Asko Appliances, Inc

PO BOX 940609 • Plano • Texas • 75094

Phone 800.898.1879

www.askousa.com

MADE IN

SWEDEN

Type: Built-in

Colors: TouchProof™ stainless steel

PERFORMANCE

Capacity: 17 place settings

Noise level 46 dB(A)

9Spray™ system, PowerZone™ Pots & Pans,

PowerZone™ Plate, PowerZone™ Cutlery

PROGRAMS

Time Heavy Normal

Daily Quick Super Quick

Delicate Eco Mixed

Rinse and Dry Rinse & Hold Lower Wash

Upper Wash

Super Quick program in 15 minutes!

FEATURES

7 Temperatures, Turbo drying™,

Delayed start 1-24 h, Time set, Time saver,

Hidden control, LCD display, Halogen interior

light, Front-adjusting rear leg for easy installa-

tion, Front LED display, Towel bar handle,

Uses as little at 2.6 gals of water in Quick

wash, Energy Star rated, 2 Plus 1 warranty

FLEXIRACKS™

Exclusive height-adjustable upper rack

accommodates:

World’s only 4 rack, 3 rack, 5 basket design,

9” - 7 1/2” items, 5 rows of glasses capacity,

Fold-down stemware shelves, World’s most

usable capacity, Exclusive: World’s tallest load-

ing height at 15 1/4”

Exclusive lower rack accommodates:

15 1/4” dishes, Fold-down tines for storage

flexibility, Wide tine design for large bowls and

platters, Upper & lower rack handles

Middle rack with dedicated wash system

Cutlery basket

ASKO Logic Dishwasher

D5654XXLHS

Exclusive World’s Most Usable Capacity - 17 place settings!

Exclusive 3 rack, 5 basket design

World’s tallest loading height!

Art no: 6301712

Speciﬁcations are subject to change without notice. See installation instructions for additional details.

Technical Data

Electricity 120V,60Hz,15Amp

Water pressure 18 – 176 psi

Heating element 1200 watt

Max loading 1300 watt

Cutout Dimensions

 US METRIC

HEIgHT:*34 3/8˝ – 36 ½˝ 873 – 927 mm

WIDTH: 24˝ 610 mm

DEPTH: 24˝ 610 mm

The electrical and water supplies should enter through the

area indicated by the shaded area. Preferably, they should

come through the right side of the machine. The access

hole must be round and smooth and no bigger than

2˝ (51 mm) in diameter.

*Total height can be reduced by ½˝ by removing upper trim.

˝ – 36 ½˝

(873 mm – 927 mm)

24 7/8˝ (632 mm)

HS Models

22 7/8˝ (581 mm)

49 ½˝

(1257 mm)

Door

BACKSIDEFRONT

High loop

drain hose

6 ¼˝ – 8 ¼˝

(159 mm – 210 mm)

2˝

(50 mm)

24˝

(610 mm)

3˝

(76 mm)

3 3/8˝

(86 mm) 9˝

(229 mm)

Unit Dimensions

US METRIC

HEIgHT:*34 3/8˝ – 36 ½˝ 873 – 927 mm

WIDTH: 24˝ 610 mm

DEPTH: 22 7/8˝ 581 mm

DEPTHW/HANDLE(HS): 24 7/8˝ 632 mm

DEPTHW/DOOROPEN: 49 ½˝ 1257 mm

WEIgHT: 106 lbs 48 kg

Planning & Design: XXL Dishwashers

D5434XXL, D5624XXL, D5634XXLHS, D5654XXLHS, D5894XXLHS

24˝

(610 mm)

24˝

(610 mm)

34 3/8˝ – 36 ½˝ minimum

(873 mm – 927 mm)

2˝

(51 mm)

6 ¼˝ – 8 ¼˝

(159 mm – 210 mm)

4˝

(102 mm)

XXL TALL TANK MODELS
