Quick
Start Guide
E3701
Navigation Map
for R300/R600/R700
Quick
Start Guide
e3701_pnd map data card.indd 1 2008.3.20 9:33:00 AM
2
Using the Navigation Map
R300
1. Insert the microSD card into the microSD
card slot ( ) on top of the device when the
device is either turned off or in sleep mode.
2. Switch the power ON ( ) to turn on the
device, or press the sleep mode button ( )
to wake up the device.
3. From the main screen, tap Navigation and
follow the screen instructions.
1
2
3
1
2
3
Note
If you turn on or wake up the device without inserting the microSD card into the microSD card slot, when tap Navigation
from the main screen, a warring message appears: “Operation failed! Insert the SD card or remove USB and try
again”. You may insert the microSD card and try again.
e3701_pnd map data card.indd 2 2008.3.20 9:33:01 AM
3
Using the Navigation Map
8
2
3
2
3
R600
1. Insert the microSD card into the adapter.
2. Insert the adapter with the microSD card into the SD card
slot ( ) on the right side of the device when the device is
switched off or when the device is in sleep mode.
3. Switch the power ON ( ) to turn on the device, or press the
sleep mode button ( ) to wake up the device.
4. From the main screen, tap Navigation and follow the screen
instructions.
1
1
Note
If you turn on or wake up the device without inserting the
microSD card into the card slot, when tap Navigation
from the main menu, a “Map initialisation error” message
appears: couldn’t nd any map les!. Follow step 1 to
insert the microSD card into the card slot, tap OK from the
error message to go back to the main menu, and then tap
Navigation.
e3701_pnd map data card.indd 3 2008.3.20 9:33:01 AM
4
Using the Navigation Map
2. From the main menu, tap Navigation to navigate using the map in the microSD card.
Note
If you insert the microSD card when the device is in sleep
mode, press the Sleep Mode Button ( ) and wait for
a few seconds until the main menu appears, then tap
Navigation to proceed.
If you insert the microSD card when the device is switched
off, switch the power ON ( ) to turn on the device, then
tap Navigation after the main menu appears.
2
3
2
3
R700
1. Insert the microSD card into the microSD card slot ( )
on the left side of the device.
Note
You can insert the microSD card into the device when it is in sleep mode or
is switched off.
1
1
e3701_pnd map data card.indd 4 2008.3.20 9:33:03 AM
