ATN ThOR Series Manuale utente

operator’s manual

Important Export Restrictions! The products,

technologies and services contained in this manual are

subject to one or more export control laws and regulations

of the U.S. Government and they fall under the control

jurisdiction of the US Department of State. It is unlawful

and strictly prohibited to export, or attempt to export or

otherwise transfer or sell any hardware or technical data or

furnish any service to any foreign person, whether abroad or

in the United States, for which a license or written approval

of the U.S. Government is required, without first obtaining

the re quire d lic ense or writ ten ap proval from t he ap propriate

Department of the U.S. Government having jurisdiction in

such matters. Diversion contrary to U.S. law is prohibited.

ATN ThOR Series

THERMAL OPTICAL RIFLESCOPES

THOR SERIES OPERATOR’S MANUAL (REV. 3, DECEMBER 2010)

The information in this manual furnished for information use only, is subject to

change without notice, is not to be construed as a commitment by ATN Corp.

ATN Corp. assumes no responsibility or liability for any errors or inaccura-

cies that may appear in this book.

www.atncorp.com/warranty

SAFETY SUMMARY

STUDY CAREFULLY THIS MANUAL BEFORE

TURNING ON AND OPERATING THIS PRODUCT.

CAUTIONS

The ATN ThOR Series Thermal Optical Riﬂescopes are preci-

sion electro-optical instruments and requires careful han-

dling.

To provide safe use of the systems the following instructions

should be observed:

•Donotdismantlethedevice.

•Keepthedeviceclean;protectitfrommoisture,sharptem-

perature drops and shocks.

•Becarefulnottotouchtheglasssurfaces.Ifyouputfinger-

prints on, or contaminate the glass surfaces, use only clean

and soft materials to clean it.

•Donotleavethedeviceinonpositionduringstopsinopera-

tion.

•Removethebatteriesfromthedevicefortheperiodofstor-

age.

THIS PRODUCT CONTAINS NATURAL RUBBER LATEX

WHICH MAY CAUSE ALLERGIC REACTIONS

CAUTION:

WARNING

Do not permanently attach the scope to dynamic-mount appli-

cations that continuously transmit vibration (such as on vehi-

cles or heavy machinery).

WARNING

Do not point the scope directly at any high-intensity objects

that you must not view with your eyes (such as the sun or a

welding arc). If you do, you will damage the scope.

WARNING

Operating ThOR Series outside of its speciﬁed operating tem-

perature range or voltage range can cause permanent damage

and will void the warranty.

WARNING

Use the power button to turn the scope off before you remove

power (remove batteries or disconnect external power

supply).

WARNING

ThOR Series operates over a wide operating temperature

range (-20°C to +60°C). Not all lithium batteries are speciﬁed

over this same temperature span. Check the manufacturer’s

speciﬁcations of your selected battery to verify the valid tem-

perature range.

WARNING

Do not use any battery other than a CR-123A lithium battery.

DO NOT use any battery(ies) providing a (combined) voltage

greater than 12.0 volts.

WARNING

Do not install batteries of different types (lithium with lithium-

ion rechargeable). All batteries must be of the same type.

WARNING

Always replace ALL 4 batteries. If you install new batteries with

used batteries, the result may be dangerous.

WARNING

Do not replace batteries in a possibly explosive environment,

such as a gas station (or any place where you must turn off

your vehicle engine). If you do, sparks can cause an explo-

sion.

WARNING

Remove the batteries before you store the riﬂescopes for

extended periods (2 weeks or more).

WARNING

Do not carry batteries in pockets containing metal objects

such as coins, keys, etc. Metal objects can cause the batteries

to short circuit and become very hot. In the case of lithium bat-

teries, a short circuit could cause them to explode.

WARNING

Observe battery manufacturer’s guidelines for safe handling

and proper disposal of batteries.

EQUIPMENT LIMITATIONS

•TheThORSeriesdetectorspectralband(7to14mkm)pro-

vides a better penetration through smoke, smog, dust, water

vapor etc.

•Infraredradiationdoesnottravelthroughglassandtherefore

the scope does not sense objects if they are behind a glass

window.

TABLE OF CONTENTS

pg.

SECTION I. INTRODUCTION 1-1

1.1 General Information 1-2

1.1.1. Scope 1-2

1.1.2. Reports 1-2

1.1.3. Storage 1-2

1.1.4. WarrantyInformation 1-3

1.2. Description and Data 1-5

1.2.1. Description 1-5

1.2.2.ThORStandardComponents 1-7

1.2.3. ThOR Optional Components 1-8

1.2.4.Specifications 1-8

1.2.5. Mechanical Functions 1-11

1.2.6. Optical Functions 1-12

1.2.7. ElectricalFunctions 1-12

SECTION II. ASSEMBLY AND PREPARATION 2-1

2.1. Preparation 2-2

2.1.1. Preparation for Use 2-2

2.1.2. Examination for Operation 2-3

2.2. Assembly 2-4

2.2.1. Remove/installation of

QuickReleaseMount(QRM) 2-4

2.2.2. Video Output 2-5

2.2.3. External Power Source 2-6

2.2.4.DVCInstallation 2-6

SECTION III. OPERATION 3-1

3.1. General Information 3-2

3.1.1. General 3-2

3.1.2. Controls and Indication 3-2

3.2. Operating procedure 3-4

3.2.1. Turning On 3-5

3.2.2.Focusing 3-4

3.2.3. Polarity 3-5

3.2.4.Brightness 3-6

3.2.5. Zoom 3-6

3.2.6. Manual Image Refresh 3-6

3.2.7.ReticleColor/BrightnessAdjustment 3-7

3.2.8.WindageandElevation 3-7

3.2.9. Shut Down Operations 3-8

SECTION IV. MAINTENANCE INSTRUCTIONS 4-1

4.1. Preventive Maintenance Checks

and Services (PMCS) 4-2

4.1.1. PurposeofPMCS 4-2

4.1.2. FrequencyofPerformingPMCS 4-2

4.2. Troubleshooting 4-4

4.2.1.General 4-4

4.2.2.TroubleshootingProcedures 4-4

4.3. Maintenance Procedures 4-5

4.3.1. ScopeMaintenance 4-5

4.3.2.CleaningProcedures 4-5

4.3.3.PreparingforExtendedStorage 4-6

iii

1-1

SECTION I

INTRODUCTION

1-2

1.1 GENERAL INFORMATION

1.1.1. SCOPE

This manual contains instructions for use in operating and main-

taining the ATN ThOR Series Thermal Optical Riflescopes.

Throughout this manual, the ATN ThOR Series will be referred to

as the scope or ThOR.

1.1.2. REPORTS

Reports from the user on recommendations for improvements are

encouraged. Send reports to the address below.

American Technologies Network Corp.

1341SanMateoAvenue

SouthSanFrancisco,CA94080

(800) 910-2862

(650) 989-5100

(650)875-0129fax

info@atncorp.com

www.atncorp.com

1.1.3. STORAGE

Storage of ThOR should be done in the factory packing and after a

thoroughPMCSasoutlinedinSection4.1ofthismanual.Thiswill

ensure the scope remains in mission ready condition during stor-

age. Batteries should be stored separately from the scope.

The scope should not be placed on the floor, in any area exposed

to high temperatures or direct sunlight. Presence of acid and al-

kaline vapor, as well as of other aggressive admixtures in the air

is unacceptable.
