LIBRA-04 M MANUAL COPY ROUTER
LIBRA-04 M
MANUAL COPY ROUTER
User's Manual
LIBRA-04 M MANUAL COPY ROUTER
TABLE OF CONTENTS
ITEM # SUBJECT PAGE #
I INTRODUCTION 3
II SAFETY APPLICATIONS 4
II.1
DESCRIPTION OF SYMBOLS USED IN THIS USER’S
MANUAL
4
II.2 SAFETY INSTRUCTIONS 5
III MACHINE DESCRIPTION 8
III.1 TECHNICAL DESCRIPTION 9
III.2 TECHNICAL DATA 9
IV INSTALLATION 10
IV.1 MACHINE LIFTIN AND MOVIN 10
IV.2 THE REQUIRED OPERATION ZONE 11
IV.3 INSTALLATION AND ASSEMBLY OF MACHINE 11
V RUNNING THE MACHINE 13
VI MAINTENANCE AND LUBRICATION 14
VII TABLE OF PROBABLE PROBLEMS AND THEIR
SOLUTIONS 15
VII.1 WHEN PROBLEM OCCURS, THE PROCESSES
THAT SHOULD BE DONE 15
VIII CIRCUIT DIAGRAMS 17
VIII.1 PNEUMATIC CIRCUIT 17
VIII.2 ELECTRIC CIRCUIT 18
LIBRA-04 M MANUAL COPY ROUTER
3 / 19
I. GENERAL INFORMATION
1.1. INTRODUCTION
The user’s manual given by the manufacturer contains necessary information about
the machine parts. Each machine operator should read these instructions carefully,
and the machine should be operated after fully understanding them.
Safe and efficient use of the machine for long term depends on understanding and
following the instructions contained in this manual. The technical drawings and details
contained in this manual constitute a guide for the operator.
1.2. DISTRIBUTOR
ATech Machine, Inc.
7609-F Airpark Road – aithersburg, MD 20879 USA
Phone: +1-301-556-9789 Toll Free: 1-866-80A-TECH Fax: +1-301-542-0140
Website: www.ATechMachine.com E-mail: info@ATechMachine.com
In case of any technical problem please contact your nearest ATECH dealer through
the above mentioned phone, fax or e-mail address.
Technical labels with the model description of the machine are fixed onto the front side
of each machine.
The machine’s serial number and manufacturing year are stipulated on the technical
label.
Before using the Libra-04 M Manual Copy Router read the user’s manual.
LIBRA-04 M MANUAL COPY ROUTER
4 / 19
II – SAFETY APPLICATION
Before operating this equipment, be sure of reading and understanding the safety
instructions.
The operator may not run the machine without reading this guide.
Reading and understanding this user guide is important for hindering to injury to the
operator, third persons, animals, environment and/or damage to the machine.
II.1 – DESCRIPTION OF SYMBOLS USED IN THIS
USER’S MANUAL
This symbol express the definitions to give some information about the machine.
This symbol express that machine does not be operated without reading the user
guide.
This express that security conditions that must be followed to prevent possible
damage to the machine.
In this technical manual all information which effect your safety are marked
with this warning symbol.
Cauti n!
The caution symbol is always used when there is danger of injury to
persons.
This is hazardous voltage symbol.
This is general warning symbol. This rules must be obeyed.
This shows that attitudes should not be done without being expert.
This symbol indicates that there is a pinch point.
This explains the processes that should be done before maintenance.
LIBRA-04 M MANUAL COPY ROUTER
5 / 19
This explains not be pulled up the protective parts
.
Do not operate without guards.
This is high temperature symbol.
II.2 – SAFETY INSTRUCTIONS
Before operating this equipment, read the safety instructions and carry out them.
This technical handbook should be accessible at all times at the site of
operation of the machine.
The operators who work during the installation, should read the machine guide.
Be sure of understanding.
User should not intervene to the machine if occurs any failure. Only expert should
repair the machine.
Machine and parts should be protected from the all external defects. Check for
proper oil level before operating machine. If it is insufficient, add up.
Do not stay under machine during loading and discharge.
Never use the machine without grounding. Machine grounding should be made
for two different coupling.
1-) Normal machine grounding.
2-) PLC grounding.
While machine is run or set up for angular cuts, be careful about pinching your
hand to clamping pistons.
When transmission parts of machine abrade, they should be replaced with new
ones.
LIBRA-04 M MANUAL COPY ROUTER
6 / 19
Use only original spare part.
Don’t lean against control panel and do not force.
Use e-Stop button when necessary for stopping the machine because very
frequent repetition of this process, may cause problems on the some electric
components.
Service personnel of our company is responsible from the first operation of
machine. Do not allowed to run the machine any other person.
In the event of the machine failure, if there is a problem about electric, electric
panel should be opened by experts and again eliminated the problem by them.
Do not operate the machine except intended purpose.
---- Don’t touch the cables which are in the machine.
Do not wear clothes that hamper manufacturing and endanger the human safety
while the operator run machine. Never operate the machine when you get alcohol
or drug.
While machine is running, don’t make repairs, adjustments and maintenance.
Never remove protective machine parts on the machines. Do not forget that such
protective machine parts are put in order to protect your security.
Never touch the heaters of machine.
Only one person should operate the machine.
Before the machine stops don’t open the safety covers.
LIBRA-04 M MANUAL COPY ROUTER
7 / 19
Disconnect electrical power hydraulic and air pressure before making repairs or
adjustments.
Do not run the machine in the watery and moist areas.
Machine should be adjusted and well-kept all the time. Never do not work with
broken machine.
LIBRA-04 M MANUAL COPY ROUTER
8 / 19
III –MACHINE DESCRIPTION
LIBRA-04 M Manual Copy Router is used for milling lock holes, hinge slots, and
handle mounting holes onto vinyl (PVC) and aluminum profiles.
LIBRA-04 M
Picture 3-1 General View
Milling roup
LIBRA-04 M MANUAL COPY ROUTER
10 / 19
IV – INSTALLATION
The Libra-04 M Manual Copy Router is factory tested to ensure that the electrical
system and all mechanical components work properly. All material and spare parts sent
from the factory have been thoroughly checked before consignment to the transportation
agency.
On receiving the equipment, check for any damage which may have occurred during
transportation.
IV.1 – MACHINE LIFTING AND MOVING
The equipment is delivered in its own special packing. Check the stability and
positioning of the load on the forks. Keep the load as low as possible when moving, for
greater stability and better visibility. Forks should be opened with maximum angle.
1. When carrying, make sure not to damage cables, cylinders, hose, regulator and
control panel.
2. Upon carrying, avoid to get a damage to the machine.
3. Carrying the machine must be done only with a proper size of forklift.
Before lifting, ensure that the lift truck fingers are clear of any wires that may be
damaged if pinched between the fingers and the machine.
Picture 4-1 Machine Lifting and M ving
