Amrobt SI-350 Manuale utente
Amrobt Sweeping Robot
Product Manual
Table of Contents
1. Important Safety Information
1.1 Use Restrictions .............................................................. 01
1.2 Battery and Charging .......................................................... 02
2. Product Diagram
2.1 Robot ...................................................................... 03
2.2 Accessories ................................................................. 05
2.3 Charging Dock ............................................................... 06
2.4 Remote Control .............................................................. 07
3. Operating and Programming
3.1 Notes Before Cleaning ......................................................... 08
3.2 Quick Start .................................................................. 09
3.3 How Amrobt Clean Your Home ....................................................11
3.4 Cleaning Schedule ............................................................ 13
3.5 APP Connecting .............................................................. 15
4. Regular Robot Care
4.1 Emptying Robot’s Bin .......................................................... 19
4.2 Cleaning Robot’s Filter ......................................................... 19
4.3 Cleaning Robot’s Side Brush .................................................... 20
4.4 Cleaning Robot’s Cliff Sensors and Charging Contacts ................................ 20
4.5 Cleaning Robot’s Floor Tracking Sensor ........................................... 21
4.6 Cleaning Robot’s Rolling Brush .................................................. 21
4.7 Battery and Charging Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5. Troubleshooting .............................................................. 24
6. Specications ................................................................ 26
7. Customer Service ............................................................. 27
1. Important Safety Information
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
The robot must be used in accordance with the directions in this Instruction Manual. Amrobt inc cannot be held liable or responsible for
any damages or injuries caused by improper use.
To reduce the risk of injury or damage, keep these safety precautions in mind when setting up, using and maintaining your robot:
• Read all safety and operating instructions before operating your robot.
• Retain the safety and operating instructions for future reference.
• Heed all warnings on your robot, battery, charging Dock and in the owner’s manual.
• Follow all operating and use instructions.
The symbol on the product or its packaging indicates:
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local authority for
information regarding the collection systems available. If electrical appliances are disposed of in landlls or dumps, hazardous sub-
stances can leak into the groundwater and get into the food chain, damaging your health and well-being. Please contact your local or
regional waste authority for more information on collection, reuse and recycling programs.
1.1 Use Restrictions
• Your robot is for indoor use only. Do not use the robot outdoor, commercial or industrial environments.
• Before using this device, pick up objects like clothing, loose papers, pull cords for blinds or curtains, power cords, and any fragile
objects. If the device passes over a power cord and drags it, there is a chance an object could be pulled or a table or shelf.
• Your robot is not a toy. Do not sit or stand on this device. Small children and pets should be supervised when your robot is operating.
• Store and operate your robot in room temperature environments only. Do not use this device to pick up anything that is burning or
smoking.
• Do not use this device to pick up spills of bleach, paint, or other chemicals, or anything wet.
• If the room to be cleaned contains a balcony, a physical barrier should be used to prevent access to the balcony and ensure safe
operation.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack
01
of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure they do not play with the robot. Cleaning and maintenance shall not be performed by children
without supervision.
• Do not place anything on top of your robot.
• Be aware that the robot moves on its own. Take care when walking in the area that the robot is operating in to avoid stepping on it.
• Do not operate the robot in areas with exposed electrical outlets in the oor.
1.2 Battery and Charging
• Use only rechargeable battery packs with the correct specication approved by Amrobt.
• Charge using a standard outlet only. Product may not be used with any type of power converter. Use of other power convert- ers will
immediately void the warranty.
• Do not use a Charging Dock with a damaged cord or plug. If the cord or plug is damaged, it must be serviced by the manu- facturer or
similarly qualied persons.
• Always charge and remove the battery from your robot and accessories before long-term storage or transportation. Charge indoors
only.
• Your robot’s Charging Dock may be protected with a surge protector in the event of severe electrical storms. Never handle the
Charging Dock with wet hands.
• Always disconnect your robot from the Charging Dock before cleaning or maintaining it. Please ensure voltage rating for enclosed
Charging Dock matches standard outlet voltage.
• Used battery packs should be placed in a sealed plastic bag and disposed of safely according to local environmental regula-
• tions.
• Before every use, check the battery pack for any sign of damage or leakage. Do not charge damaged or leaking battery packs.
• If the battery pack is leaking, contact Amrobt Customer Service for disposal. The battery pack must be removed from the robot before
disposal.
• Do not crush or dismantle battery packs. Do not heat or place the battery pack near any heat source. Do not incinerate the battery
pack. Do not short-circuit the battery pack.
• Do not immerse the battery pack in any liquid.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera-
tion.
02
2. Product Diagram
2.1 Robot
Power On / Cleaning
Press to Power on or Power Off
Hold on : Enter into network connecting
Press to Start Cleaning
03
Release Button Bumper
Charing Entrance
Infrared Sensor
Dust Collector
Anti-Drop Sensors
Side Brushes
Driving Wheels
Power Switch
Dust Bin
Universal Wheel
Charing Contacts
Battery Pack
Main Brush
04
2.2 Accessories
1 x Charging Dock 1 x Adapter 1 x Remote Control
1 x Dust Bin 4 x Side Brushes 1 x High Efciency Filter
1 x Brush 1 x Main Brush Water Tankand Cleaning Cloth
05
2.3 Charging Dock
Charging Indicator
Signal Transmission Area
Power Interface
Butting Charging Pole Piece
06
2.4 Remote Control
Mode and Time Display Screen
Start / Pause Button
Automatic Cleaning
Automatic Re-charging Button
Edge Cleaning Button
Zigzag Cleaning Button
Time Setting
Direction Buttons
Schedule Setting
Spot Cleaning Button
Non Function
07
