Audio Pro Image Series B1.36 Manuale utente

Service manual

B1.36 manual 07.2004

B1.36

Headquarters:

Audio Pro AB. Box 1015. S-251 10 HELSINGBORG

SWEDEN

R&D , Service and spareparts:

Audio Pro AB. Box 1308. S-581 13 LINKÖPING

SWEDEN

Powered Subwoofer

featuring

Technical data B1.36

Enclosure: 200W powered, bass reflex.

Drive units, Woofer: 10” heavy duty woofer

Crossover -Hi Pass: 100Hz 6dB / octave

-Lo Pass: 50 - 100Hz / 24dB / octave

Freq.range: 25-100Hz

Power requirements: AC 230V 50HZ

Power consumption (max): 200W

Dimensions(WxHxD mm): 350 x 380 + 70 x 350 + 35

Weight net: 20,0 kg

Important note when repairing power amp pcb on B.5 or B.5 amp’s.

Before you perform soldering / unsoldering or DC resistance measuring on power

amp pcb, connector CN03B must be disconnected. Otherwise unwanted discharge

might cause damage on semiconductors.

FREQUENCY

LOW PASS

Serial no:

SPEAKER

LEVEL

T1AL 250V FOR 230V

FUSE TYPE:

POWER ON OFF

OUT

MAF OFF

LEVEL

AUTO

50HZ

MIN

100HZ

MAX

TYPE AND RATING OF FUSE.

REPLACE WITH ONLY THE SAME

TO REDUCE THE RISK OF FIRE,

CAUTION:

ATTENTION:

UTILISER UN FUSIBLE DE

RECHANGE DE MEME TYPE.

LINE IN

WARNING:SHOCK HAZARD-DO NOT OPEN.

AVIS:RISQUE DE CHOC ELECTRIQUE-NE

PAS OUVRIR.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

DOUBLE INSULATION - when servicing

use only identical replacement parts.

AC 230V 50Hz 200W

B1.36

4 4

3 3

2 2

1 1

PCB-1708

PCB-D10006(K19-0144)

HI LEVEL

O/P

HI LEVEL

I/P

<Doc> DG-A

B1.36

1 1Wednesday, June 02, 2004

Title

Size Document Number Rev

Date: Sheet of

+15V

-15V

S+15V

-15V

S+15V

+15V

S+15V

+15V S-15V

-15V

S+15V

S-15V

+15V

S-15V

+15V

-15V

C117

10U/50V

C118

10U/50V

TO CN05A

CN05A

R129

5K6 R131

220

IC105A

TL072

D101

1N4148

R133

3M9

R135

10K

C116

100U/50V

C102

0.001(M)

R132

22K

R136

100K

R137

12K

R141

100K

Q102

655E

C122

100U/25V

Q103

C1815

ZD101

3V3

R140

47K

IC102A

TL072

8 4

TEST

TIME

IC102B

TL072

8 4

R119

82K 1%

IC105B

TL072

8 4

C108

0.1(M)

Q101

2SK363

C144

0.1(M)

R112

1K 1/2w

C115 47P

C143

0.1(M)

R106

15K 1%

R130

3M9

IC101A

TL072

8 4

R116

39K 1%

R111

1K 1/2w

R109

430K 1%

C138

0.47(M)

R113

18K 1%

IC101B

TL072

8 4

C105 47P

C103

0.033(M)

100UF/100V

C104 0.033(M)

C107

0.1(M)

R144

22/2W

R105

15K 1%

R118

39K 1%

R114 18K 1%

R115

4K7 1%

VR101 50KA

R110

430K 1%

100UF/100V

R108

430K 1%

R101

220

R103

18K 1%

C101

0.001(M)

R126

100K 1%

IC104B

TL072

8 4

R125

11K 1%

R128

2k7 1%

C114

10U/50V

R143

100

CN02A

RI/P

RCA JACK

VR102C

20KB

R123

18K

C112

0.22(M)

IC104A

TL072

8 4

C136

0.033M)

R124

18K

VR102C

20KB

CN06A

C119 10/50

C120 10/50

MAF SW

IC103A

TL072

8 4

R122

18K

R121

18K

C111

0.082(M)

C110

0.1(M)

VR102A

20KB

VR102B

20KB

R127

150K 1%

R107

430K 1%

CN06A

R102

220

R104

18K 1%

LI/P

RCA JACK

CN01A

R134

5K6

D102B

1N4148

AUTO ON

SW102

R142

2k 1%

C123

4.7U/50V

R145

22k
