Screwdriver Structure Diagram
Type-C
Charging Port
Working Status
Indicator
R
Forward Key
L
Reverse Key
LED Lights
Aluminium Alloy
Body
Bit Installation
Port
Dynamic Indicator
lights from
bottom to top.
Press and hold L
For Reverse
Press and hold R
For Forward
Dynamic Indicator
lights from
top to bottom.
Warranty card:
Warranty regulations
1. The warranty period for this product is 12 months.
2. With 7 days from the date of sale, if product perfor-
mance fault is found, it can be returned, replaced or
maintained, please contact the customer service.
3. If you have any quertions, please contact your dealer.
The following situations are not covered by
the warranty:
1. Product is damaged due to improper use,
maintenance, and storage.
2. No after-sales vouchers and valid invoices.
3. The damage is caused by force majeure.
The company reserves the right to modify the above
provisions, without violating relevant national laws and
regulations, we have the final right of interpretation.
Maintenance information
User name:
Telephone:
E-mail:
Address:
Purchase date:
Maintenance reasons:
Manufacturer Information
Manufacturer: Freemax Technology Co.,Ltd
Address: Room 1203,12/F,Wah Shing Centre,
11-13 Shing Yip Street,Kwun Tong,Hong Kong
T: + 852 3590 9790
www.am-smart.com
Mini Electric Screwdriver Set 96+6
Precision screwdriver box set
Thank you for choosing SES MINI ( Electric Screwdriver).
Please read the instructions manual carefully.
Product description:
SES MINI design L,R (forward, reverse) button,
design four indicator lights to dynamically display
the working status. The four LED lights on the
head will automatically light up while working.
SES MINI handle adopts a square shape with a
circular arc surface, breaking the circular design
of the traditional precision electric screwdriver,
making it better to control the screwdriver during
work and the grip is more comfortable. While
effectively protecting the motor from overload, the
screwdriver is also properly protected in manual
mode. The product has applied for a number of
patents.
The specially formulated high-capacity lithium
battery makes more effective use of the internal
space of the product. Under the premise of
maintaining the torque and power required for
normal operation, the volume of the SES MINI is
reduced by more than 20% on average compared
with the current similar products, and the lithium
battery capacity can reach 350mAh , which makes
the working time of SES MINI longer.
SES MINI is with a precision screwdriver set
96 in 1. The internal structure is compact.
There are 96 different types of bit. Most 3C
products, computers, four-axis unmanned
machines, glasses, clocks, toys, models, etc,
can be installed and disassembled.
Working Status:
Ÿ Press and hold the L-reverse key, the four
indicators lights will light up from bottom to top
on the dynamic display, the screwdriver head
rotates to the left to loosen the screw.
Ÿ Press and hold the R-forward key, the four
indicators lights turn on sequentially from top
to bottom on the dynamic display, and the
screwdriver head rotates to the right to lock
the screw.
Ÿ The indicator shows the current remaining
battery: 4 lights (100%) / 3 lights (75%) /
2 lights (50%) / 1 light (25%).
Storage Instructions:
Ÿ Press the top of the storage box,
the inner box of the storage box pops out
to open.
Ÿ Press the top of the inner box once more
to close the storage box.
Precision screwdriver storage:
Ÿ The precision screwdriver is fixed to the
inner box of the storage box in the form of
a buckle.
Ÿ After use, put precision screwdriver back
into the tray.
Ÿ Bits are accommodated in the inner box
by magnetic absorption. After using the bit,
back into the slot, the bit can be absorbed
by itself.
ŸTake out the bit from the slot and insert it
into the bit installation port. - Inner Box
- Precision Screwdriver
- Bits
- Storage Box
Product parameters:
Product model: AM-199811
Battery voltage: 3.7V
Size: 15 x 15 x 115 mm
Lithium battery: 350 mAh
Weight: 45g
No-load speed: 200r/min
Electric maximum torque: 1.5kgf.cm
Charging time: 50 minutes
Product list:
1x SES MINI
1x Magnetic pad
1x Power tip extension
1x Precision screwdriver storage box
1x Precision screwdriver
48x S2 steel 4mm double end screwdriver bits
T9H-T15H
T10H-T20H
1.5- 1.0
1.5- 1.2
1.8- 1.5
2.0- 2.0
2.5- 2.5
3.0- 3.0
3.5- 3.5
4.0- 4.0
2.0- 3.5
2.5- 4.0
1.0- 2.0
1.3- 2.3
PZ000- 1.8
PZ00- 1.2
T1-T5
T2-T8
T1-T6
T2-T7
T3-T8
T4-T9
T5-T10
T6-T15
T9-T20
H0.7-H1.5
H0.9-H2.0
H1.0-H3.0
H1.3-H3.5
H1.5-H4.0
T5H-T7H
T6H-T8H
PZ0- 2.0
PZ1- 2.5
PZ2- 3.0
0.8- 1.5
0.8- 1.5
1.2- 2.0
1.2- 1.5
2.0-Y2.0
2.3-Y2.5
2.6-Y0.6
3.0- 0.8
U2.6-S2
U3.0-H4.0
Y0.6-Y3.0
S0- 1.0
S1- 2.5
1x Type-C cable
1x SES thor stand
1x Manual
