Asus Eee PC 2G Series Manuale operativo

Quick Use Guide

E4123

15G06Q062000

Windows® XP Edition

Quick Use Guide - 2

Powering on your Eee PC

These are only quick instructions for using your Eee PC. Read the full

manual for detailed information.

1. Install the battery pack 2. Connect the AC power

adapter

1

1

2

1

3

2

3. Turn ON the Eee PC

Remember to fully charge the battery before ﬁrst use and

whenever it is depleted to prolong battery life.

Status Indicators

Status indicators represent various hardware/software conditions.

Power Indicator

Battery Charge Indicator

When you open the display panel, do not force it down to the

table or else the hinges may break! Never lift the Eee PC by the

display panel!

Solid State disk (SSD)

Indicator

Wireless Indicator

Damage may occur if you

use a different adapter

to power the Eee PC.You

may damage both your

battery pack(s) and the

Eee PC with a faulty AC-DC

adapter.

Quick Use Guide - 3

Shutdown

Do the following instructions to turn down your Eee PC.

1. Click the start button to display the start menu.

2. Click Turn Off Computer.

1

2

3. Select Turn Off to power off your Eee PC.

3

Quick Use Guide - 4

Launching for the First Time

For the ﬁrst time you start your Eee PC, the Windows wizard

will launch automatically and lead you through setting up your

preferences and some basic information. Follow the wizard

instructions to ﬁnish the initialization.

Conguring a network connection

Wireless Network Connection

1. Double-click the crossed wireless network icon in the

Notiﬁcation area.

2. Select the wireless access

point you want to connect

to from the list and click

Connect to build the

connection.

If you cannot ﬁnd the desired access point, click Refresh

network list in the left pane and search in the list again.

If the wireless connection icon does not show in the Notiﬁcation

area. Activate the wireless LAN function by pressing +

(<Fn> + <F2>) before conﬁguring a wireless network connection.

Quick Use Guide - 5

3. When connecting, you may

have to enter a password.

4. After a connection has been

established, the connection

is shown on the list.

5. You can see the wireless

network icon in the

Notiﬁcation area.

The wireless connection icon disappears when you Press +

(<Fn> + <F2>) to disable the WLAN function.

Quick Use Guide - 6

Local Area Network

To establish a wired network, follow the instructions below:

Using a dynamic IP:

1. Right-click the network icon

with a yellow warning triangle

on the Windows® taskbar

and select Open Network

Connections.

3. Click Internet Protocol

(TCP/IP) and click Properties.

2. Right-click Local Area

Connection and select

Properties.

4. Click Obtain an IP address

automatically and click OK.

Quick Use Guide - 7

5. Click Create a new

connection to start the New

Connection Wizard.

6. Click Next.

7. Select Connect to the

Internet and click Next.

8. Select Set up my

connection manually.

9. Select your connection type

and click Next.

10. Enter your ISP Name and

click Next.

Quick Use Guide - 8

11. Enter your User name and

Password. Click Next.

12 Click Finish to ﬁnish the

conﬁguration.

13. Enter your user name and

password. Click Connect to

connect to the Internet.

Using a static IP:

1. Repeat the step 1–3 of Using a dynamic IP to start the static IP

network conﬁguration.

2 Click Use the following IP address.

3. Enter the IP address, Subnet mask and Gateway from your

service provider.

4. If needed, enter the preferred DNS Server address and

alternative address.

5. After entering all the related values, click OK to build the

network connection.

Contact your Internet Service Provider (ISP) if you have problems

connecting to the network.
