Centellis 2000 User Card 10GE TelcoAlarm-Quick Start Guide
Artesyn Embedded Technologies
Marketing Communications
2900 S. Diablo Way, Suite 190
Tempe, Arizona 85282
Artesyn Embedded Technologies
Lilienthalstr. 17-19
85579 Neubiberg/Munich
Germany
Finding more information
For more information on the product, see
the Centellis 2000 User Card 10GE with
Telco Alarm Installation and Use and other
related documentation.
Visit our Web site http://www.arte-
syn.com/computing. Use SUPPORT>TECH-
NICAL DOCUMENTATION link to look for
technical documentation.
Technical Assistance
To request technical assistance, visit our
Web site
http://www.artesyn.com.
Installing Centellis 2000
User Card
The following procedure describes the
installation of the board. It assumes that
your system is powered. If your system is
not powered, you can disregard the blue
LED and thus skip the respective step. In this
case it is a purely mechanical installation.
1. Put on an ESD wrist strap.
2. Connect the strap to the shelf by attach-
ing the front or rear ESD jack /ESD snap.
3. Insert the board into the shelf by placing
the left and right edges of the board in
the card guides of the shelf. Ensure that
the guiding module of shelf and board
are aligned properly. The alignment pin
facilitates the insertion and prevents
bent pins.
4. Slide the board into the shelf by using the
extraction handles until you feel resis-
tance.
5. Wait until the blue LED is illuminated.
6. Tighten the screws on the left and on the
right of the board. In this way the handle
switch activator is closed and the board
can be powered. The blue LED blinks.
7. Wait until the blue LED is switched off.
8. The switched off blue LED indicates that
the board is activated.
9. Attach cables to the front panel connec-
tors as necessary.
5Removing Centellis 2000
User Card
The following procedure describes how
to remove the board from a system. It
assumes that the system is powered. If
the system is not powered, you can dis-
regard the blue LED and thus skip the
respective step. In that case it is a purely
mechanical procedure.
1. To extract the active shelf manager
initiate a switchover. Otherwise con-
tinue with the next step.
2. Put on an ESD wrist strap.
3. Connect the strap to the shelf by
attaching it to the front or rear ESD
jack /ESD snap.
4. Remove any cables that are attached
to front panel connectors.
5. Unfasten the screws of the face plate
until the handle is detached from the
front panel of the board. The handle
switch activator triggers the blinking
of the blue LED. The hotswap state
remains in the state "extraction
pending", so that the blue LED is still
blinking.
6. Wait until the blue LED is illuminated.
7. Remove the board from the shelf
using the extraction handles.
6
