The information within this guide must be used in conjunction with the information in the Audi Owner’s Manuals. Refer to your vehicle’s Owner’s Manual for all information and warnings.

By using this guide, you acknowledge that you are aware of and have read the warnings and information provided in the Owner’s Manual on the topics in this guide and will use this

information to augment that material.

LEARN MORE AT

auditechnology.com

Audi Explore

Welcome

Your new A6 is equipped with many features designed to accentuate

your driving experience and create an environment that is reﬁned,

elegant and supremely functional. This guide will assist you in better

understanding some of the features of your A6 and provide you with

the knowledge needed to enjoy your new Audi to its fullest.

When you see this symbol, you can

discover more with your smart phone

by texting the letter keys to the code

provided. A video tutorial will be sent

to further explain the topic.

Standard messaging and data rates charged by your phone

service provider will apply.

The MMI® system consists of the MMI® display screen and the

MMI® control panel. This panel is composed of a control knob,

control buttons and function buttons.

Pressing one of the six “function buttons” such as

“RADIO” or “NAV” (Navigation) displays that feature’s

options in each corner of the MMI® screen. For instance,

after pressing the “RADIO” function button, the four

corners of the MMI® screen read “Presets”, “Band”,

“Functions” and “Settings”.

To select one of these options, use one of the four corresponding

buttons, known as the “control buttons,” surrounding the “control

knob.” While operating the function options, you can return to a

previous screen by pressing the “BACK” button.

You can access sub-menus and lists by turning the control knob, which

scrolls through the listings on the MMI® screen. To make a selection,

simply press the control knob.

The MMI® Touch can be used to write letters and numbers or

access Preset Radio stations. To enter a space, drag your ﬁnger

from left to right. While in Navigation mode, after pressing

the control knob, the touch pad can be used to move along the

map in the desired direction.

Do not text and drive. Message and data rates may apply.

TEXT A6NAV1 to 38981

MMI® Controls

Audio & Navigation

MMI® Controls

Media Function Button

7YY[iiWlW_bWXb[c[Z_W\hecYedd[Yj[ZiekhY[i

8BK;JEEJ>7kZ_e"I:YWhZ":L:"@ka[Xen"

and Audi Media Interface (AMI).

Volume/Track Advance Buttons

The knob to the upper right of the control knob is the volume dial.

Fh[ii_d]edY[m_bbckj[j^[WkZ_e$>ebZ_d]_jZemdm_bbjkhdj^[

system oﬀ. The arrow buttons allow you to move through the

audio tracks and radio stations.

MMI® Controls

cont.

Steering Wheel Controls

In addition to the MMI® control

panel you can use the multifunction

steering wheel controls to display

speciﬁc MMI® features in the

Driver Information System. Simply

press the “ARROW” buttons to

display the MMI® modes. Press the

“MENU” button to display

submenu options for that mode.

The thumbwheel can be used to

scroll through the options. Press it

to make a selection.

The “TALK” button is used to

activate Voice Recognition.

The volume thumbwheel is

used to adjust the volume,

pressing it will mute audio.

Pressing the “iNAV” button

will repeat the last Navigation

announcement when

navigation is active.

The is used to access

a programmable stored

function.

MMI® Controls

You can set any mix of up to 50 Presets from FM, AM or Sirius options.

Setting Station Presets

1. Press the “RADIO” function

button multiple times to

toggle between FM, AM

ehI?H?KI$

Do not text and drive. Message and data rates may apply.

TEXT A6NAV6 to 38981

*$Ehfh[iiWdZ^ebZj^[Y[dj[h

control knob until the

Presets screen shows

the Preset list.

2. Tune to the desired

station using the control

knob and pressing

to select.

3. Press and hold the desired

number on the touchpad

until you hear the tone that

the station has been stored.

MMI® Controls

cont.

To access your Presets:

Fh[iij^[“RADIO” function button

then the Presets control button.

Ki[j^[CC?YedjhebadeXjeiYhebb

through your Presets.

Fh[iij^[Y[dj[hXkjjede\j^[Yedjheb

knob to select a Preset.

EYYWi_edWbbo"jWbbXk_bZ_d]iWdZjkdd[bicWo_dj[hhkfjj^[iWj[bb_j[i_]dWb$<ehceh[_d\ehcWj_ed"fb[Wi[h[\[hjej^[I_h_kiNCXheY^kh[_doekh]bel[Xen$

5. Scroll to the numbered list position

where you want to save your selection.

6. Press the center control knob again;

the station is saved to this position.

MMI® Controls

BLUETOOTH® Pairing MMI®

Initial Setup

3. Select Audi MMI® when it

appears on the phone’s

screen.

BLUETOOTH® pairing is a one-time procedure. Once paired via BLUETOOTH®, your phone will

automatically connect when you start your vehicle and your phone’s contacts automatically

synchronize, allowing you to retrieve contacts, and make and receive calls through the infotainment

system. For more information regarding phone compatibility visit audiusa.com/bluetooth.

To pair a phone:

1. Switch ignition to accessories mode.

2. Activate your phones BLUETOOTH® function

and set to Pairing or Search mode.

Do not text and drive. Message and data rates may apply.

See your phone’s owner manual for speciﬁc pairing instructions. Vehicle should be stationary with the parking brake engaged while performing this operation.

TEXT A6NAV2 to 38981

4. The Audi MMI® system

will indicate a PIN number

is required and ask, Would

you like to connect? Use

the MMI® control knob to

select Yes.

5. Conﬁrm the six-digit PIN

displayed matches the PIN

displayed on your phone,

and select Yes using the

control knob.

Note: Once paired, the BLUETOOTH® symbol appears in the MMI® screen along with network strength bars and it will be displayed whenever a paired phone is connected to the infotainment system.

6. Select Pair on your phone

to complete the pairing

process.

-$9edjWYjiiodY^hed_p_d]$

8BK;JEEJ>WYj_l[WdZ

network strength bars.

BLUETOOTH®

Pairing

Call By Name

Do not text and drive. Message and data rates may apply.

TEXT A6NAV3 to 38981

Voice Recognition: MMI®

1. Press the “TALK” button.

A beep will sound.

2. Say, “Call” <Name from directory>

(e.g., “Call John Smith”).

3. To conﬁrm the request, say “Yes”.

The number will be dialed.

Note: If multiple numbers are stored for a given contact, the

system will ask which number you wish to dial. When calling by

name using voice recognition, you must say the name as it is

stored in your phone book.

BLUETOOTH®

Pairing

Voice Recognition: MMI®

cont.

Name Tags

You may attach your own speciﬁc verbal Name Tags to stored Contacts, such as nicknames or other words that are not in the directory listing.

You may use any short verbal command.

TEXT A6NAV3 to 38981

Do not text and drive. Message and data rates may apply.

3. Select contact’s name and press MMI®

control knob to open contact’s information.

2. From the telephone menu,

select Directory.

1. Press the “TEL” function button.

4. Press the “TALK” button. After the beep, say “Store Name”.

5. When prompted, say <name>. When prompted,

repeat <name>.

6. The system will conﬁrm, “The name <name> has been stored.”

7. To call this contact, refer to call by name using voice

recognition instructions.

Important Warnings and Safety Information, which you must read are listed on the last panel under

Voice Recognition.

BLUETOOTH®

Pairing

Audi connect® can provide you with Google Earth™, Google Voice™

Local Search, Wi-Fi Hotspot, Online Services (fuel prices, weather

information, travel information, news feeds) and myAudi

Destinations.

TEXT A6ACT1to 38981

Do not text and drive. Message and data rates may apply.

Audi connect®

Conﬁguration:

Audi connect®

Initial Setup

Note: Vehicle should be stationary with the parking brake set before

performing these operations.

1. Ensure SIM card (provided by dealer) is

present in the SIM slot.

2. Press the “TEL” function button.

3. Press the “Settings” control button.

Audi connect®

4. Scroll to Connections and press

the control knob once to select. Wi-Fi Conﬁguration

5. Select Data connection. 6. Then, select Set up

connection, scroll to

without request and select.

7. Press the “BACK” function

button and select Network

connection (Wi-Fi).

8. Ensure that Wi-Fi active is

On as notated by a check

mark.

Audi connect®

cont.

9. Scroll to Wi-Fi settings

and select.

10. Select Password and

enter a password at least

eight characters long and

select OK.

*Most devices use Encryption type

WPA2 as the default.

11. Select Apply settings to

save your password.

12. On your device, search for

Wi-Fi Networks select

the SSID and enter your

password to establish

a connection.

Note: You may connect up to eight wireless

devices at one time.

Always pay careful attention to the road, and do not drive while distracted. The features and technologies discussed are optional, may

require an additional subscription with separate terms and conditions, and should be used only when it is safe and appropriate.

The Wi-Fi hotspot feature is intended for passenger use only.

Audi connect® services are only available where there is mobile network coverage. You can obtain more information from your current service provider.

Audi connect®
