Article NERA Manuale utente

Assembly Instructions

NERA

6 Drawer Double Dresser

VERSION 1.1

NERA 6 Drawer Double Dresser Page 2 of 9

ASSEMBLY INSTRUCTIONS

Read these instructions carefully and keep for future

reference. Refer to parts inventory for guidance, and

ensure you have all pieces before starting.

When assembling, place all parts on a soft, clean, and ﬂat

surface such as a carpet to prevent scratches.

If you’re having diculty, our friendly Customer Care

team is always here to help. Call us at 1.888.746.3455

during business hours, email [email protected] or chat

live at article.com.

15 min

PARTS INVENTORY

ID DESCRIPTION QTY

CENTER LEG 1

SIDE LEG FRAME 2

M6 ×15MM BOLT 12

ALLEN KEY 1

TIME # OF PEOPLE DIFFICULTY

ANTI-TIP

Installation Required

Page 3 of 9

NERA 6 Drawer Double Dresser

× 12

THISSIDE UP

THIS SIDE HEADBOARD

Adjust levelers on

side legs as needed.

Page 4 of 9

ANTI-TIP Installation

Children have died from furniture tipover.

To reduce the risk of furniture tipover:

• ALWAYS install tipover restraint provided.

• NEVER put a TV on this product.

• NEVER allow children to stand, climb or hang

on drawers, doors, or shelves.

• NEVER open more than one drawer at a time.

• Place heaviest items in the lower drawers.

20 min

TIME

REQUIRED TOOL

8MM / 5/16" DRILL BIT

# OF PEOPLE DIFFICULTY

PARTS INVENTORY

ID DESCRIPTION QTY

BRACKET 4

M4 ×20MM SCREW 4

M8 ×51MM PLUG 4

M6 ×70MM SCREW 4

STRAP 2

ANTI-TIP RESTRAINT INSTALLATION

WARNING!

Hardware (C/D) to attach brackets to wall is

designed for drywall. To attach this unit to another

type of wall, consult with your local hardware store.

1010 Raymur Ave.

Vancouver, BC V6A 3T2

VERSION 1.4

Page 5 of 9

ANTI-TIP Installation

Attach pair of brackets to top corners of

the back of the unit. Note there are no

existing pilot holes on the product.

× 4

Mark on wall where second pair

of brackets should be placed.

× 2

× 4× 4 × 4

Drill holes in wall using

8mm / 5/16"drill bit.

Page 6 of 9

ANTI-TIP Installation

Align brackets on unit

with brackets on wall.

Pull strap down until it snap-locks.

× 2 × 2

Page 7 of 9

NERA Soft Close Drawers

Adjustment Instructions

FIXED A CROOKED DRAWER

SOFT CLOSING DRAWERS

ADJUSTMENT INSTRUCTIONS

Structural integrity is warranted only if all

fasteners are properly installed & tightened,

and the bed is moved only per instructions.

×2

Adjust levelers on either side of drawer

as needed to straighten drawer.

Page 8 of 9

NERA Soft Close Drawers

Adjustment Instructions

REMOVE DRAWER

×2

To unlock.

Page 9 of 9

NERA Soft Close Drawers

Adjustment Instructions

INSTALL DRAWER

×2

To lock.
