Asus Eee PC MK90H Manuale utente

E4889

15G06Q162100

Quick Start Guide

netpal

Disney Netpal Quick Start Guide

DO NOT expose

to dirty or dusty

environments.

DO NOT expose

to strong

magnetic or

electrical ﬁelds.

DO NOT expose

to or use near

liquids, rain, or

moisture.

DO NOT press or touch

the display panel.

DO NOT place on

uneven or unstable

work surfaces.

DO NOT place or

drop objects on

top.

Safety Precautions

The following safety precautions will increase the life of the Disney Netpal.

Follow all precautions and instructions. Except as described in this manual,

refer all servicing to qualiﬁed personnel.

Disconnect the AC power before cleaning.Wipe the Disney Netpal

using a clean cellulose sponge or chamois cloth dampened with a

solution of nonabrasive detergent and a few drops of warm water

and remove any extra moisture with a dry cloth.

DO NOT leave the

Disney Netpal on your

lap or any part of the

body.

Ambient

temperatures

between 5°C (41

°F) and 35°C (95°

CAUTION! ELECTRICALLY OPERATED PRODUCT.THIS IS NOT A TOY.

TO AVOID RISK OF ELECTRIC SHOCK OR FIRE, IT SHOULD NOT BE

PLAYED WITHOUT ADULT SUPERVISION OR PLACED WHERE SMALL

CHILDREN CAN REACH.

Disney Netpal Quick Start Guide

Powering on your Disney Netpal

These are only quick instructions for using your Disney Netpal.

1. Connect the AC power adapter

• When you open the display panel, do not force it down to the table

or else the hinges may break! Never lift the Disney Netpal by the

display panel!

• Only use battery packs and power adapters supplied with this

Disney Netpal or speciﬁcally approved by the manufacturer or

retailer for use with this model or else damage may occur to the

Disney Netpal.The output voltage of this adapter is +12Vdc, 3A.

Remember to fully charge the battery before ﬁrst use and whenever

it is depleted to prolong battery life.

2. Turn ON the Disney Netpal

Damage may occur if you use

a different adapter to power

the Disney Netpal.You may

damage both your battery

pack(s) and the Disney Netpal

with a faulty AC-DC adapter.

Disney Netpal Quick Start Guide

First-time Startup

For the ﬁrst time you start your Disney Netpal, the Windows wizard will

launch automatically and lead you through setting up your preferences

and some basic information.

Follow the wizard instructions to ﬁnish the initialization:

2. Select your system settings by

specifying the region you are

in, the language you use and

the keyboard type you use.

Click Next to continue.

1. The Welcome message

appears. Click Next to

continue.

3. Select the time zone you are

in and click Next to continue.

4. Follow the onscreen instructions to ﬁnish the initialization and to

Disney Netpal Quick Start Guide

Parental Control

Disney Desktop helps you keep your child safe from inappropriate web

content and applications. It allows you to conﬁgure how you want your

child to use this Disney Netpal, including programs which they can and

cannot use and a safe environment for your children when they go online.

Setting the master password and

creating an account

1. Double-click the Parental Control icon on the

desktop to start the program.

After the Windows initialization, you will

be asked to conﬁgure Parental Control.

You can conﬁgure the settings whenever

you want by clicking the shortcut on the

desktop.

2. Click Windows Control Panel

on the left pane to set the

administrator password.

For service and support, visit our multi-language web site at

http://support.asus.com.

3. Refer to the User Manual for the following instructions to ﬁnish the

Disney Parental Control conﬁguration.

Disney Netpal Quick Start Guide

Wireless network connection

1. Double-click the crossed wireless network icon in the

Notiﬁcation area.

3. When connecting, you may have to

enter a password.

2. Select the wireless access point

you want to connect to from the

list and click Connect to build the

connection.

If you cannot ﬁnd the desired access

point, click Refresh network list in

the left pane and search in the list

again.

If the wireless connection icon does not show in the Notiﬁcation

area. Activate the wireless LAN function by pressing

(<Fn> + <F2>) before conﬁguring a wireless network connection.

4. After a connection has been

established, the connection is shown

on the list.

5. You can see the wireless network

icon in the Notiﬁcation area.

The wireless connection icon disappears when you Press

(<Fn> + <F2>) to disable the WLAN function.

Disney Netpal Quick Start Guide

Wired network connection

To establish a wired network, follow the instructions below:

Using a dynamic IP:

1. Right-click the network icon with a

yellow warning triangle on the

Windows® taskbar and select Open

Network Connections.

3. Click Internet Protocol

(TCP/IP) and click Properties.

2. Right-click Local Area Connection

and select Properties.

4. Click Obtain an IP address

automatically and click OK.

Disney Netpal Quick Start Guide

Using a static IP:

1. Repeat the step 1–3 of Using a dynamic IP to start the static IP

network conﬁguration.

2 Click Use the following IP address.

3. Enter the IP address, Subnet mask and Gateway from your service

provider.

4. If needed, enter the preferred DNS Server address and alternative

address.

5. After entering all the related values, click OK to build the network

connection.

Contact your Internet Service Provider (ISP) if you have problems

connecting to the network.

Disney Netpal Quick Start Guide

Connecting removable devices

You can connect removable devices based on your needs.

1 2

Memory Card Slot

USB Flash Memory Disk

USB External Hard Disk DriveUSB External Optical Disk Drive

SD (Secure Digital)

MiniSD (with SD adapter)

MMC (Multimedia Card)

MMC Plus

RS-MMC (Reduced Size) (with MMC adapter)

USB Port (2.0/1.1)

microSD

SD Adapter

Disney Netpal Quick Start Guide

WLAN Setup FAQ

If you follow the instructions in the manual and fail to build a wireless

network connection successfully, refer to the frequently asked questions

below for quick solutions to your problems. For more information and

advanced wireless network conﬁguration, please visit http://livesupport.

asus.com/eeewirelessxphowto.html.

Ensure that the wireless LAN function is enabled before conﬁguring

a wireless network connection. If not, press <Fn> + <F2> to activate

the wireless LAN function.

1. I am asked to enter the key for the wireless connection.

The network you would like to connect is encrypted, you need to

enter the correct key before using this network. Unless you have

your own wireless router, you will always need a correct key for the

encrypted wireless network.

2. Is my USB 3G wireless data card/wireless router compatible with

Disney Netpal Windows XP OS?

Contact the wireless card/router manufacturer if you have a

compatible issue.

3. I cannot build a wireless connection to my wireless router.

Try the following solutions.

• Restart your router and ensure that the router setup is correct.

• Cancel the encryption key (if there’s one) and try again.

• The distance from router inﬂuences the wireless signal strength.

Weak signal strength may fail the connection.
