hoods). Before installing, make sure that the
- 8 -
wall/ceiling structure is strong enough to suspend
the hood. Some hoods are very heavy.
• For details of the installation distance above an
electric hob please refer to product technical
sheet If the installation instructions of the gas
cooker specify a greater distance, this must be
taken into account (Fig. 1).
• Do not leave an open ame under the hood.
When the pots are removed from the burner, set
the minimum ame. Always make sure that the
ame does not extend outside the pot, because it
causes unwanted loss of energy and a dangerous
concentration of heat.
• When cooking on fat, supervise the pans con-
stantly, because overheated fat can ignite.
• Unplug the appliance before any cleaning, replac-
ing the lter or repair work.
• Cooker hood grease lter should be cleaned at
least once a month, because the lter saturated
with fat is ammable.
• Ensure adequate ventilation (air ow) if other
equipment such as liquid fuel stoves or heaters
are operated in the room in addition the cooker
hood. When the cooker hood is simultaneously
operated with burning appliances requiring ade-
quate fresh air from the room to work properly,
their safe operation is possible if under pressure
around these appliances is a maximum of 0.004
mbar (this does not apply when the cooker hood
is used as an odour lter)
• Do not lean on the hood.
• The hood should be cleaned regularly both inside
and out (AT LEAST ONCE A MONTH, following the
indications concerning maintenance provided in
this manual)..Failure to adhere to the rules con-
cerning cleaning the hood and replacing lters
results in a re risk.
• If the power cord is damaged it should be re-
placed by a specialised service centre.
• Ensure that it is possible to disconnect the ap-
- 9 -
pliance from the mains by removing the plug or
switching o the bi-polar switch.
• This appliance is not intended for use by persons
(including children) with physical, mental or sen-
sory handicaps, or by persons inexperienced or
unfamiliar with the appliance, unless under su-
pervision or in accordance with the instructions
as communicated to them by persons responsible
for their safety.
• Particular attention should be paid not to allow
unaccompanied children to use the appliance.
• Make sure voltage indicated on the nameplate
corresponds to the local mains supply voltage.
• Before use, extend and straighten the power cord.
• Packaging materials (bags, polyethylene, poly-
styrene, etc.) should be kept away from children
during unpacking.
• Before connecting the hood to the mains power
supply always check that the power cord is prop-
erly installed and is not trapped by the appliance.
Do not connect the appliance to the mains until
assembly is complete.
• Do not operate your kitchen hood without the al-
uminium grease lters.
• It is strictly forbidden to cook dishes under on an
open ame (ambé) under your kitchen hood.
• Always strictly adhere to regulations issued by the
competent local authorities regarding the techni-
cal and safety requirements for fume extraction.
• Failing to tighten bolts and fasteners in accord-
ance with these instructions may endanger life
and health.
• Hanging kitchen hoods operate only in air circu-
lation / odour absorber mode
• WARNING! Failure to install the screws or xing
device in accordance with these instructions may
result in electrical hazards.
- 10 -
UNPACKING
During transportation, protective
packaging was used to protect the
appliance against any damage. Af-
ter unpacking, please dispose of all
elements of packaging in a way that
will not cause damage to the environ-
ment.
All materials used for packaging the
appliance are environmentally friendly; they are
100% recyclable and are marked with the appropri-
ate symbol.
Important! Packaging materials (bags, polyethyl-
ene, polystyrene, etc.) should be kept away from
children during unpacking.
DISPOSAL OF OLD APPLIANCE
In accordance with European Directive
2012/19/EU and local legislation re-
garding used electrical and electronic
goods, this appliance is marked with
the symbol of the crossed-out waste
container. This marking indicates that
the appliance must not be disposed of
together with other household waste
after it has been used.
The user is obliged to hand it over to waste collec-
tion centre collecting used electrical and electron-
ic goods. The collectors, including local collection
points, shops and local authority departments pro-
vide recycling schemes.
Proper handling of used electrical and electronic
goods helps avoid environmental and health haz-
ards resulting from the presence of dangerous com-
ponents and the inappropriate storage and process-
ing of such goods.
Questo manuale è adatto per i seguenti modelli
2
Indice
Lingue:
Altri manuali Amica Cappa di ventilazione
Amica
Amica OKP6552SB Manuale utente
Amica
Amica KHF 664 630 S Manuale utente
Amica
Amica OTP6233W Manuale utente
Amica
Amica KHF 695 630 S Manuale utente
Amica
Amica KHF 665 610 S Manuale utente
Amica
Amica OMC6751B Manuale utente
Amica
Amica OMP6252BG Manuale utente
Amica
Amica OKM6652IS Manuale utente
Amica
Amica OSC5232I Manuale utente
Amica
Amica KHF 664 100 S Manuale utente
Amica
Amica UH Series Manuale utente
Amica
Amica OTP9651BG Manuale utente
Amica
Amica OTP6651BG Manuale utente
Amica
Amica OWC4441BK Manuale utente
Amica
Amica HCT Series Manuale utente
Amica
Amica KHF 662 610 Gy Manuale utente
Amica
Amica KH 17196-1 E Manuale utente
Amica
Amica 60311 Manuale utente
Amica
Amica OTP6241I/ST 62 AX Manuale utente
Amica
Amica AEP60BL Manuale utente
