Asus VG278H Series Manuale utente
VG278H Series
LCD Monitor
User Guide
August 2011
ii
Copyright © 2011 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Table of contents
Notices......................................................................................................... iii
Safety information ...................................................................................... iv
Care & Cleaning........................................................................................... v
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Monitor introduction .................................................................... 1-2
1.3.1 Front view ....................................................................... 1-2
1.3.2 Back view........................................................................ 1-4
1.3.3 Experiencing 3D Virtual Effects ...................................... 1-5
1.3.4 How to use your wireless 3D glasses ............................. 1-6
2.1 Assembling the monitor base..................................................... 2-1
2.2 Adjusting the monitor.................................................................. 2-2
2.3 Detaching the arm (for VESA wall mount)................................. 2-3
3.1 OSD (On-Screen Display) menu ................................................. 3-1
3.1.1 Howtocongure ............................................................. 3-1
3.1.2 OSD Function Introduction.............................................. 3-2
3.2 Specications............................................................................... 3-7
3.3 Troubleshooting (FAQ)................................................................ 3-9
3.4 Supported Timing List ............................................................... 3-10
iii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
As an Energy Star® Partner, our company has determined
that this product meets the Energy Star® guidelines for energy
efciency.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
iv
Safety information
• Before setting up the monitor, carefully read all the documentation that
came with the package.
• To prevent fire or shock hazard, never expose the monitor to rain or
moisture.
• Never try to open the monitor cabinet. The dangerous high voltages
inside the monitor may result in serious physical injury.
• If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.
• Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.
• Slots and openings on the back or top of the cabinet are provided for
ventilation. Do not block these slots. Never place this product near or
over a radiator or heat source unless proper ventilation is provided.
• The monitor should be operated only from the type of power source
indicated on the label. If you are not sure of the type of power supply to
your home, consult your dealer or local power company.
• Use the appropriate power plug which complies with your local power
standard.
• Do not overload power strips and extension cords. Overloading can
result in fire or electric shock.
• Avoid dust, humidity, and temperature extremes. Do not place the
monitor in any area where it may become wet. Place the monitor on a
stable surface.
• Unplug the unit during a lightning storm or if it will not be used for a
long period of time. This will protect the monitor from damage due to
power surges.
• Never push objects or spill liquid of any kind into the slots on the
monitor cabinet.
• To ensure satisfactory operation, in case use at a PC then it should
use the monitor only with computers which have appropriate
configured receptacles marked between 100-240V AC.
• If you encounter technical problems with the monitor, contact a
qualified service technician or your retailer.
• The wall socket shall be installed near the equipment and shall be
easily accessible.
v
Care & Cleaning
• Before you lift or reposition your monitor, it is better to disconnect the
cables and power cord. Follow the correct lifting techniques when
positioning the monitor. When lifting or carrying the monitor, grasp the
edges of the monitor. Do not lift the display by the stand or the cord.
• Cleaning. Turn your monitor off and unplug the power cord. Clean the
monitor surface with a lint-free, non-abrasive cloth. Stubborn stains
may be removed with a cloth dampened with mild cleaner.
• Avoid using a cleaner containing alcohol or acetone. Use a cleaner
intended for use with the LCD. Never spray cleaner directly on the
screen, as it may drip inside the monitor and cause an electric shock.
The following symptoms are normal with the monitor:
• The screen may flicker during the initial use due to the nature of the
fluorescent light. Turn off the Power Switch and turn it on again to
make sure that the flicker disappears.
• You may find slightly uneven brightness on the screen depending on
the desktop pattern you use.
• When the same image is displayed for hours, an afterimage of the
previous screen may remain after switching the image. The screen will
recover slowly or you can turn off the Power Switch for hours.
• When the screen becomes black or flashes, or cannot work anymore,
contact your dealer or service center to fix it. Do not repair the screen
by yourself!
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
IMPORTANT: Information that you MUST follow to complete a
task.
NOTE: Tips and additional information to aid in completing a task.
vi
Wheretondmoreinformation
Refer to the following sources for additional information and for product
and software updates.
1. ASUS websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Your product package may include optional documentation that may
have been added by your dealer. These documents are not part of
the standard package.
1-1
ASUS VG278H Series LCD Monitor
1.1 Welcome!
Thank you for purchasing the ASUS®LCD monitor!
The latest widescreen LCD monitor from ASUS provides a crisper,
broader, and brighter display, plus a host of features that enhance your
viewing experience.
With these features, you can enjoy the convenience and delightful visual
experience that the monitor brings you!
1.2 Package contents
Check your package for the following items:
LCD Monitor
Power Cord
VGA Cable
DVI (Dual-Link) Cable
3.5mm Audio Cable
NVIDIA®3D Vision™ Glasses
Support CD
Quick Start Guide
Warranty Card
If any of the above items is damaged or missing, contact your retailer immediately.
1-2 Chapter 1: Product Introduction
1.3 Monitor introduction
1.3.1 Front view
1 2 3 4 5 6 7
1. Button:
• Press this hotkey to switch from six video preset modes
(Scenery Mode, Standard Mode, Theater Mode, Game
Mode, Night View Mode, and sRGB ) with SPLENDID™ Video
Intelligence Technology.
• Exits the OSD menu or goes back to the previous menu when
the OSD menu is active.
The Splendid, Contrast and Brightness adjustment functions will be temporarily
disabled while 3D function is activated.
2. Button:
• Press this button to automatically adjust the image to its
optimized position, clock, and phase (for VGA mode only).
3. Button:
• Press this button to decrease the value of the function selected
or move to the next functions.
• Volume hotkey
1-3
ASUS VG278H Series LCD Monitor
4. Button:
• Press this button to enter/select the icon (function) highlighted
while the OSD menu is activated.
• Exits the hotkey OSD menu.
5. Button:
• Press this button to increase the value of the function selected
or move to the previous function.
• Brightness hotkey
6. Input Select Button:
• Press this button to select input source.
7. Power Button/Power Indicator:
• Press this button to turn the monitor on/off.
• The color definition of the power indicator is shown below.
Status Description
Blue ON
Amber Standby mode
OFF OFF
1-4 Chapter 1: Product Introduction
1.3.2 Back view
1 2 543 6 7
Rear connectors
1. Kensington lock slot.
2. AC-IN port: This port connects the power cord.
3. HDMI-IN port: This port is for connection with an HDMI compatible
device (support NVIDIA®3D Vision™ and Blu-ray 3D).
4. DVI port: This 24-pin port is for PC (Personal Computer) DVI-D digital
signal connection (support NVIDIA®3D Vision™).
The 3D feature is only supported through HDMI-IN and DVI port.
5. VGA port: This 15-pin port is for PC VGA connection.
6. PC Audio-In Jack: This 3.5mm stereo jack is for PC audio connection.
7. Earphone-Out Jack: This 3.5mm stereo jack is for earphone audio
connection.
Indice
Altri manuali Asus Monitor
Asus
Asus MG28UQ Manuale utente
Asus
Asus VH192 Series Manuale utente
Asus
Asus VZ2791R Series Manuale utente
Asus
Asus PB248 Series Manuale utente
Asus
Asus VP229HE Series Manuale utente
Asus
Asus VS228 Series Manuale utente
Asus
Asus VH162 Series Manuale utente
Asus
Asus VA34VCPSN Series Manuale utente
Asus
Asus VG278HE Series Manuale utente
Asus
Asus VS239H Manuale utente
Asus
Asus VN247HA Manuale utente
Asus
Asus SV425 Manuale utente
Asus
Asus VA247HE Series Manuale utente
Asus
Asus PA32UCX Series Manuale utente
Asus
Asus VK207S Manuale utente
Asus
Asus VG247 Series Manuale utente
Asus
Asus MM17DE Manuale utente
Asus
Asus VB198T Manuale utente
Asus
Asus VA279HAE Manuale utente
Asus
Asus VK278Q Series Manuale utente
