T
he Tube MP is the world’s most popular external
tube microphone preamp. Whether you’re
working with a four-track, hard-disk, or digital
multitrack recorder, the Tube MP’s TEC award
nominated design will allow you to obtain
professional recording studio results at a fraction of
the cost of comparable equipment. The hybrid
design of the Tube MP allows it to add warmth and
fatness to a signal while maintaining exceptionally
low-noise and high quality. While its primary
application is to be used with a microphone, the
Tube MP is an exceptional direct box - impedance
matching, amplifying and improving the sound of any instrument plugged into it.
The usage of external mic/ line preamps has become increasingly popular over the past
several years. The Tube MP offers superior performance and sound quality to the “on-
board” preamps found in today’s low-cost mixers and multi-trackers. It’s sound has been
consistently favored over other products costing upwards to ten-times its price. Professional
quality sound combined with professional features like: a 12AX7a Tube, phantom power
and Phase Reverse, are what have made the Tube MP a staple in thousands of studios
worldwide. For a minimal investment, a Tube MP can provide the single largest
improvement to the sound of your studio.
A R T is the industry leader in Tube dynamics processing equipment. Pick up a Tube MP
today at your favorite authorized A R T dealer.
TUBE MP
PROFESSIONAL TUBE MICROPHONE PREAMPLIFIER
FEATURES:
PROVIDES SUPERIOR
PREAMPLIFICATION FOR:
MICROPHONES,
INSTRUMENTS AND LINE
LEVEL SOURCES
HAND SELECTED 12AX7A
PROVIDES OVER 70DB OF
GAIN
SMOOTH, WARM AND FAT
SOUND QUALITY
VARIABLE INPUT AND
OUTPUT GAIN CONTROLS
EXCELLENT AS A TUBE DI
XLR AND 1/4” INPUTS AND
OUTPUTS
+48 VOLTS PHANTOM
POWER
PHASE REVERSAL SWITCH
SUPERIOR SONIC
PERFORMANCE TO ON-
BOARD PREAMPS
TEC-AWARD NOMINATED
DESIGN
3 YEAR WARRANTY
DESIGNED AND
MANUFACTURED IN THE
USA
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
10
9
8
7
6
5
4
3
2
1
LINE INPUT
1/4” out to amp
XLR out to mixer
~ Mic or Instrument Direct to Tape Through the Tube MP ~
~ Into a Line Input of a Mixer ~
~ Used as a Tube DI ~
SPECIFICATIONS:
Dimensions 5.0"D x 5.5"W x 2.0"H
Weight 1.5 lbs
Dynamic Range >100dB (20Hz to 20kHz)
Frequency Response 10Hz to 20kHz (+0,-1dB)
THD <0.1% (typical)
CMMR >75dB (typ @1kHz)
EIN -129dBu (‘A’ weighted XLR to XLR)
Maximum Gain 70dB (XLR to XLR typical)
60dB (1/4” to XLR typical)
Max. Input Level +14dBu (XLR), +22dBu (1/4”)
Max. Output Level +28dBu (XLR), +22dBu (1/4”)
Input Impedance 2k ohms (XLR), 840K ohms (1/4”)
Output Impedance 600 ohms (XLR), 300 ohms (1/4”)
Power Requirements USA - 9 VAC @ 700ma (typ)
Export units configured for country of
destination
Warranty 3 Years
APPLICATIONS:
Four to Twenty-Four Track Home Recording Studios
FOH Sound Systems
Tube Direct Box
Guitar, Bass and Keyboard Rigs
Digital Audio Workstation & Computer Recording
MIDI Recording and Samplers
Line Driver
APPLIED RESEARCH AND TECHNOLOGY, INC. 215 TREMONT STREET, ROCHESTER, NY 14608 USA
Vox: 716.436.2720, Fax: 716.436.3942, http://www.artroch.com
Features and specifications subject to change without prior notice.
1997 Applied Research and Technology, Inc. 000-102-127
TUBE MP
SPECIFICATIONS
“A kick-ass preamp whose
power and transparency
belie its bargain price”
Guitar Player August 1997
“.. the Tube MP is a rockin’
good deal. Every recordist
working with an MDM or
hard-disk recorder should
buy this piece of equipment
immediately. Trust me, you’ll
find tons of uses for the
Tube MP.”
Electronic Musician
Feb. 1996
“A R T has created a cool
little tube preamp that can
be used in quite a variety of
recording situations.”
EQ
Feb. 1996
