Specification of Vertical Type
Model PH20V PHC30V PHC45V PHC60V PHC60Vs PHC75Vs
Heatingcapacity KW
(air26℃,water26℃)9 12 16 23 23 30
C.O.P.
(air26℃,water26℃) ≥6.0 ≥6.0 ≥6.0 ≥6.0 ≥6.0 ≥6.0
Heatingcapacity KW
(air15℃,water26℃)6.3 8.5 11 16 16 21
C.O.P.
(air15℃,water26℃) ≥4.5 ≥4.5 ≥4.5 ≥4.5 ≥4.5 ≥4.5
CoolingCapacity KW
(air35℃,water28℃)\ 7.5 9.5 14 14 18
C.O.P.
(air35℃,water28℃) \ ≥3.8 ≥3.8 ≥3.8 ≥3.8 ≥3.8
Ratedpower/Max
power Kw 1.4/1.8 1.8/2.4 2.4/3.1 3.8/5.6 3.8/5.6 4.5/6.3
Powersupply 220-240V/1Ph/50Hz 380-415V/3Ph/50Hz
Ratedcurrent/Max
current A 6.4/8.2 8.2/11 10.9/14.1 17.3/26 5.8/8.5 6.8/9.5
Function
Noiselevel dB(A) ≤48 ≤48 ≤50 ≤56 ≤56 ≤58
Net/Grossweight Kg 55/60 70/75 85/93 107/117 107/117 127/137
Waterpipe in-outspec mm 48 48 48 48 48 48
Advisedwater flux m³/h 4-6 5-7 6.5-8.5 8-10 8-10 10-12
Parameters of product range
*C.O.P: Coefficient of performance
Note:
1. Mode PH~ only haveheat function and PHC is heat and cool optional. S refers to 3-phase.
2. This product can work well under air temp +0
℃
~43℃. Performance cannot be guaranteed outside the
operating ranges and must take account the exterior conditions of use identified to select suitable mode
(such as location, area of swimming pool, and numbers of swimmer.)
3. Above parameters are subjected to adjustment periodically for technical improvement with further notice.
Please refer to nameplate on each machine for accurate information.
3
