Aspen ASPA-400 Manuale utente
ASPA-400
Smart Air Purifier
1
What’s in the BoxTable of Contents
What’s in the Box 1
Safety Precautions 2
Technical Specifications 3
LED Information 4
Setup / Getting Started 6
Setup / Download Aspen Home App 8
Setup / Pairing Your Device 9
Setup / Inside The App 11
How To Replace The Filter 13
Care & Maintenance 15
FAQ 17
FCC Statement 19
Warranty 20
1. Air Purier
2. 3 in 1 HEPA Filter
3. Front Panel
4. Instruction Manual
Instruction
1
2
3
4
2 3
Safety Precautions Technical Specifications
Product specifications
Real-time display of air quality conditions
The following safety precautions and instructions must be read
carefully and observed the product is used!
.
Model ASPA-400
Related voltage frequency 120V~/60Hz
Rated power 60W
Rated current 0.85A
CADR (Particulate matter) 232CFM
Noise 56dB
Net weight 6.3kg / 14lbs
Gross weight 8.4kg / 18.5lbs
Product size 382x200x649mm / 1.25’ x 0.65’ x 2.13’
Packaging Size 475x285x765mm / 1.5’ x 1’ x 2.51’
Work environment Temperature: 14ºF ~ 104ºF(-10ºC ~ -40ºC) humidity: <
95%RH
PM2.5 value Air quality PM2.5 Air quality
indicator
Wind speed gear
0-12 Excellent Green Speed gear
13-35 Good Blue 1
36-55 Medium Yellow 2
>55 Poor Red 3
Prohibitory Sign
The behaviors with this sign must be prohibited, otherwise it may cause
product damage or endanger the user’s personal safety.
Warning Sign
The behaviors with this sign must be operated in strict accordance with
the requirements, otherwise it may cause product damage or endanger
the user’s personal safety.
Attention Sign
The behaviors with this sign must be paid attention to, otherwise it may
cause product damage or other losses due to improper operation.
Please do not touch
the power plug with wet
hands.
Please regularly clean
the machine
Please do not block the
air inlet/outlet.
Only the 120V power
sockets are
Please do not use the
machine in any place
with much oil fume or
high humidity.
Please do not put it
close to or on any heat
source (such as a re-
place, stove or a place
with ammable gases).
Please do not rinse the
high-efciency compos-
ite lter with water.
Please be careful when
cleaning the
This machine shall not
be used by people with
disabilities, percep-
tual disturbance or
dysgnosia or children
alone, unless they use
it under the supervision
and guidance of safety
director on the site.
Please do not unplug
the power cord from
the power socket when
cleaning the air purier
or leaving it unused.
Otherwise, it may cause
electric shock due to
poor insulation or re
due to short circuit.
4 5
LED Information LED Information
LED Ring Color Air Quality
Green
Excellent Air Quality
Blue
Good Air Quality
Yellow
Moderate Air Quality
Red
Bad Air Quality
LED Ring
On/Smart(Auto)
Tap once to turn on the unit
and set it to Smart Mode
(Glowing LEDs)
Low
Tap second time to set
to Low speed
(Single Solid LED)
Medium
Tap third time to set to
Medium speed
(2 Solid LEDs)
High
Tap set to set to High speed
(3 Solid LEDs)
Turn Off/Standby
Tap and hold for 3 seconds till
the power icon turns red.
Replace Filter
Flashing red light will indicate
new lter is needed
6 7
Setup / Getting Started Setup / Getting Started
1. Pull the panel off the device by pulling from the top.
2. Remove the new lter from inside the device to remove
plastic wrapping from lter.
3. After plastic wrapping is removed from the lter, place the
lter back inside the device.
4. Place the panel back on top.
5. Connect the power cord to a power outlet
6. Push the control button to power on the unit. A red light
will indicate the device is off/standby mode
7. Now your device is ready to be paired to the
Aspen Home App
1
3
2
4
5
6
8 9
Setup / Download Aspen Home App
• Download the Aspen Home App form the Apple App
Store or Google Play Store.
• Create a new account with your email address or log-
in to your existing account.
Setup / Pairing Your Device
1. Press and hold the control button for 7 – 10 seconds to start
pairing (Ignore rst beep around 3 seconds)
2. The device will beep a few times and the LED will begin to
ash red and blue. This means pairing mode is now active
and you can pair to the app on your phone.
3. Follow the instructions inside the app to complete the
pairing process
10 11
Setup / Inside The App
Inside the app you will be able to see your air quality, adjust
your fan speed, set a schedule to turn the fan on and/or off,
and reset your lter life after replacement
Air Quality
Color
know your
indoor air
quality right
in your phone
with color
indicator
Timer
Convenient-
ly set timer
anywhere
using Aspen
Home App
Smart Auto
Speed
Auto fan
speed
changes
according
the indoor
air quality
Filter
Reset
Reset lter
in App with-
out a hassle
nding a pin
to reset
Setup / Pairing Your Device
4. Open the App from the home screen of your phone
5. Tap the “Add Device” button
6. Select the device you want to pair with and follow on screen
instructions to complete pairing
7. You are now nished pairing your device. You can begin to
control the device through the Aspen Home app.
12 13
Setup / Inside The App
See what your air quality is like
Turn On/Off Fan, control fan speed, and
setup a schedule
Turn On/Off the child lock setting and the
device LED light
A 7 Day line chart shows the Fine parti-
cles levels in the past week
Check your lter life and reset your lter
after installing a new lter and order a
new lter.
Don’t know when to order a new lter,
check out our lter subscription service
and let us take care of all your new lters.
How To Replace The Filter
1. Pull the panel off the device by pulling from the top.
2. Remove the new lter from plastic wrapping
1 2
14 15
Cleaning Instruction
To avoid scratching the control panel, do not use abrasive/
caustic cleaning solutions or scrubbing pads. With the unit
unplugged, dampen a clean towel lightly with soap and water to
clean the control panel, then dry gently with a soft cloth or paper
towel. Glass cleaner (e.g. Windex) is also OK. To avoid damag-
ing electronic components, DO NOT allow liquid to seep into the
unit.
PrelterCleaning
The white mesh layer on the front of the lter, known as the
prelter, captures large dust and hair. This layer is attached to
the True HEPA lter. This prelter can be vacuumed in place to
maintain efcient operation of the unit.
Care & Maintenance
How To Replace The Filter
3. After plastic wrapping is removed from the lter,
place the lter back inside the device.
4. Place the panel back on top.
5. Push the control button to power on the unit.
6. Your new lter is ready to be enjoyed
34
5
16 17
FAQ
Why doesn’t the device turn on?
Make sure the device is properly plugged into an electrical
socket and sure the lter has been installed correctly and the
panel is secure
HowdoIresetthelterindicatorlights?Iputina
newlterbuttheredlightisstillilluminated.
Please note that the lter can only be reset in the app. After
replacing the lter, follow the instructions in the app to reset the
lter life. This will turn the light green.
Why isn’t any air coming out or the device is
making an unusual sound?
Please check to make sure the lter has been removed from the
plastic packaging or there isn’t any objects blocking the intake of
the air ow.
HowdoIndoutwhatelectricalspecicationsmy
unit needs?
Please refer to the rating label on the back of the unit. Here you
will nd your unit’s voltage:
hertz, amps, and outlet requirements.
Care & Maintenance
Replacing The Filter
The Filter Indicator has four lights: Green, Blue, Yellow, and
Red. The Green light will be illuminated for most of the life of
the lter. The yellow light will come on shortly before your lter
should be re-placed. This is the ideal time to order a new lter.
You may order a new lter
at www.theaspen.com/accessories or by calling (877) 365-3464
The Red light will be illuminated when it is time to replace the
lter.
The lters used in Aspen Air Puriers are not designed to be
washed, cleaned, or otherwise reused. Over time, the lters
become overloaded with particles, decreasing their ltration
performance. We recommend regular lter replacements to
extend the life of your air purier and maximize performance.
