APM CO., LTD
AAL-9412
IP Speed Dome Camera
SPECIFICATIONS
Image Sensor 1/4” Sony EXview HAD CCD
Effective Pixels 768 (H) x 494 (V)
Lens 18x zoom, f=4.1 mm (wide) to 73.8 mm (tele), F1.4 to F3.0
Digital zoom 12x
Angle of view (H) 48° (wide end) to 2.8° (tele end)
Minimum working distance 35 mm (wide end), 800 mm (tele end)
Minimum Illumination 0.7 lux (Typical) (F1.4, normal shutter speed)
S/N ratio More than 50 dB
Gain Auto/Manual (-3 to 28 dB, 16x 2 dB steps)
Electronic shutter 1/1 to 1/10,000 s, 22 steps
White Balance Auto, ATW, Indoor, Outdoor, One-Push, Manual
Privacy Zone Masking ON/OFF
ICR ON/OFF
Panning/tilting
Panning Range 360° endless
Panning / Tilt Speed Manual: Approx. 0.1°/s ~ 200°/s, preset: up to approx. 400°/s
Tilting Range –2° ~ 90° (upward - level - downward)
Number of The Preset
Positions 64
PTZ control Preset, Auto pan, Tour
Video
Video compression MPEG4 / JPEG (dual codec), H.263 (for 3GPP)
Video frame rate up to 30fps for all video resolutions
Compression rate selection 5 levels: best, better, normal, faster, fastest
Frame rate setting NTSC: 1,2,3,4,5,6,7,10,15,30 fps ; PAL: 1, 2,3,4,5,6,12,25 fps
NTSC:176x112, 320x240, 640x480, 704x480
PAL:176x144, 352x288, 640x480, 704x576
Image rotation Mirror / Up side down / Flip
Motion detection Yes (3 windows)
Video resolution
22F-6, No.180, Jingping Rd., Jhonghe City, Taipei County 23581, Taiwan, R.O.C.
2 of 2
APM CO., LTD
Audio
Internal Microphone Sensitivity: 62 dB
Communication
LAN port RJ-45, 10/100M auto-sensed, auto crossover
Communication protocol HTTP, RTSP, FTP, SMTP, TCP/IP, UDP, ARP, ICMP, DHCP, PPPoE,
DDNS, UPnP, SAMBA
Video Streaming Multicasting / RTSP / Over HTTP
System
CPU 32bit RISC CPU
RAM 32MB
Flash ROM 4M Byte
OS uCLinux
I/O
Alarm Input 4
Alarm output 2
Analog video output 1
Analog audio output 1
LAN port 1
Software
Browser Internet Explorer 6.0 or above
Application Software CentaView application software
OS supported Microsoft Windows 2000, XP
Open API CGI commands to control camera
Media SDK to handle streaming
Power 24V AC / 12V DC
Size
Main body 149 x 230 mm
Operating environment
Operating temperature -10°C ~ 50°C
Storage temperature -20°C ~ 70°C
Humidity 10% ~ 90% non-condensing
Approvals CE Class B/ FCC Class B/ CCC
22F-6, No.180, Jingping Rd., Jhonghe City, Taipei County 23581, Taiwan, R.O.C.
