Patio Fireplace Grill
Instruction Manual
Made in China
©2004 World Factory,Inc.®
Distributed by:
World Factory, Inc.®
Southlake, TX 76092
IFYOUHAVEANYPROBLEMS OR QUESTIONS CONCERNINGTHIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER, CONTACTCUSTOMER SERVICE AT
1-888-424-3354
Please keep this instruction manual for future reference
IFYOUHAVE ANYPROBLEMS OR QUESTIONS CONCERNINGTHIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER,CONTACTCONSUMER SUPPORTAT
1-888-424-3354
IFYOUARE ASTORE MANAGER OR EMPLOYEE INNEEDOF ASSISTANCE CALL
1-888-851-5569
PLEASE HAVE YOUR STORE NUMBER READY
OR
Limited Warranty
World Factory, Inc.®Products for Home Use
World Factory, Inc.®(Seller) warrants to the original Buyer only, that each Astonica™ Product will be
free from defects in material and workmanship for a period of one (1) year from date of purchase.
SELLER’S SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE,
WHICH ARE DEFECTIVE IN MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY
THE SELLER WHICH HAVE BEEN MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR
INDIRECTLY FROM REPAIRS OR ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS;
IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT ARE NOT COVERED BY THIS LIMITED
WARRANTY. This warranty does not apply to damage, heat-induced coloration changes, scratching or
alteration due to normal use or weathering. To make a claim under this Limited Warranty, you must return
the complete product with proof of purchase, transportation prepaid, to any World Factory, Inc.®authorized
service center. Call 1-888-424-3354 for the location of the nearest authorized service center.
Additional Limitations
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY OR CONSUMABLE ITEMS
RELATED TO THIS PRODUCT. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO
ONE (1) YEAR FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE FORANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LIABILITY
FOR LOSS OF PROFITS, ARISING FROMTHE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such
provision shall not affect any other provision herein, this Limited Warranty shall be construed as if
such invalid and/or unenforceable provision had never been contained herein.
This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all
prior agreements, arrangements, or understandings between the parties relating to product warranty.
PARTS PACKED LIST
PART # DESCRIPTION QUANTITY
A 1Fire Pit Bowl
B 4Legs
C 1Cooking Grate
D 4Outer Rails
E 1Screen Lid, Upper
G 1Screen Lid, Lower with Handle
H 1Screen Lid, Lower
Screen Lid, Upper with Handle
F 1
Lid Lifter & Poker
I 1
1
4
ASSEMBLY INSTRUCTIONS
5.(SEE FIGURE 5) Use lidlifter (I) toopenthe
screenlids.
4.(SEE FIGURE 4) Connectthe upper (E) and
lower (H) screenlids together, fasten tothe
twobrackets onthe sides of firepitbowl
usingspacer (7), twoscrews (2), washer (6)
andnuts (4).
FIGURE 4
2
7
6
E H
4
FIGURE 5
AA
D
G
I
E
B
C
I
H
F
Carefullyremovethe contents fromthepackage.
If any parts aremissingdonotattempt touse the productuntil
theyhavebeenobtainedandcorrectlyinstalled.
IFYOUHAVE ANY PROBLEMS OR QUESTIONS CONCERNINGTHIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER.
CONTACT CUSTOMER SERVICE AT
1-888-424-3354.
Carefullyremove the contents fromthepackage.
If any parts are missingdonot attempttouse the product until
they havebeenobtainedandcorrectlyinstalled.
HARDWARE LIST
PART # DESCRIPTION QUANTITY
12Screws
12Screws For Bracket
26Flat Head Screws
314Nuts
46Acorn Nuts
520Washers
Wrench
62
71
8Spacer
2 3
ASSEMBLY INSTRUCTIONS
1.(SEE FIGURE 1) Locate firepit bowl (A), attach
four legs (B) to firepit bowl (A) usingscrews
(1), washers (6) andnuts (4).
2.(SEE FIGURE 2) Locate three outer rails (D),
insertends of rails together, attachrails
to firepit bowl (A) atone time using screws
(1), washers (6) andnuts (4). Place cooking
grate (C) ontefire pit bowl.
FIGURE 1
FIGURE 2
3.(SEE FIGURE 3) Assemble screenlid(E) and
screen lid(F) usingscrews (3), washers
(6) and nuts (5). Note the screws (3) go
upwards withthe nuts (5) on top. Assemble
screen lid(G) and screenlid(H) using
screws (3), washers (6)andnuts (5). Note
thescrews (3)godownwards withthe
nuts (5) on the top.
FIGURE 3
A
A
B
1
1
6
6
4
4D
C
1
2 3 4
5 6 7 8
CAUTION
• Donot use liquidfirestarter, charcoal lighter or anyother combustible liquidto
startthe fire.
• Readandfollow all safetyinstructions specifiedby the manufacturer of the charcoal
and/or firestarters youareusing.
WARNING PRACTICE FIRE SAFETY AT ALL TIMES
1. USE WITHADULT SUPERVISIONONLY. KEEP OUT OF THE REACHOF CHILDREN.
2. DONOT LEAVE UNATTENDEDWHILE BURNINGOR SMOLDERING
3. DONOT PLACE NEAR FLAMMABLE OR COMBUSTIBLE MATERIALS WHENBURNING.
4. OUTDOOR USE ONLY.
5. KEEP AWAYFROMOVERHANGS, TREES, ETC.
6. DONOT USE ONBALCONIES OR WOODDECKS.
7. KEEPAFIRE EXTINGUISHER WITHINREACHAT ALLTIMES
8. TAKE CARE NEVER TOTOUCHMETAL SURFACES AFTER AFIRE HAS BEENLIT FOR AT LEAST
3-4 HOURS AFTER FIRE IS OUT OR UNTILTHOROUGHLYCOOLED.
THENWEAR GLOVES TOPROTECT YOURSELF.
E
G
F
H
