Amplicomms PowerTel M6000 Manuale utente
Mobile Phone
Operating Instructions
PowerTel M6000
2
HAC Hearing Aid Compatible
to M4 / T4 Rating
The M6000 Phone has a built in Induction Coil and is
hearing aid compatible.
To ensure optimum benefit, users with hearing aids
may wish to select the T setting on their hearing aids.
Exposure to the receiver at full volume
for a long period could cause ear
damage.
1
Contents
3
1 Quick Start Guide 4. . . . . . . . . . . . . .
2 At a Glance 16. . . . . . . . . . . . . . . . . .
3 How does it work 20. . . . . . . . . . . . . . .
4 Getting Started 24. . . . . . . . . . . . . . . .
5 Phone Book Set Up 30. . . . . . . . . . . . .
6 Making and Receiving Calls 34. . . . . . .
7 Call Lists 38. . . . . . . . . . . . . . . . . . . .
8 SMS − Text Messages 40. . . . . . . . . . .
9 Voice Mail 46. . . . . . . . . . . . . . . . . . .
10 Other Useful Features 48. . . . . . . . . . .
11 Bluetooth 72. . . . . . . . . . . . . . . . . . . .
12 Emergency Call Function 74. . . . . . . . .
13 Services 83. . . . . . . . . . . . . . . . . . . . .
14 Menu Structure 84. . . . . . . . . . . . . . . .
15 Trouble Shooting 98. . . . . . . . . . . . . . .
16 Technical Properties 101. . . . . . . . . . . .
17 Safety Information 104. . . . . . . . . . . . . .
18 Maintenance / Guarantee 109. . . . . . . . .
19 Index 111. . . . . . . . . . . . . . . . . . . . . . .
Service−Hotline: 0844 800 6503 (Using an UK landline, at the time of going to print:
calls cost 6p for connection charge and then 5p a minute. Mobile costs may vary.)
Quick Start Guide
4
1 Quick Start Guide
Important: Before you start, please read the
safety information on page 104.
Quick Glance
1 Earpiece
2 Display
3 One−touch dialling keys / Softkeys
4 On/Off key / End call key
5 Scroll up/down keys
6 Hash key
7 Microphone
8 Star key
9 Keypad
10 Call key
11 LED
12 Attachment for Lanyard (not supplied)
13 Mini USB charging socket
14 Charge contacts
15 Headset socket (Headset not supplied)
16 Volume control
17 Loudspeaker
18 Emergency call switch
19 Battery compartment cover
Service−Hotline: 0844 800 6503 (Using an UK landline, at the time of going to print:
calls cost 6p for connection charge and then 5p a minute. Mobile costs may vary.)
Quick Start Guide
5
Service−Hotline: 0844 800 6503 (Using an UK landline, at the time of going to print:
calls cost 6p for connection charge and then 5p a minute. Mobile costs may vary.)
1
2
3
4
5
6
8
9
10
11
17
18
19
15
16
12
14
14
13
7
2
Quick Start Guide
6
What is in the box
The box contains:
1 mobile phone 1 power adapter plug
1 li−ion battery 1 operating manual
1 desktop charging unit
Installing the SIM card and battery
Risk of swallowing small objects!
The SIM card can be removed.
Small children can swallow them.
Switch the phone off.
Pay attention that the SIM card is not bent or
scratched. Prevent any contact with water, dirt
or electrical charges.
Slide the mobile phone’s
battery compartment cover
towards the bottom using a
little force. Lift the battery
compartment cover off the
phone completely.
Your telephone number is carried by the SIM
card, not the phone. Therefore if you use a
SIM card you had in a previous phone, you will
keep the same phone number.
Service−Hotline: 0844 800 6503 (Using an UK landline, at the time of going to print:
calls cost 6p for connection charge and then 5p a minute. Mobile costs may vary.)
1
2
Quick Start Guide
7
If there is already a battery
inside, remove it.
Slide the SIM card with the
golden contacts facing down
in the moulded SIM card
holder. The SIM card must be
located under the metal
retaining bar to be in the
correct position.
Insert the battery. The golden
contacts on the battery must
face towards the bottom right.
Press lightly on the top end of
the battery until it snaps into
place.
Replace the battery
compartment cover back on
the phone. Slide the battery
compartment cover upwards
until it snaps in to place.
Service−Hotline: 0844 800 6503 (Using an UK landline, at the time of going to print:
calls cost 6p for connection charge and then 5p a minute. Mobile costs may vary.)
1
2
1
2
3
Quick Start Guide
8
Charging the battery
Before starting to charge the battery, check
that it has been installed properly.
Do not remove the battery while it is being
charged. This could damage the phone.
When charging the battery for the first time, it
should be charged for at least 4 hours. Some
batteries only reach their full capacity after
several complete charge/discharge cycles.
Charging via the mini USB charging socket
Plug the power adapter in the
mini USB charging socket.
Connect the power adapter
plug as illustrated in the
diagram. For safety reasons,
only use the power adapter
plug supplied.
Service−Hotline: 0844 800 6503 (Using an UK landline, at the time of going to print:
calls cost 6p for connection charge and then 5p a minute. Mobile costs may vary.)
Mains power
outlet
4
5
Quick Start Guide
9
Charging via the desktop charging unit
Plug the power adapter plug
in the mini USB charging
socket on the charging unit.
Insert the phone in the
charging unit to charge it.
The display will go blank but even so the
battery is still being charged. This is correct
operation.
It may take a few seconds before the phone
indicates the charging process.
You can use the phone during the charging
process.
When the phone is switched off there is a different
view in the display − the charge icon is shown
pumping with the red LED.
Battery status warning
The current battery charge status is indicated in the
display as follows:
Full Half empty Low Empty
Service−Hotline: 0844 800 6503 (Using an UK landline, at the time of going to print:
calls cost 6p for connection charge and then 5p a minute. Mobile costs may vary.)
Quick Start Guide
10
When the battery charge is low, a corresponding
warning message appears in the display.
Charge the battery.
In cases where the battery charge is extremely low, it
is possible that the back−lighting no longer works and
certain functions are no longer available.
Charge the battery.
When the battery charge drops below the minimum
status, the phone switches off automatically.
Switching the mobile phone on and off
3 sec. Switch the mobile phone on
3 sec. Switch the mobile phone off
Some SIM cards will require you to enter a PIN
code. Follow the prompts on the screen or
read more details about PIN & PIN2 on
Page 59.
Make sure you are in range of your Network
Some networks offer better coverage than others in
different areas. The icon indicates you have a
signal and are connected to the network. The
network will also appear in the display.
Service−Hotline: 0844 800 6503 (Using an UK landline, at the time of going to print:
calls cost 6p for connection charge and then 5p a minute. Mobile costs may vary.)
