ACD7000W
OPERATION MANUAL
APPLIANCES
FOR LIVING
Congratulations, you are now the proud owner of an ARTUSI cooking appliance. Thank you for purchasing ARTUSI
and welcome to the ARTUSI Family.
This instruction manual has been specially created to inform you of the full range of features your ARTUSI appliance
has to offer and serves as an introduction to getting the very best out of your ARTUSI appliance.
We present detailed information on each of the features your ARTUSI appliance consists of. Once you have read
this section you will be able to choose the most appropriate settings for your appliance when cooking different
types of food.
We ask you to read the instructions in this booklet very carefully as this will allow you to get the best results from
using your appliance. KEEP THE DOCUMENTATION OF THIS PRODUCT FOR FUTURE REFERENCE.
TO REGISTER YOUR PRODUCT WITH ARTUSI, PLEASE FILL OUT THE WARRANTY CARD AT THE END OF
THIS BOOKLET AND POST IT TO: REPLY PAID 83617
LEICHHARDT NSW 2040
Dear Artusi Customer, please read this user manual carefully before using the product and, keep it permanently at
your disposal.
Note: This user manual is prepared for more than one model. Some of the features specified in this Manual may not
be available on your appliance.
All our appliances are only for domestic use, not for commercial use. Products marked with (*) are optional.
“THIS APPLIANCE SHALL BE INSTALLED IN ACCORDANCE WITH THE REGULA TIONS FORCE AND ONLY USED
IN A WELL VENTILATED SPACE. READ THE INSTRUCTIONS BEFORE INSTALLING OR USING THIS APPLIANCE”
“Conforms with the WEEE Regulations.”
Tumble Dryer / User Manual
EN
ACD7000W
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the
operation and maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep
this book for future reference.
Icon Caption Description
WARNING Risk of serious injury or death
RISK OF ELECTRIC SHOCK Dangerous voltage
FIRE
ATTENTION Risk of injury or material damage
IMPORTANT/NOTE Information on correct operation of the system
Read the instructions.
Hot surface
EN - III
CONTENTS
1. SAFETY INSTRUCTIONS ................................................................................. 3
1.1. Electrical Safety ............................................................................................... 3
1.2. Children's Safety ............................................................................................. 4
1.3. Product Safety ................................................................................................. 5
1.4. Correct Use ..................................................................................................... 6
1.5. Installing On Top Of a Washing Machine......................................................... 7
2. INSTALLATION .................................................................................................. 9
2.1. Connection to Water Outlet (with optional drain hose) .................................... 9
2.1.1. Connecting the Water Discharge Hose ........................................................ 9
2.2. Adjusting the Feet ............................................................................................ 9
2.3. Electrical Connection ..................................................................................... 10
2.4. Under Counter Installation ............................................................................. 10
3. OVERVIEW ...................................................................................................... 10
4. PREPARING THE LAUNDRY .......................................................................... 11
4.1. Sorting the Laundry to be Dried..................................................................... 11
4.2. Preparing the Laundry to be Dried ................................................................ 12
4.3. Load Capacity................................................................................................ 12
5. USING THE TUMBLE DRYER ........................................................................ 13
5.1. Control Panel ................................................................................................. 13
5.1.1. Programme Selection Knob........................................................................ 13
5.1.2. Electronic Indicator and Additional Functions ............................................. 13
5.2. Programme Selection and Consumption Table ............................................. 14
5.2.1. Auxiliary Functions...................................................................................... 15
5.2.2. Starting the Programme ............................................................................. 16
5.2.3. Programme Progress ................................................................................ 17
5.3. Drum Light Information .................................................................................. 17
6. CLEANING AND CARE ................................................................................... 19
6.1. Cleaning the Lint Filter................................................................................... 19
6.2. Emptying the Water Tank............................................................................... 19
6.3. Cleaning the Condenser ................................................................................ 20
6.4. Cleaning the Humidity Sensor ....................................................................... 20
6.5. Cleaning the Inner Surface of the Loading Door ........................................... 21
7. TECHNICAL SPECIFICATIONS ...................................................................... 22
8. TROUBLESHOOTING ..................................................................................... 23
EN - IV
9. AUTOMATIC FAULT WARNINGS AND WHAT TO DO ................................... 25
10. ENVIRONMENTAL PROTECTION AND PACKAGING INFORMATION ...... 26
10.1. Packaging Information ................................................................................. 26
11. DESCRIBING THE ENERGY LABEL AND SAVING ENERGY..................... 26
11.1. Energy Labelling .......................................................................................... 26
11.2. Energy Efficiency ......................................................................................... 27
EN - 1
PRIMARY CONSIDERATIONS
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children must not play with the
appliance. Cleaning and user maintenance must not
be made by children without supervision.
• This tumble dryer is intended only for household
and indoor use. The warranty will be void in case of
commercial use.
• Use this product only for laundry with a label that
indicates it is suitable for drying.
• The manufacturer will not accept responsibility for
damages resulting from incorrect use or transport.
• The service life time of your tumble dryer is 10
years. This is the period during which the spare
parts required for the tumble dryer to operate
properly will be commercially available.
•
ventilation openings.
• Installation and repair of the machine should
only be made by an authorised repair agent.
The manufacturer cannot be held responsible for
damages resulting from un-authorised repairs.
WARNING: Never spray or pour water onto the
dryer to wash it! There is risk of electric shock!
• Leave at least 3 cm of space between the side and
rear walls of the product and above if you plan on
placing your appliance under a worktop.
• Assembly / disassembly for under-counter
installation if neccessary must be done by an
authorised service agent.
EN - 2
• Before installation, check the product for visible
damage. Never install or operate a damaged
product.
• Keep pets away from the dryer.
• Fabric softeners, or similar products, should
be used in accordance with the manufacturers
instructions.
• Remove all objects from pockets such as lighters
and matches.
• The appliance must not be installed behind a
lockable door, a sliding door or a door with a hinge
on the opposite side to that of the tumble dryer, if it
prevents the door from being fully opened.
EN - 3
1. SAFETY INSTRUCTIONS
This section contains safety instructions that will help
protect you from risk of personal injury or property
damage. Failure to follow these instructions will void
any warranty.
1.1. Electrical Safety
• The appliance must not be supplied through an
external switching device, such as a timer, or
connected to a circuit that is regularly switched on
• Do not touch the power plug with wet hands. Always
pull the plug to unplug the product, otherwise, there
will be risk of an electric shock.
• Connect the dryer to a grounded socket with fuse
protection. Have the earth connection installed by
responsible for damages/losses resulting from using
the dryer without an earth connection as required
by local regulations.
• The voltage and the allowable fuse protection are
indicated on the type plate.(For the type plate,
please see Overview)
• Voltage and frequency values indicated on the
type plate must be equal to the mains voltage and
frequency value in your house.
• Unplug the dryer when it is not used for an
extended period, and before installation,
maintenance, cleaning and repair, otherwise, the
dryer may get damaged.
• The plug socket must be freely accessible at all
times after installation.
EN - 4
give you an electric shock. When damaged it must
personnel.
use extension cords, multi sockets or adapters to
connect the dryer to mains power.
1.2. Children's Safety
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved. Children must not play with the
appliance. Cleaning and user maintenance must not
be made by children without supervision.
• Do not leave children unattended near the machine.
• Children might lock themselves in the machine
resulting in risk of death.
• Do not allow children to touch the glass door during
operation. The surface becomes extremely hot and
may cause skin damage.
• Keep packaging material away from children.
• Poisoning and irritation may occur if detergent and
cleaning materials are consumed or come into
contact with the skin and eyes.
