Atomic FFZ Manuale utente
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
1
Assembly Manual
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
2
M2x6 PM
Motor Mount
M2x6 PM
6x8x1.5 O-ring
2x5x2.5 Bearing
3x6x2 Bearing
M1.7x3 KM
M2x4 KM M1.7x3 KM
Step 2 – Chassis and Bulkheads
Step 1 - Drive Pulley Assembly
Steel Axel
Spur Gear
15T Drive Pulley
2.0*3.0 *0.1 washer
2.0*3.0 *0.1 washer
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
3
Rubber Collar
Apply Ball Diff Grease
3x6x2 Bearing
Diff Lock Nut
M2x4 PM
6x10x3 Bearing
Adjust the bearing hub position to
adjust belt tension. Middle position is a
good start.
40T Belt
Step 4 – Front Drive System
Apply Thrust
Bearing Grease
oil
Loosen
Tighten
A
f
t
er a
s
s
e
m
b
l
y
Diff tool
27T
Step 3 – Ball Differential
Polish the diff plate and thrust
bearing plate with #1500 sand
paper
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
4
Step 5 – Servo Mount M2x4 KM
M2x4 KM
M2x4 KM
M2x4 KM
M2x4 KM
M2x4 PM
Adjust the gear mesh, not too lose nor
too tight
Step 6–Motor and Pinion Gear
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
5
Step 7 – Battery Holder
Step 8 –Top Deck
M2x4 KM
M2x4 KM
M1.5x 4 PM
M1.5 x 4 PM
Instant glue
M2x4 PM
M2x4 PM
M2x4 PM
M2x4 PM
M2x4 PM
M2x4 PM **
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
6
Step 9 – Front Arms
Step 10 – Front Knuckles
2 x 12 pin
1.5 x 11 pin
1.2 x 4 PB (self-tapping screw)
1.2 x 3 PM
4.0mm Ball Head
Put 0.1 or 0.2 shims to adjust the
Play slop (M3 shims) 3 x 6 x 2
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
7
Step 11 – Steering Crank
Normal Thread
Reverse Thread
Step 12 – Steering System
3x6x2 Bearing
6.5 mm
2.5 Ball Caps
2.5 Ball Heads
2.5 Ball Heads
2.5 Ball Heads
M2 x 5 x 0.8 shims (4pcs)
M2 x 8 PM
M2 x 4 PM
3 x 5 x 0.2 shim
Video to show how to smooth ball links, please scan the QR code.
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
8
Step 13 – Servo Linkage
Step 14 – Rear Arms
2.5 Ball Heads
17mm
M2 x 4 KM
M2 x 4 KM
1.2 x 4 KA (Flat head self-taping)
1.5 x 13 pin
f
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
9
Step 15 – Rear Uprights
Step 16 – Rear Suspension
3.5 Ball Head
Camber link Collar
3 x 6 x 2 Bearing
Wheel Axle
Rear upright
2 x 8 pin
Pin cover
FFZ -FRONT WHEEL DRIVE CHASSIS ATOMIC
V1.1 (25 Dec 2018)
1
0
1
.
2
mm
T
r
im
18.8mm
Step 17 – Rear Camber Links
Step 18 – Rear Dampers
M2 x 6 set screw
3.5mm Ball Head
M1.2 x 4 PB
M2 x 4 PM
M2 x 4 KM
M2 x 4 PM
M2 x 6 PM
4mm Hollow Ball
Apply shock grease #25000
Default setup
