Asus DSL-N16 Manuale utente
DSL-N16
300Mbps Wi-Fi VDSL/ADSL Modem Router
Quick Start Guide / Kullanim Kılavuzu
¨
u10545 / First Edition / July 2015
English.............................................................5
Български......................................................9
Hrvatski...........................................................13
Čeština.............................................................17
Dansk............................................................... 21
Nederlands .................................................... 25
Eesti.................................................................. 29
Suomi...............................................................33
Français ...........................................................37
Deutsch........................................................... 41
Ελληνικά.......................................................... 45
Magyar ............................................................ 49
Italiano ............................................................ 53
Latviski ............................................................ 57
Lietuvių ..........................................................61
Norsk................................................................ 65
Polski................................................................ 69
Português ...................................................... 73
Română........................................................... 77
Русский........................................................... 81
Srpski .............................................................. 85
Slovensky ...................................................... 89
Slovenščina ................................................... 93
Español ........................................................... 97
Svenska .......................................................... 101
Türkçe ..............................................................105
Українська .................................................... 109
u10545_dsl-n16_qsg.indb 1 2015/8/5 17:58:58
u10545_dsl-n16_qsg.indb 2 2015/8/5 17:58:58
u10545_dsl-n16_qsg.indb 3 2015/8/5 17:58:58
u10545_dsl-n16_qsg.indb 4 2015/8/5 17:58:58
5
English
Package contents
VDSL/ADSL Wireless Modem Router AC adapter
Network cable (RJ-45 cable) Quick Start Guide
xDSL/phone cable (RJ-11) Warranty card
A quick look
NOTE: If any of the items is damaged or missing, contact your retailer.
1. Power LED 7. Power button
2. DSL LED 8. Reset button
3. Internet LED 9. WPS and W-Fi on/o button
4. LAN 1~4 LED 10. LAN 1 ~ 4 ports
5. Wi-Fi LED 11. RJ-11 port
6. Power (DC-IN) port
DSL-N16 300Mbps Wi-Fi VDSL/ADSL Modem Router
u10545_dsl-n16_qsg.indb 5 2015/8/5 17:58:58
6
English
Setting up
1. Insert your xDSL modem router’s power adapter to the
DC-IN port and plug it to a power outlet.
2. Connect one end of the RJ-11 cable to the DSL port of
your xDSL modem router, and connect the other end
to the DSL port of your splitter.
3. Using a network cable, connect your computer to your
xDSL modem router’s LAN port.
Powering up
1. Turn on your xDSL modem router and wait for a few minutes for Internet connection.
2. When DSL LED stops ashing and lights constantly, you can start the DSL setup process via the
QIS Wizard (Quick Internet Setup Wizard).
NOTE: For more details on QIS, refer to the user manual.
Getting started
1. Launch your web browser, and key in the default user name (admin) and password (admin).
DSL-N16
2
DSL
1
3
LAN
Line
Power
Phone
Laptop
Wall Power Outlet
Wall telephone outlet Splitter
u10545_dsl-n16_qsg.indb 6 2015/8/5 17:58:59
7
English
NOTE: If QIS does not launch automatically, follow these steps to manually launch QIS:
• Key in http://192.168.1.1 or http://router.asus.com and run the Quick Internet Setup (QIS)
Wizard again.
• Disable the proxy settings, dial-up connection, and set your TCP/IP settings to automatically
obtain an IP address. For more details, please refer to the ASUS Support site.
2. Your xDSL modem router automatically congures the DSL Annex mode, Internet connection
type, and VPI/VCI value and encapsulation modes. Key in the Internet account information that
you obtained from your Internet Service Provider (ISP).
IMPORTANT! Obtain the necessary information from your ISP to congure the Internet connection.
NOTES:
• The auto-detection of your ISP connection type takes place when you congure your xDSL
modem router for the rst time or when your device is reset to its default settings.
• By default, the QIS Wizard is for DSL setup. If you want to congure DSL-N16 as a wireless router,
refer to the section Internet Connection in the user manual.
u10545_dsl-n16_qsg.indb 7 2015/8/5 17:58:59
8
English
4. Assign the wireless network name (SSID) and security key for your wireless connection. Click
Apply when done.
5. A summary page appears to show the current settings for your network. Click Next to save your
network settings and go to the Network Map page.
IMPORTANT! Obtain the necessary information from your ISP to congure the Internet connection.
NOTES:
• The auto-detection of your ISP connection type takes place when you congure your xDSL
modem router for the rst time or when your device is reset to its default settings.
• By default, the QIS Wizard is for DSL setup. If you want to congure DSL-N16 as a wireless router,
refer to the section Internet Connection in the user manual.
3. If QIS failed to detect your Internet connection type, manually congure your connection set-
tings.
u10545_dsl-n16_qsg.indb 8 2015/8/5 17:58:59
9
български
Бърз преглед
Безжичен VDSL/ADSL модем-рутер Адаптер
Мрежов кабел (RJ-45 кабел) Ръководство за бърз старт
DSL/телефонен кабел (RJ-11 кабел) Гаранционна карта
Бърз преглед
ЗАБЕЛЕЖКА: Ако някой от компонентите е повреден или липсва, свържете се с
Вашия търговски представител.
1. Индикатор на захранването 7. Бутон за включване и изключване
2. DSL LED 8. Бутон за нулиране
3. Интернет индикатор 9. Бутон за включване и изключване
на WPS и Wi-Fi
4. LAN1~4 LED 10. LAN1~4 порта
5. Wi-Fi LED 11. RJ-11 порт
6. Порт захранване (DC-IN)
DSL-N16 300Mbps Wi-Fi VDSL/ADSL Modem Router
u10545_dsl-n16_qsg.indb 9 2015/8/5 17:58:59
10
български
Настройка
1. Включете захранващия адаптер на Вашия xDSL
модем-рутер във входа за прав ток, след което го
включете в контакт.
2. Свържете единия край на RJ-11 кабела към DSL
порта на Вашия xDSL модем-рутер, след което
свържете другия край към DSL порта на Вашия
сплитер.
3. С помощта на мрежов кабел, свържете компютъра
си с LAN порта на безжичния xDSL модем-рутер.
Включване
1. Включете своя xDSL модем-рутер и изчакайте няколко минути за интернет връзка.
2. Когато DSL LED спре да мига и започне да свети непрекъснато, можете да стартирате
процеса на инсталиране на DSL чрез QIS Wizard (Съветник за бързо конфигуриране на
интернет).
ЗАБЕЛЕЖКА: За повече информация относно QIS (Бързо конфигуриране на интернет) вижте
Ръководство на потребителя.
Първи стъпки
1. Стартирайте воя уеб брауър и въведете стандартното потребителско име (admin) и
паролата (admin).
DSL-N16
2
DSL
1
3
LAN
Line
Power
Phone
Laptop
Wall Power Outlet
Wall telephone outlet Splitter
u10545_dsl-n16_qsg.indb 10 2015/8/5 17:58:59
