The information within this guide must be used in conjunction with the information in the Audi Owner’s Manuals. Refer to your vehicle’s Owner’s Manual for all information and warnings.

By using this guide, you acknowledge that you are aware of and have read the warnings and information provided in the Owner’s Manual on the topics in this guide and will use this

information to augment that material.

LEARN MORE AT

auditechnology.com

Audi Explore

Welcome

Your new A5 is equipped with many features designed to accentuate

your driving experience and create an environment that is reﬁned,

elegant and supremely functional. This guide will assist you in better

understanding some of the features of your A5 and provide you with

the knowledge needed to enjoy your new Audi to its fullest.

When you see this symbol, you can

discover more with your smart phone

by texting the letter keys to the code

provided. A video tutorial will be sent

to further explain the topic.

Standard messaging and data rates charged by your phone

service provider will apply.

MMI® Controls

Audio & Navigation

The MMI® system consists of the MMI® display screen

and the MMI® control panel. This panel is composed of a

control knob with joystick, control buttons and function

buttons.

Pressing one of the six “function buttons” such as

“RADIO” or “NAV” (Navigation) displays that feature’s

options in each corner of the MMI® screen. For instance,

after pressing the “RADIO” function button, the four

corners of the MMI® screen read “Presets”, “Band”,

“Functions” and “Settings”.

To select one of these options, use one of the four corresponding

buttons, known as the “control buttons,” surrounding the “control

knob.” While operating the function options, you can return to a

previous screen by pressing the “BACK” button.

You can access sub-menus and lists by turning the control knob,

which scrolls through the listings on the MMI® screen. To make a

selection, simply press the center button of the control knob.

To move to a speciﬁc location within the Navigation Map or to control

the main menu of a DVD, a joystick located directly on top of the

control knob provides additional convenience.

Do not text and drive. Message and data rates may apply.

TEXT A5NAV1 to 38981

MMI® Controls

Media Function Button

7YY[iiWlW_bWXb[c[Z_W\hecYedd[Yj[ZiekhY[i

8BK;JEEJ>7kZ_e"I:YWhZ":L:"@ka[Xen"

and Audi Media Interface (AMI)*.

J^[_FeZ7C?YWXb[Yec[iijWdZWhZm_j^

MMI® Navigation plus.

Volume/Track Advance Button

The knob to the upper right of the control knob is the volume dial.

Tipping the knob right or left allows you to move through audio

tracks and radio stations. Pressing once will mute the audio.

>ebZ_d]_jZemdm_bbjkhdj^[ioij[ceú$

*iPod AMI cable is standard on Audi Vehicles with concert radio and convenience package.

MMI® Controls

cont.

Steering Wheel Controls

In addition to the MMI® control panel, you can use the

multifunction steering wheel controls to display speciﬁc

MMI® features in the Driver Information System. Simply

press the “MODE” button until you reach your desired

function, including Radio functions.

The thumbwheel can be used to scroll through the options.

Press it to make a selection. Steering wheel controls allow

you to select Phone functions.

MMI® Controls

You can set any mix of up to 50 Presets from FM, AM or Sirius options.

Setting Station Presets

Do not text and drive. Message and data rates may apply.

TEXT A5NAV2 to 38981

1. Press the “RADIO” function button

multiple times to toggle between FM,

7CehI?H?KI$

2. Tune to the desired station using the

control knob and pressing to select.

3. Press and hold the center control knob

until the Presets screen shows the

Preset list.

MMI® Controls

cont.

MMI® Controls

To access your Presets:

Fh[iij^[“RADIO” function button

then the Presets control button.

Ki[j^[CC?YedjhebadeXjeiYhebb

through your Presets.

Fh[iij^[Y[dj[hXkjjede\j^[Yedjheb

knob to select a Preset.

EYYWi_edWbbo"jWbbXk_bZ_d]iWdZjkdd[bicWo_dj[hhkfjj^[iWj[bb_j[i_]dWb$<ehceh[_d\ehcWj_ed"fb[Wi[h[\[hjej^[I_h_kiNCXheY^kh[_doekh]bel[Xen$

4. Scroll to the numbered list position

where you want to save your selection.

5. Press the center control knob again;

the station is saved to this position.

BLUETOOTH® Pairing MMI®

Initial Setup

3. Select Audi MMI® when it

appears on the phone’s

screen.

To pair a phone:

1. Switch ignition to accessories mode.

2. Activate your phone’s BLUETOOTH® function

and set to Pairing or Search mode.

Do not text and drive. Message and data rates may apply.

See your phone’s owner manual for speciﬁc pairing instructions. Vehicle should be stationary with the parking brake engaged while performing this operation.

TEXT A5NAV1 to 38981

BLUETOOTH® pairing is a one-time procedure. Once paired via BLUETOOTH®, your phone will

automatically connect when you start your vehicle and your phone’s contacts automatically

synchronize, allowing you to retrieve contacts and make and receive calls through the infotainment

system. For more information regarding phone compatibility visit audiusa.com/bluetooth.

4. The Audi MMI® system

will indicate a PIN number

is required and ask, Would

you like to connect? Use

the MMI® control knob to

select Yes.

5. Conﬁrm the six-digit PIN

displayed matches the PIN

displayed on your phone,

and select Yes using the

control knob.

Note: Once paired, the BLUETOOTH® symbol appears in the MMI® screen along with network strength bars, and it will be displayed whenever a paired phone is connected to the infotainment system.

6. Select Pair on your phone

to complete the pairing

process.

-$9edjWYjiiodY^hed_p_d]$

8BK;JEEJ>WYj_l[WdZ

network strength bars.

BLUETOOTH®

Pairing

TEXT A5NAV6 to 38981

Voice Recognition: MMI®

Do not text and drive. Message and data rates may apply.

Call By Name

1. Press the “TALK” button.

A beep will sound.

2. Say, “Call” <Name from directory>

(e.g., “Call John Smith”).

3. To conﬁrm the request, say “Yes”.

The number will be dialed.

Note: If multiple numbers are stored for a given contact, the

system will ask which number you wish to dial. When calling by

name using voice recognition, you must say the name as it is

stored in your phone book.

BLUETOOTH®

Pairing

Voice Recognition: MMI®

cont.

Name Tags

You may attach your own speciﬁc verbal Name Tags to stored Contacts, such as nicknames or other words that are not in the directory listing.

You may use any short verbal command.

TEXT A5NAV6 to 38981

Do not text and drive. Message and data rates may apply.

3. Select contact’s name and press MMI®

control knob to open contact’s information.

2. From the telephone menu,

select Directory.

1. Press the “TEL” function button.

4. Press the “TALK” button. After the beep, say “Store Name”.

5. When prompted, say <name>. When prompted,

repeat <name>.

6. The system will conﬁrm, “The name <name> has been stored.”

7. To call this contact, refer to call by name using voice

recognition instructions.

Important Warnings and Safety Information, which you must read, are listed on the last panel under Navigation - Voice Recognition.

BLUETOOTH®

Pairing

Initial Setup

BLUETOOTH® pairing is a one-time procedure. Once paired via

BLUETOOTH®, your phone will automatically connect when you start your

vehicle and your phone’s contacts automatically synchronize, allowing

you to retrieve contacts, and make and receive calls through the

infotainment system.

BLUETOOTH® Pairing:

Audi concert radio

To pair a phone:

1. Switch ignition to accessories mode and turn on the Audi concert radio.

2. Activate your phone’s BLUETOOTH® function and set to Pairing or Search mode. BLUETOOTH® functions are accessed through the

phone’s settings.

Do not text and drive. Message and data rates may apply.

TEXT A5BT1 to 38981

For more information regarding phone compatibility visit audiusa.com/bluetooth.

3. Select Audi UHV when it

appears on the phone’s

screen.

4. Enter default PIN 1-2-3-4

and press Pair.

5. The phone is now paired

and your contacts will be

synchronized.

Note: Pairing methods may diﬀer. See your phone’s owner manual for speciﬁc pairing instructions.

BLUETOOTH®

Pairing

Name Tag Creation

A name tag is required to operate the voice recognition system.

Voice Recognition:

concert radio

1. Press the “TALK” button.

2. After the beep, say “Store Name”.

TEXT A5BT1 to 38981

Do not text and drive. Message and data rates may apply.

To create a name tag:

4. The system will ask for the

phone number. Speak the

<numbers>, (e.g., 8-0-0,

5-5-5-, 1-2-3-4.)

5. If incorrect, say “Back” to

remove the last set of

numbers.

6. If correct, say “Store

Number”, and the system

will conﬁrm that <name>

is saved.

Note: To conﬁrm or play back the saved voice tags, press the “TALK” button. After the beep, say “Play Phone Book”.

3. When prompted say the

<name>. A second

prompt will ask you to

repeat the <name>.

Call by name

2. Say “Select Name”. 3. When prompted,

say the <name>.

4. After name conﬁrmation,

say “Dial”, and the number

will be dialed.

1. Press the “TALK” button.

Important Warnings and Safety Information, which you must read, are listed on the last panel under BLUETOOTH® Pairing.

BLUETOOTH®

Pairing
