Arris Touchstone TG1672 Manuale utente

Touchstone®TG1672

Telephony Gateway

User’s Guide

Get ready to experience the Internet’s express lane! Whether you’re checking out

streaming media, downloading new software, checking your email, or talking with

friends on the phone, the Touchstone TG1672 Telephony Gateway brings it all to you

faster and more reliably. All while providing toll quality Voice over IP telephone ser -

vice and both wired and wireless connectivity. It also provides a Lithi um-Ion bat-

tery backup to provide continued telephone service during power outages.

The Touchstone Telephony Gateway provides four Ethernet connections for use as

the hub of your home/ofﬁce Local Area Network (LAN). The Telephony Gateway

also provides 802.11a/b/g/n wireless connectivity for enhanced mobility and ver-

satility. In addition, the Telephony Gateway provides for up to two separate lines of

telephone service. The Telephony Gateway also offers integrated MoCA 1.1 home

networking providing Internet access and transfer of multimedia content between

devices over coaxial cable in the home.

Installation is simple and your cable company will provide assistance to you for any

special requirements. The links below provide more detailed instructions.

Safety Requirements

Getting Started

Battery Installation and Removal

Installing and Connecting Your Telephony Gateway

Conﬁguring Your Ethernet Connection

Using the Telephony Gateway

Troubleshooting

Glossary

Export Regulations

This product may not be exported outside the U.S. and Canada without U.S. Department of Commerce, Bureau of Export Admin istration au-

thorization. Any export or re-export by the purchaser, directly or indirectly, in contravention of U.S. Export Adminis tration Regulation is prohib-

ited.

any derivative work (such as translation, transformation, or adaptation) without written permission from ARRIS Enterprises, Inc. (“ARRIS”).

ARRIS reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of ARRIS to

provide notiﬁcation of such revision or change.

ARRIS provides this guide without warranty of any kind, implied or expressed, including, but not limited to, the implied warranties of mer-

chantability and ﬁtness for a particular purpose. ARRIS may make improvements or changes in the product(s) described in this manual at any

time. The capabilities, system requirements and/or compatibility with third-party products described herein are subject to change without no-

tice.

ARRIS and the ARRIS logo are all trademarks of ARRIS Enterprises, Inc. Other trademarks and trade names may be used in this document to

refer to either the entities claiming the marks and the names of their products. ARRIS disclaims proprietary interest in the marks and names of

others.

Protected under one or more of the following U.S. patents: 7,031,435, 7,916,744. Other patents pending.

Release 16 Standard 1.0 October 2013

Safety Requirements

ARRIS Telephony Gateways comply with the applicable requirements for perform-

ance, construction, labeling, and information when used as outlined below:

CAUTION

Risk of shock

Mains voltages inside this unit. No user serviceable parts inside. Refer

service to qualiﬁed personnel only!

CAUTION

Potential equipment damage

Potential loss of service

Connecting the Telephony Gateway to existing telephone wiring should

only be performed by a professional installer. Physical connections to

the previous telephone provider must be removed and the wiring must

be checked; there must not be any voltages. Cancellation of telephone

service is not adequate. Failure to do so may result in loss of service

and/or permanent damage to the Telephony Gateway.

CAUTION

Risk of explosion

Replacing the battery with an incorrect type, heating a battery above

75°C, or incinerating a battery, can cause product failure and a risk of

ﬁre or battery explosion. Do not dispose of in ﬁre. Recycle or dispose

of used batteries responsibly and in accordance with local ordinances.

• The Telephony Gateway is designed to be connected directly to a telephone.

• Connecting the Telephony Gateway to the home’s existing tele phone wiring

should only be performed by a professional in staller.

• Do not use product near water (i.e. wet basement, bathtub, sink or near a

swimming pool, etc.), to avoid risk of electrocu tion.

• Do not use the telephone to report a gas leak in the vicinity of the leak.

Touchstone TG1672 Telephony Gateway User’s Guide

Safety

Getting

Started

Battery

Installation Installation

Ethernet

Conﬁguration Usage Troubleshooting Glossary

• The product shall be cleaned using only a damp, lint-free, cloth. No sol-

vents or cleaning agents shall be used.

• Do not use spray cleaners or aerosols on the gateway.

• Avoid using and/or connecting the equipment during an electri cal storm, to

avoid risk of electrocution.

• Do not locate the equipment within 6 feet (1.9 m) of a ﬂame or ignition

source (i.e. heat registers, space heaters, ﬁreplaces, etc.).

• Use only power supply and power cord included with the equip ment.

• Equipment should be installed near the power outlet and should be easily

accessible.

• The shield of the coaxial cable must be connected to earth (grounded) at the

entrance to the building in accordance with applicable national electrical in-

stallation codes. In the U.S., this is required by NFPA 70 (National Electrical

Code) Article 820. In the European Union and in certain other countries,

CATV instal lation equipotential bonding requirements are speciﬁed in IEC

60728-11, Cable networks for television signals, sound signals and interac-

tive services, Part 11: Safety. This equipment is in tended to be installed in

accordance with the requirements of IEC 60728-11 for safe operation.

If the equipment is to be installed in an area serviced by an IT power line

network, as is found in many areas of Norway, spe cial attention should be

given that the installation is in accor dance with IEC 60728-11, in particular

Annex B and Figure B.4.

• In areas of high surge events or poor grounding situations and areas prone

to lightning strikes, additional surge protection may be required (i.e.

PF11VNT3 from American Power Conver sion) on the AC, RF, Ethernet and

Phone lines.

• When the Telephony Gateway is connected to a local computer through Eth-

ernet cables, the computer must be proper ly grounded to the building/res-

idence AC ground network. All plug-in cards within the computer must be

properly installed and grounded to the computer frame per the manufac-

turer’s speciﬁcations.

• Ensure proper ventillation. Position the Telephony Gateway so that air ﬂows

freely around it and the ventillation holes on the unit are not blocked.

Touchstone TG1672 Telephony Gateway User’s Guide

Safety

Getting

Started

Battery

Installation Installation

Ethernet

Conﬁguration Usage Troubleshooting Glossary

• Do not mount the Telephony Gateway on surfaces that are sensitive to heat

and/or which may be damaged by the heat generated by the modem, its

power supply, or other accessories.

FCC Part 15

This equipment has been tested and found to comply with the requirements for a

Class B digital device under Part 15 of the Federal Communications Commission

(FCC) rules. These requirements are intended to provide reasonable protection

against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in ac-

cordance with the instructions, may cause harmful interference to radio communi-

cations. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the fol-

lowing measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modiﬁcations to this equipment not expressly approved by

the party responsible for compliance could void the user’s authority to operate the

equipment.

RF Exposure

This equipment complies with FCC radiation exposure limits set forth for an uncon-

trolled environment. This equipment should be installed and operated with mini-

mum distance of 7.9 inches (20cm) between the radiator and your body. This

transmitter must not be co-located or operating in conjunction with any other an-

tenna or transmitter.

Touchstone TG1672 Telephony Gateway User’s Guide

Safety

Getting

Started

Battery

Installation Installation

Ethernet

Conﬁguration Usage Troubleshooting Glossary

Industry Canada Compliance

Under Industry Canada regulations, this radio transmitter may only operate using

an antenna of a type and maximum (or lesser) gain approved for the transmitter

by Industry Canada. To reduce potential radio interference to other users, the an-

tenna type and its gain should be so chosen that the equivalent isotropically radi-

ated power (e.i.r.p.) is not more than that necessary for successful communication.

This device complies with Industry Canada license-exempt RSS standard(s). Oper-

ation is subject to the following two conditions: (1) this device may not cause in-

terference, and (2) this device must accept any interference, including interference

that may cause undesired operation of the device.

For Mexico

The operation of this equipment is subject to the following two conditions: (1) This

equipment or device cannot cause harmful interference and (2) this equipment or

device must accept any interference, including interference that may cause some

unwanted operation of the equipment.

Touchstone TG1672 Telephony Gateway User’s Guide

Safety

Getting

Started

Battery

Installation Installation

Ethernet

Conﬁguration Usage Troubleshooting Glossary

European Compliance

This product complies with the provisions of the Electromagnetic Com patibility

(EMC) Directive (89/336/EEC), the Amending Directive (92/31/EEC), the Low Volt-

age Directive (73/23/EEC), and the CE Marking Directive (93/68/EEC). As such,

this product bears the CE marking in accordance with the above applicable Direc-

tive(s).

A copy of the Declaration of Conformity may be obtained from: ARRIS Interna-

tional, Inc., 3871 Lakeﬁeld Drive, Suite 300, Suwanee, GA 30024.

As indicated by this symbol, disposal of this prod uct or battery

is governed by Directive 2002/96/EC of the European Parliament

and of the Council on waste electrical and electronic equipment

(WEEE). WEEE could potentially prove harmful to the environ-

ment; as such, upon disposal of the Telephony Gateway the Di-

rective requires that this product must not be disposed as

unsorted munic ipal waste, but rather collected separately and

dis posed of in accordance with local WEEE ordinances.

This product complies with directive 2002/95/EC of the European

Parliament and of the Council of 27 January 2003 on the restriction

of the use of certain hazardous substances (RoHS) in electrical and

electronic equip ment.

Touchstone TG1672 Telephony Gateway User’s Guide

Safety

Getting

Started

Battery

Installation Installation

Ethernet

Conﬁguration Usage Troubleshooting Glossary

Getting Started

About Your New Telephony Gateway

The Touchstone TG1672 Telephony Gateway is DOCSIS compliant with the follow-

ing features:

• Speed: much faster than dialup or ISDN service; up to eight times faster

than DOCSIS 2.0 cable modems.

• Convenience: supports Ethernet and 802.11b/g/n wireless connections; both

can be used simultaneously

• Flexibility: provides two independent lines of telephone service as well as

high speed data

• Compatibility:

– Data services: DOCSIS 3.0 compliant and backward-compatible with

DOCSIS 2.0 or 1.1; supports tiered data services (if offered by your

cable company)

– Telephony services: PacketCable™ 1.5 or 1.0 compliant

The TG1672 provides:

• Wireless 802.11b/g/n connectivity

• Four Ethernet ports for connections to non-wireless devices

• Up to two lines of telephone service

• DOCSIS 3.0 compliant with Li-Ion backup battery

• One USB host port (future support for external USB devices)

What’s in the Box?

Make sure you have the following items before proceeding. Call your cable company

for assistance if anything is missing.

• Telephony Gateway

• Power Cord

• Battery (Not included with all models.)

Touchstone TG1672 Telephony Gateway User’s Guide

Safety

Getting

Started

Battery

Installation Installation

Ethernet

Conﬁguration Usage Troubleshooting Glossary

Coax Cable

Safety

Getting

Started

Battery

Installation Installation

Ethernet

Conﬁguration Usage Troubleshooting Glossary

Touchstone TG1672 Telephony Gateway User’s Guide

• Wireless Connection Conﬁguration Guide

• Ethernet Cable

• End User License Agreement

Items You Need

If you are installing the Telephony Gateway yourself, make sure you have the fol-

low ing items on hand before continuing:

•Telephony Gateway package: see What’s in the Box? for a list of items

in the package.

•Coaxial cable (coax): as shown in the image to the left, this is a round

cable with a connector on each end. It is the same kind of wire used to con-

nect to your television for cable TV. You can buy coax from any electronics

retailer and many discount stores; make sure it has connectors on both

ends. There are two types of connectors, slip-on and screw-on; the screw-

on connectors are best for use with your Telephony Gateway. The coax

should be long enough to reach from your Telephony Gateway to the near-

est cable outlet.

•Phone Cable: as shown in the image to the left, this is a standard phone

cable with standard phone connectors (RJ11 type) on both ends. You can

buy phone cables from any electronics retailer and many discount stores.

•Splitter (optional): provides an extra cable connection by splitting a sin-

gle outlet into two. You may need a splitter if you have a TV already con-

nected to the cable outlet that you want to use. You can buy a splitter from

any electronics retailer and most discount stores; you may also need a short

piece of coax cable (with connectors); use it to connect the splitter to the

cable outlet and then connect the Telephony Gateway and TV to the splitter.

Note: A splitter effectively cuts the signal in half and sends each half to its

two outputs. Using several splitters in a line may deteriorate the quality of

your television, telephone, and/or internet connection.

•Wall-Mounting Bracket (optional): if you want to wall-mount your Tele-

phony Gateway, you need to obtain two drywall anchors or wood screws and

order a wall-mounting bracket from your cable company.

Phone Cable

•Information packet: your cable company should furnish you with a packet

containing information about your service and how to set it up. Read this in-

formation carefully and contact your cable company if you have any ques-

tions.

Getting Service

Before trying to use your new Telephony Gateway, contact your local cable company

to establish an Internet account and telephone service. When you call, have the

fol lowing information ready:

• the Telephony Gateway serial number and cable MAC addresses of the unit

(printed on a sticker on the bottom of the Telephony Gateway)

• the model number of the Telephony Gateway

If the Telephony Gateway was provided by your cable company, they already have

the required information.

In addition, you should ask your cable company the following questions:

• Do you have any special system requirements or ﬁles that I need to down-

load after I am connected?

• When can I start using my Telephony Gateway?

• Do I need a user ID or password to access the Internet or my e-mail?

• Will my phone number(s) change?

• What new calling features will I have and how do I use them?

Touchstone TG1672 Telephony Gateway User’s Guide

Safety

Getting

Started

Battery

Installation Installation

Ethernet

Conﬁguration Usage Troubleshooting Glossary

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Arris Portale

Arris

Arris Touchstone TG3452 Manuale utente

Arris

Arris SURFboard SBG6900-AC Manuale utente

Arris

Arris Touchstone TG3492LG-LIB Manuale utente

Arris

Arris NVG5X8 Manuale utente

Arris

Arris SURFboard SBG6950 Manuale utente

Arris

Arris NVG599 Manuale utente

Arris

Arris Touchstone DG2470 Manuale utente

Arris

Arris Touchstone DOCSIS 3.0 Manuale utente

Arris

Arris Touchstone DG950 Manuale utente

Arris

Arris Touchstone TG3452 Manuale

Arris

Arris Touchstone TG862G Manuale utente

Arris

Arris Touchstone DG2460 Manuale utente

Arris

Arris SURFboard SBG6400 Manuale utente

Arris

Arris NVG34x Manuale utente

Arris

Arris SURFboard SBG7400AC2 Manuale utente

Arris

Arris Touchstone TG9452 Manuale utente

Arris

Arris SurfBoard SVG2482AC Manuale utente

Arris

Arris Touchstone TG862G Manuale utente

Arris

Arris SurfBoard SVG2482AC Manuale utente

Arris

Arris Touchstone DG2460 Manuale utente

Arris

Arris Touchstone DG860 Manuale utente

Arris

Arris Touchstone TG862 Manuale utente

Arris

Arris SURFboard SBG7580-AC QSG Manuale utente

Arris

Arris BGW210 Scheda tecnica

Manuali Portale popolari di altre marche

LST

LST M500RFE-AS Manuale utente

Kinnex

Kinnex Media Gateway Manuale utente

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuale utente

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuale utente

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuale utente

Telsey

Telsey CPVA 500 - SIP Manuale utente

RTA

RTA 460A-NNA4 Scheda tecnica

Shaw

Shaw Gateway HDPVR Manuale utente

ABB

ABB VSN900 Guida rapida

Commander

Commander Pulse Manuale utente

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuale utente

NETGEAR

NETGEAR C6300BD Manuale utente

Amit

Amit CDW531AM Manuale utente

HMS

HMS Netbiter EasyConnect EC150 Manuale utente

Huawei

Huawei EchoLife HG620 Manuale utente

AT&T

AT&T U-verse 3801 Manuale per l'uso e la cura

Logic IO

Logic IO RTCU MX2 turbo Manuale utente

Suttle

Suttle MediaMAX MXM-521 Manuale utente
