Audi TT COUPE Manuale utente

Audi TT Coupé

Quick reference guide

Fuel

(see sticker)

Tyre pressures

(see sticker on door pillar

on driver side)

Fuel tank flap

To open:

Press the switch on

the driver’s door.

To close:

Press the tank flap until you

hear it click into place.

Engine oil

The correct oil

specifications and

engine oil capacity are

listed in the

Performance, weights

and dimensions

section of the

Owner’s Manual.

Warning triangle

The compartment for the

warning triangle is located in

the luggage compartment.

Welcome

Dear Audi Driver,

This quick reference guide gives you an

overview of the main features and

controls of your vehicle. However, it

cannot replace the detailed Owner’s

Manual which contains important

information and safety warnings.

Please refer to your Owner's Manual for

detailed information on your vehicle.

You will find everything you need to

know about the radio, CD, navigation,

TV and telephone functions in the

Operating Manual for your sound system

or navigation system.

We wish you safe and enjoyable

motoring with your new Audi.

AUDI AG

Controls and

displays

Unlock switches for:

Tailgate

Tank flap

Electric windows

To set the desired position:

Press/pull to the first stop

and hold.

"One-touch" function:

Press/pull briefly to the

second stop.

Adjuster for exterior

mirrors

Turn the adjuster for:

Left exterior mirror

Exterior mirror heating

Right exterior mirror

10 12

9 9

Exterior mirror

retraction

Press the adjuster to move

the mirror glass in the desi-

red direction

Bonnet lock release

Door handle and central

locking switch

Lock

Unlock

Light switch

Headlight range control

and daytime running lights

Cruise control system

Controls on multi-function

steering wheel

Overview

Ashtray

Buttons for:

Audi magnetic ride

Electronic stabilisation

program

Hazard warning lights

Rear spoiler

Activating tyre

pressure monitoring

Handbrake

ESP

OFF

19 18

Turn signal and main beam

lever

Instruments and

warning/indicator lamps

Windscreen wipers/washer

and buttons for on-board

computer

Ignition lock

Steering wheel position

adjuster

10 Navigation system or

sound system

Warning lamp for front

passenger's airbag

Air conditioner

Front passenger’s

seat heating

Driver’s seat heating

Gear lever or selector lever

for automatic gearbox

123

Manual seat adjustment

To move seat backwards

or forwards:

Lift the lever and move the seat.

Then release the lever and move the

seat further until the catch engages.

To adjust lumbar support:

Press the appropriate part of

the switch.

To adjust seat height:

Pull up or press down the

lever repeatedly.

To adjust backrest:

Take your weight off the backrest

and turn the knob.

Easy entry function:

Pull the lever upwards and fold the

backrest forwards.

Adjusting head restraints

Take hold of the sides of the head

restraint with both hands and move

it up as required. The top of the

head restraint should be at eye level

or higher.

Seat adjustment

Electric seat adjustment

To adjust lumbar support:

Press the appropriate part of the switch.

To adjust seat height and move seat

backwards or forwards:

Front of seat cushion up/down

Rear of seat cushion up/down

Seat up/down

Seat forwards/backwards

To adjust backrest:

Backrest further

upright/further

reclined

Sitting position

Sit in a normal upright position and

do not sit too close to the steering

wheel. If necessary, also adjust the

position of the steering wheel.

min.

25 cm

Automatic gearbox

Selector lever positions

PParking lock

RReverse gear

NNeutral

DDrive (forwards)

SSport position

To release the selector lever and engage a gear:

Switch on the ignition, press the brake pedal, and

press the interlock button on the selector lever.

Move the selector lever to Dor Sto start

driving forwards.

tiptronic: To switch to manual gear

selection mode, push the selector

lever from position Dto the right.

The gears are shown on the driver

information system.

To shift up or down a gear: Briefly push

the selector lever forwards or backwards.

First steps

Starting the engine

Switching on the ignition/starting the engine

Insert the key into the ignition lock.

To switch on the ignition: Turn the key

to position .

To start the engine (on vehicles with

manual gearbox): Press the clutch and turn

the key to position until the engine

starts.

To start the engine (on vehicles with

automatic gearbox): Move the selector lever

to position Por N, press the brake pedal,

and turn the key to position until the

engine starts.

To switch off the engine: Turn the key to position .

Switches for air conditioner

Control on left: Temperature selection

Control in middle: Switching air conditioner on/off

and regulating blower speed

Control on right: Air distribution

Automatic mode

Set the desired temperature and

press the button.

Air recirculation

Circulates and filters the air in the interior

of the vehicle

Switching air cooling system on/off

Defrosting windscreen and side windows

Rear window heating

AUTO

Air conditioner

Audi magnetic ride

Two suspension systems in one vehicle

Normal driving mode: Comfort-oriented suspension

Sport driving mode: Performance-oriented suspension

Press the switch to activate/deactivate.

Technology

When the system is switched on, the indicator

lamp appears in the instrument cluster.

To switch on/off: Pull/press lever .

To set speed: Press button .

To adjust stored speed: Press lever up (faster)

or down (slower).

Cruise control system

Rear spoiler

To increase stability

The down force of the rear axle

increases when the rear

spoiler is extended.

Automatic mode:

The rear spoiler extends at

speeds above 120 km/h and

retracts at speeds below

80 km/h.

Manual mode:

Briefly press the button to extend the rear spoiler.

Briefly press the button again (while driving between

20 km/h and 120 km/h) to retract the rear spoiler again.

Press and hold the button (while driving below

20 km/h) to retract the rear spoiler.

Audi Navigation System plus

Components

Driver information system

Multi-function steering wheel

Scroll the left thumbwheel to select a menu item in the

driver information system. Press the thumbwheel to

confirm the selection.

Press the MODE button to switch between the active audio

source and the navigation and telephone functions.

Briefly press the button to switch on the speech

dialogue system.

Speak after the <beep>, e.g. say <Help> to call up the pos-

sible operating commands.

Press and hold the talk button to switch off the speech

dialogue system.

Scroll the right thumbwheel to adjust the volume.

If you press the right thumbwheel, the last navigation

cue will be repeated.
