ASROCK Jupiter H610 Manuale utente

Version 1.0

Published March 2023

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

English

H610D4-P1

Motherboard Layout

DC Jack

HDMI1

H610D4-P1

RoHS

DDR4_B1

DDR4_A1

USB 3.2 Gen1

USB_TC_1

BIOS

ROM

M2_3

M2_2

M2_1

M2_3_CT1_1

M2_2_CT1_1

M2_1_CT1_1

CPU_FAN1

CMOS

Battery

COM1

MONO1

CHA_FAN1

SATA1

Mic In

Power

Button

USB 3.2 Gen1

T: USB_1

B: USB_TC_2

USB 2.0

T: USB_2

B: USB_3

Headset

CLRMOS1

RJ-45

USB 3.2 Gen1

T: USB_6

B: USB_7

USB 3.2 Gen1

T: USB_4

B: USB_5

DP1 DP2

LAN

CI1

English

No. Description

1 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1)

2 CPU Fan Connector (CPU_FAN1)

3 Chassis Fan Connector (CHA_FAN1)

4 2.5W Mono Out Speaker Header (MONO1)

5 SATA3 Connector (SATA1)

6 Clear CMOS Jumper (CLRMOS1)

7 Chassis Intrusion Header (P305)

8 COM Port Header (COM1)

English

H610D4-P1

1.4 Front Panel

No. Description No. Description

1 Power Button (SW1) 4 USB 3.2 Gen1 Type-C Port (USB_TC_2)

2 USB 2.0 Ports (USB_2_3) 5 Microphone Input

3 USB 3.2 Gen1 Type-A Port (USB_1) 6 Headphone/Headset Jack

135

English

1.5 Rear Panel

No. Description No. Description

1Display Port (DP1) 5 USB 3.2 Gen1 Type-A Ports (USB_4_5)

2 Display Port (DP2)*(co-lay D-SUB) 6 LAN RJ-45 Port*

3 HDMI Port 7 USB 3.2 Gen1 Type-A Ports (USB_6_7)

4 USB 3.2 Gen1 Type-C Port 8 DC Jack**

(USB_TC_1)

* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection

Blinking Data Activity Green 100Mbps connection

On Link Orange 1Gbps connection

** Please use a 19V power adapter for the DC jack. is jack accepts dual barrel plugs with an inner diameter of 2.5

mm and an outer diameter of 5.5 mm, where the inner contact is +19 (±10%) DC and the shell is (centre positive).

Please use a 90W adapter for the 35W CPU and a 120W adapter for the 65W CPU.

is motherboard is available with support for either 4-pin ATX 19V power or DC-in power supplies. Please do

not use two kinds of power supplies at the same time! Doing so may damage the motherboard components and

devices. When you use the DC-in power adapter, please use the onboard SATA power connector to get the power

for HDDs.

ACT/LINK LED

SPEED LED

LAN Port

1 3 4 65 7 8

Chapter 1 Introduction

ank you for purchasing H610D4-P1 motherboard. In this documentation,

Chapter 1 and 2 contains the introduction of the motherboard and step-by-step

installation guides.

1.1 Package Contents

• H610D4-P1 Motherboard

• 1 x Quick Installation Guide

• 1 x SATA Data with Power Cable (Optional)

• 2 x Screws for M.2 Sockets (Optional)

• 1 x Screw for WiFi Module (Optional)

English

H610D4-P1

Chapter 1 Introduction

ank you for purchasing H610D4-P1 motherboard. In this documentation,

Chapter 1 and 2 contains the introduction of the motherboard and step-by-step

installation guides.

1.1 Package Contents

• H610D4-P1 Motherboard

• 1 x Quick Installation Guide

• 1 x SATA Data with Power Cable (Optional)

• 2 x Screws for M.2 Sockets (Optional)

• 1 x Screw for WiFi Module (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice.

English

1.2 Specications

Platform • 6.7-in x 6.8-in, 17.0 cm x 17.2 cm

• Solid Capacitor design

CPU • Supports 13th Gen & 12th Gen Intel® CoreTM Processors

(LGA1700)

• 4 Power Phase design

• Supports Intel® Hybrid Technology

• Supports Intel® Turbo Boost Max 3.0 Technology

Chipset • Intel® H610

Memory • Dual Channel DDR4 Memory Technology

• 2 x DDR4 SO-DIMM Slots

• Supports DDR4 non-ECC, un-buered memory up to 3200*

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

• Max. capacity of system memory: 64GB

• Supports Intel® Extreme Memory Prole (XMP) 2.0

Expansion

Slot

• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module

and Intel® CNVi (Integrated WiFi/BT)

Graphics • Intel® UHD Graphics Built-in Visuals and the VGA outputs

can be supported only with processors which are GPU

integrated.

• Intel® XeGraphics Architecture (Gen 12)

• ree graphics output options: 1x HDMI, 1 x DisplayPort 1.4

(DP1), 1 x DisplayPort 1.2 (DP2)

• Supports Triple Monitor

• Supports HDMI 2.1 TMDS Compatible with max. resolution

up to 4K x 2K (4096x2160) @ 60Hz

• Supports DisplayPort 1.4 with DSC (compressed) max.

resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @

120Hz

• Supports DisplayPort 1.2 with DSC (compressed) max.

resolution up to 4K x 2K (4096x2304) @ 60Hz

English

H610D4-P1

• Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and

DisplayPort 1.4/1.2 Ports

Audio • Realtek ALC269 Audio Codec

• 1 x MIC IN

• 1 x Headset/Headphone

LAN • Gigabit LAN 10/100/1000 Mb/s

• Giga PHY Intel® I219V

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Front

Panel I/O

• 1 x Power Button

• 1 x Headphone/Headset Jack

• 1 x USB 3.2 Gen1 Type-A Port (Support ESD Protection)

• 1 x USB 3.2 Gen1 Type-C Port (Support ESD Protection)

• 2 x USB 2.0 Ports (Supports ESD Protection)

• 1 x Microphone Input Jack

Rear Panel

I/O

• 1 x DC Jack (Compatible with the 19V power adapter)*

* Please use 90W power adapter for 35W CPU and 120W power

adapter for 65W CPU.

• 1 x HDMI Port

• 2 x DisplayPort*

* (1 x DP co-lay D-SUB)

• 4 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)

• 1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection)

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

Storage • 1 x SATA3 6.0 Gb/s Connector, supports NCQ, AHCI and Hot

Plug

• 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280

PCIe Gen4x4 (64 Gb/s) mode*

• 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2280 PCIe

Gen3x4 (32 Gb/s) mode*

* Supports NVMe SSD as boot disks

English

Connector • 1 x COM Port Header

• 1 x Chassis Intrusion Header

• 1 x CPU Fan Connector (4-pin)

* e CPU Fan Connector supports the CPU fan of maximum 1A

(12W) fan power.

• 1 x Chassis Fan Connector (4-pin) (Smart Fan Speed Control)

• 1 x Mono-Out Header

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

• ACPI 6.0 Compliant wake up events

• SMBIOS 2.7 Support

Hardware

Monitor

• Fan Tachometer: CPU, Chassis Fans

• Quiet Fan (Auto adjust chassis fan speed by CPU temperature):

CPU, Chassis Fans

• Fan Multi-Speed Control: CPU, Chassis Fans

• CASE OPEN detection

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

OS • Microso® Windows® 10 64-bit / 11 64-bit

Power • 1 x DC Jack (Supports 19V DC Power Adapters)

Certica-

tions

• FCC, CE

• ErP/EuP ready (ErP/EuP ready power supply is required)

Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using third-party

overclocking tools. Overclocking may aect your system’s stability, or even cause damage to

the components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.
