Package Contents
Basic Package
The basic VE803 package consists of:
1 VE803T HDMI USB Extender
1 VE803R HDMI USB Extender
1 Power Adapter
1 USB cable (1.8 m)
1 Mounting Kit
1 User Instructions*
Check to make sure that all the components are present and that nothing got
damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation
procedures carefully to prevent any damage to the unit, and/or any of the
devices connected to it.
*Features may have been added to the VE803 since this manual was
published. Please visit our website to download the most up-to-date version.
© Copyright 2013 ATEN® International Co., Ltd.
Manual Date: 2013-07-10
ATENandtheATENlogoareregisteredtrademarksofATENInternationalCo.,Ltd.Allrightsreserved.
All other brand names and trademarks are the registered property of their respective owners.
VE803 User Manual
v
Contents
FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
RoHS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
SJ/T 11364-2006. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Basic Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Product Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
1. Introduction
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Source Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Display Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
VE803T Right View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
VE803T Left View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
VE803R Right View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
VE803R Left View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2. Hardware Setup
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3. Basic Operation
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
EDID Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Equalization Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Appendix
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Technical Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
International. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
VE803 User Manual
vi
About this Manual
This User Manual is provided to help you get the most from your system. It
covers all aspects of installation, configuration and operation. An overview of
the information found in the manual is provided below.
Chapter 1, Introduction, introduces you to the VE803 system. Its purpose,
features and benefits are presented, and its front and back panel components
are described.
Chapter 2, Hardware Setup, describes how to set up your installation. All
necessary steps to prepare for operation are provided.
Chapter 3, Basic Operation, describes how to use the EDID switch and EQ
switch to adjust the picture quality.
An Appendix, provides specifications and other technical information
regarding the VE803.
VE803 User Manual
vii
Conventions
This manual uses the following conventions:
Product Information
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized
Reseller. Visit ATEN on the Web for a list of locations and telephone numbers:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear
together in the same bracket with a plus sign between them:
[Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦Bullet lists provide information, but do not involve sequential steps.
→Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start →Run means to
open the Start menu, and then select Run.
Indicates critical information.
International http://www.aten.com
North America http://www.aten-usa.com
1
Chapter 1
Introduction
Overview
The VE803 HDMI USB Extender extends HDMI signals up to 60 meters from
the HDMI source using two Cat 5e cables. It is capable of sending 1080i
signals up to 60 meters, and 1080p signals up to 40 meters.
The VE803 is equipped with USB connectors, which allow you to extend any
USB device between the units. The USB feature also provides support for
touch panel control, allowing you to control the local HDMI source device
from the remote display, or control the remote display through the local unit.
The VE803 is ideal for transportation centers, medical facilities, shopping
malls or anywhere touch panel control at a kiosk is required. For flexibility and
convenience, the VE803 local unit can be powered via the USB cable when
connected to an appropriate source device. The VE803 is HDCP compliant,
providing an easy and ideal HDMI extender solution for any application.
Chapter 1. Introduction
2
Features
Uses two Cat 5e cables to connect the local and the remote units
Extends 1080p by 40m; extends 1080i by 60m
Superior video quality – HDTV resolutions of 480p, 720p, 1080i, 1080p
(1920x1080), VGA, SVGA, XGA, SXGA, UXGA and WUXGA
(1920x1200)
Supports USB touch panels
8-segment Equalization adjustment switch optimizes display quality
Supports Dolby True HD and DTS HD Master Audio
Built-in 8KV / 15KV ESD protection
Transparent USB Support – supports all USB 2.0 full speed device (12
Mbps)
USB 2.0 compatible
Supports wide screen formats
HDMI (3D, Deep Color); HDCP compatible – signaling rates up to 2.25
Gbits
Transmitter unit powered via USB cable
VE803 User Manual
3
Requirements
Source Device
The following equipment must be installed on the source device or computer:
HDMI Type A output connector(s)
Display Device
A display device or receiver with an HDMI Type A input connector
Cables
Use HDMI cables to connect the HDMI source and display device to the
VE803T and VE803R
Use two Cat 5e cables to connect the VE803T to the VE803R
Use standard USB cables with Type A to Type B connectors to connect
USB devices
Note: Cables are not included in this package. We strongly recommend that
you purchase high-quality cables of appropriate length since this will affect the
quality of the audio and video display. Contact your dealer to purchase the
correct cable sets.
Maximum cable distances are as follows:
40 m at 1080p @ 24-bit color depth
60 m at 1080i @ 24-bit color depth
