JHD910
9
5. Auxiliary Input Function
To connect a portable audio device (MP3 player, iPOD, etc.) to the JHD910, connect the headphone or
line level output of the device to the 1/8" auxiliary input jack of the JHD910 (5b) using the audio patch
cord (included). Pres AUX (5a) to select auxiliary input mode.
6. Timer
Press TIMER (6) momentarily to directly access timer mode. Briefly press TIMER to start the timer
function, and the “TIMER” icon will flash in the display. Press TIMER again to stop the timer, and the
“TIMER” icon will remain in the display (without flashing). Press the button again briefly to resume the
timer, or press and hold it for three seconds to reset it to zero and to remove the “Timer” icon from the
display.
7. Volume
Briefly press VOL+ (7a) or VOL- (7b) to adjust the volume up or down one step. Press and hold VOL+
or VOL- for more than one second to continuously adjust the volume level until the button is released.
The current volume level (0 to 40) will appear in the display when the volume is adjusted, returning to
the default display three seconds after the adjustment is complete.
8. Setting the Clock
To set the clock to display the current time, press DISP for more than three seconds to enter clock
setting mode, and the time will flash in the display. Press TUN- (8a) to adjust the hours or TUN+ (8b) to
adjust the minutes. When no adjustment is made for ten seconds, the time will be set and normal
operation will resume.
9. Audio and Menu Adjustment
Audio Adjustment
Press AUDIO/MENU (9) momentarily to step through the following audio adjustment options: Bass,
Treble and Balance (left to right). When the desired option appears in the display, press VOL+ (7a) or
VOL- (7b) to adjust that audio feature. When no adjustments have been made for three seconds, the
unit will resume normal operation.
Menu Adjustment
Press AUDIO/MENU for more than three seconds to enter menu adjustment mode and adjust any of
the menu options: When the desired option appears in the display, press VOL+ or VOL- to adjust that
menu option. When no adjustments have been made for three seconds, the unit will resume normal
operation. The following menu options may be adjusted using this feature:
• Beep Confirm (On or Off) - Determines if a beep will be heard each time a button is pressed.
• Operation Region (USA or Euro) - Selects the appropriate operating region.
• Clock Display (12 or 24) - Selects a 12-hour or 24-hour clock display.
• Display Brightness (Low, Mid or High) - Determines brightness level of the display.
• Backlight Color (Amber or Green) - Determines the backlight color of the unit.
• P-VOL [Power on Volume] (On or Off) - Determines if preset Turn On Volume will be set.
• Turn On Volume (0-40) - Selects desired volume level for the unit to assume when turned on.
• WB Alert (On or Off) - Determines if the weather band alert feature is activated.
• Default - Select to return to factory default settings.
NOTE: Underlined option denotes the default setting.
