Asko OM8487S Manuale utente

Instructions for use

OVEN

OM8487S / BO4SM3F3-77

OM8487B / BO4SM3F3-77

OM8487A / BO4SM3F3-78

688917_en_naslovnica_drug_papir.indd EN3688917_en_naslovnica_drug_papir.indd EN3 22. 11. 2021 10:51:4122. 11. 2021 10:51:41

EN Manual EN 3 - EN 32

Pictograms used

Important information

Tip

688917_en_naslovnica_drug_papir.indd EN4688917_en_naslovnica_drug_papir.indd EN4 22. 11. 2021 10:52:0722. 11. 2021 10:52:07

EN 3

YOUR MICROWAVE

Your microwave

Introduction 4

Control panel 5

Description 6

Guide rails/Telescopic guide rails 6

Accessories 6

Door 7

Cooling fan 7

Main functions 7

Keys 8

Navigation 9

Initial use

What to do first 11

Operation

Selecting your function 13

Functions settings mode 13

Progress mode 15

Finish display 15

Changing settings during the progress 16

Use

Functions table 17

Using the microwave 18

Settings menu 20

Plus menu 22

Cooking information 22

Stage cooking 23

Go to manual cooking 24

Programs and Favourites 24

Egg timer 24

Child lock 25

Extra functions 26

Cleaning

Cleaning the appliance 27

Aqua clean 27

Removing and cleaning the guide rails 28

Replacing the oven lamp 28

Solving problems

General 30

Your oven and the environment

Disposing of the appliance and the packaging 32

688917_en_naslovnica_drug_papir.indd EN3688917_en_naslovnica_drug_papir.indd EN3 22. 11. 2021 10:52:0822. 11. 2021 10:52:08

EN 4

Introduction

Congratulations on choosing this Asko microwave.

This product is designed to offer simple operation and optimum

user-friendliness. The microwave has a wide range of settings enabling

you to select the correct cooking method every time.

This manual shows how you can best use this microwave. In addition

to information about operating the microwave, you will also find

background information that may be useful when using the appliance.

Please read the separate safety instructions

carefully before using the appliance!

Read this manual before using the appliance and keep it in a safe

place for future use.

Installation instructions are supplied separately.

YOUR MICROWAVE

688917_en_naslovnica_drug_papir.indd EN4688917_en_naslovnica_drug_papir.indd EN4 22. 11. 2021 10:52:0822. 11. 2021 10:52:08

EN 5

YOUR MICROWAVE

Control panel

1. Function knob (in ‘Off’ position)

2. Defrost programs

3. Programs & Favourites

4. Defrost

5. My microwave

6. Microwave

7. Warming

8. Clean air

9. Aqua clean

10. Display

11. Selection knob

12. On/off key and stop key (cancel)

13. Light key

14. Timer key

15. Navigation key left

16. Navigation key right

17. Plus key

18. Child lock key (lock key)

19. Confirm key (+ 30 seconds microwave (6) time)

Note:

The keys respond best if you touch them with a large area of your

fingertip. Every time you press a key during use, a short acoustic signal

will sound.

12 13 14 15 16 17 18 19

1 10 116 7 8 95432

688917_en_naslovnica_drug_papir.indd EN5688917_en_naslovnica_drug_papir.indd EN5 22. 11. 2021 10:52:0822. 11. 2021 10:52:08

EN 6

YOUR MICROWAVE

Description

1. Control panel

2. Oven levels

3. Oven door

4. Door handle

Guide rails/Telescopic guide rails

• The oven has four or five guide rails (Level 1 to 4/5), depending on

the model. Level 1 is mainly used in combination with bottom heat.

The two upper levels are mainly used for the grill function.

• Place the oven rack, baking tray or steam dish in the gap between

the guide rail sliders.

• A number of shelf levels can have fully-retractable telescopic guide

rails, depending on the model.

▷Pull the telescopic guide rails out of the oven cavity completely

and place the oven rack / baking tray / steam dish on them.

Then slide the oven rack / baking tray / steam dish on the

telescopic guide rails, back into the oven cavity.

▷Only close the oven door when the telescopic guide rails have

been returned completely back into the oven cavity.

Accessories

Your appliance is accompanied by a range of accessories, depending

on the model. Only use original accessories; they are specially suited

toyour appliance. Be sure that all the accessories that are being used

are able to withstand the temperature settings of the chosen oven

function.

Level 1

Level 2

Level 3

Level 4

688917_en_naslovnica_drug_papir.indd EN6688917_en_naslovnica_drug_papir.indd EN6 22. 11. 2021 10:52:0822. 11. 2021 10:52:08

EN 7

Note: not all accessories are suitable/available for every appliance

(itmay also differ by country). When purchasing, always provide the

exact identification number of your appliance. Please see the sales

brochures or check online for more details about optional accessories.

Accessories that can be supplied with your appliance (depending on the model)

Glass baking tray; for microwave and oven use.

• NOT suitable for pyrolysis cleaning.

Door

• The door switches interrupt the operation of the microwave when

the door is opened during use. The microwave continues operating

when the door is closed.

• This oven has a ‘Soft close door system’. When closing the oven

door, this system dampens the movement, from a certain angle, and

silently closes the oven door.

Cooling fan

• The appliance is equipped with a cooling fan that cools the casing

and control panel.

Main functions

With the function knob you can select the main functions of your

microwave.

Setting Description

Off/standby mode

My microwave

Programs and favourites

Favourites

Programs

YOUR MICROWAVE

688917_en_naslovnica_drug_papir.indd EN7688917_en_naslovnica_drug_papir.indd EN7 22. 11. 2021 10:52:0922. 11. 2021 10:52:09

EN 8

YOUR MICROWAVE

Defrost

Manual defrost

Microwave

Clean air

Warming

Aqua clean

Defrost programs

Keys

In the table below you can find the discription of the different keys.

Keys Description of the keys

On/off key and stop key:

- Press short: cancel operation or go one step back in

the menu.

- Press long: turn the appliance off or on.

Light key:

- To turn the cavity light on or off.

Egg timer

- The egg timer can be used independent of the oven

function.

- The longest possible timer setting is 23:59.

Navigation key left

- To move the active area to the left.

688917_en_naslovnica_drug_papir.indd EN8688917_en_naslovnica_drug_papir.indd EN8 22. 11. 2021 10:52:0922. 11. 2021 10:52:09

EN 9

Navigation key right

- To move the active area to the right.

Plus key

- To open or exit the settings menu (in standby-mode).

- To open or exit the plus menu with the extra options

possible at that moment (in on-mode).

Child lock key

- Press and hold the left navigation key and right

navigation key simultaniously to lock the appliance.

Confirm key

- To confirm all the white settings/elements in the

screen.

- Add 30 seconds microwave time (microwave

function).

Navigation

active area

stop key confirm keyfunction knob selection knobnavigation keys

By turning the function knob away from the 0-position, the icon of the

chosen main function is lit. The display will show the icon and name

of the activated function for about 1,5 seconds. Next you will see the

chosen main function and sub-function at the top of the display in the

feedback bar. Also the function settings mode will become active (grey

background). In this activated area you can select your settings using

the selection knob.

750 W 1:00

MICROWAVE 14:30

YOUR MICROWAVE

688917_en_naslovnica_drug_papir.indd EN9688917_en_naslovnica_drug_papir.indd EN9 22. 11. 2021 10:52:0922. 11. 2021 10:52:09

EN 10

YOUR MICROWAVE

Within every menu the navigation is as follows:

• Use the navigation keys or press the selection knob to move the

active area (grey background).

• The setting in the active area can be changed by turning the

selection knob (left = decrease, right = increase). The setting will be

saved automaticallly.

• When all elements in the screen are set, then confirm these settings

by pressing the confirm key (this key will start blinking when it is

possible to start the program).

• Press the stop key to go one step back in the menu.

At the top of the display is a feedback bar. This bar shows where you

are in the menu and what setting you are changing. Functions / settings

are separated with a vertical line.

SETTINGS l GENERAL l SOUND l KEY SOUND

PROGRAMS l ... l CHICKEN

688917_en_naslovnica_drug_papir.indd EN10688917_en_naslovnica_drug_papir.indd EN10 22. 11. 2021 10:52:0922. 11. 2021 10:52:09
