Model AS-RC3260 TV Cart
Rolling Cart for Audio Mount™ System
2
Introduction
Congratulaons on the purchase of your new Audio Soluons™ AS-RC3260 Rolling Cart. For maximum
benet, please read the enre manual before beginning installaon.
NOTE: This rolling cart has been designed to work with the Audio Soluons™ 2.1 or 3.1 Audio Mount™.
This cart will also work directly with most 32 to 60 inch Plasma, LCD and LED televisions with a maximum
weight of 132lbs (60kg).
Safety Instructions
Please read this enre manual carefully before assembling this unit and mounng the television to avoid
bodily injury and/or any property loss. If you do not understand these direcons, or have any doubts about
the safety of the installaon, please call a qualied contractor or contact the Audio Soluons™ customer
service department @ 1-866-839-9187. Please check carefully to ensure there are no missing or defecve
parts. Our customer representaves can quickly assist you with installaon quesons and missing or
defecve parts. Replacement parts for products purchased through authorized dealers will be shipped to
you directly. Do not aempt to use any parts not provided by the manufacturer. Using other screws could
cause injury or property loss. Never use defecve parts, as improper installaon may cause damage or
serious injury. Do not use this product for any purpose not explicitly specied by Audio Soluons™. Audio
Soluons™ cannot be liable for damage or injury caused by incorrect mounng, incorrect assembly, or
incorrect use.
• Read these instrucons.
• Keep these instrucons.
• Heed all warnings.
• Follow all instrucons.
• WARNING: Use only the supplied screws intended for the current applicaon to avoid personal injury
or property damage.
Opening the Package
The AS-RC3260 Rolling Cart and accompanying hardware have been carefully packed in a carton designed
to protect it from transportaon damage. Aer opening the carton, check that the components are in good
condion and that all listed contents are included.
GETTING STARTED
3
Package Contents
Base Post Metal Tray
Vertical Mounting
Bracket (x2)
Metal Shelf Clip (x2) Cable Clip (x3)
◦Mounng/Assembly Hardware
◦This User Manual
Mounting Instructions
Please read all enclosed instrucons and verify hardware contents carefully before mounng.
GETTING STARTED
4
Cart Assembly Hardware
#PartImage Descripon Qty
1 M6 x 16 Bolt 8
2 M8 x 16 Bolt 4
3M8 Washer 4
4M8 Nut 4
5Wheel 2
6 Locking Wheel 2
7 M12 Nut 4
8 M12 Spring
Washer
4
9M12 Washer 4
10 Leveling Foot 4
11 Allen Wrench 1
12 Wrench 1
GETTING STARTED
TV Bracket Assembly Hardware
#PartImage Descripon Qty
A M4 x 12 Bolt 4
BM5 x 12 Bolt 4
CM6 x 12 Bolt 4
DM8 x 16 Bolt 4
EM4 x 30 Bolt 4
FM5 x 30 Bolt 4
GM6 x 35 Bolt 4
HM8 x 40 Bolt 4
IM4/M5
Spacer
4
JM8/M6
Spacer
4
KM4/M5
Washer
4
LM6/M8
Washer
4
MM4 Washer 4
NM5 Washer 4
OM6 Washer 4
PM8 Washer 4
5
STEP 1
Read and understand all of the enclosed instrucons and verify that all parts are present and appear in
good working order before you begin.
STEP 2
Decide if you’d rather use the Leveling Feet or Wheels on the cart Base. Choose opon A or B to connue.
Using one M12 Nut, one M12 Spring Washer and one M12 Washer per wheel, screw the four wheels into
the legs, as shown in Figure 1.
Figure 1 - Attach Wheels to Base
(B) Screw the four Leveling Feet into the legs, as shown in Figure 2.
Figure 2 - Attach Leveling Feet to Base
INSTALLATION
6
INSTALLATION
STEP 3
Aach the Post to the Base using the M6 bolts, as illustrated in Figure 3.
Figure 3 - Attach Pole to Base
7
STEP 4
Loosen the screws where the mounng bracket aaches to the post poles. Hold the mounng bracket to
keep it from falling too quickly while adjusng the height to the ideal posion. Tighten the screws to secure
the mounng bracket at the desired height. See Figure 4.
Figure 4 - Adjust Height
INSTALLATION
8
STEP 5
Aach the Metal Tray to the post using the Metal Shelf Clips and M8 bolts, washers and nuts. See Figure 5.
Figure 5 - Install Metal Tray
INSTALLATION
9
STEP 6
In the hardware bag provided, locate the 4 pan head bolts that t the thread paern for your television or
Audio Mount™. With the two Vercal Brackets centered on the back of the TV or Audio Mount™, gently
thread the screws into the holes by hand. DO NOT USE AN ELECTRIC OR BATTERY DRILL unl you are
certain you have the right size thread. DO NOT OVER TIGHTEN the screws (Figure 6). When installing an
Audio Soluons™ Audio Mount™ 2.1 or 3.1, mount the television to the Audio Mount™ as instructed in the
Audio Mount™ Owner’s Manual and then mount the brackets to the back of the mount, as illustrated in
Figure 6.
Figure 6 - Attach Brackets to TV or Audio Mount™
NOTE: If aaching directly to a TV, make sure to use the proper bolts and washers that correspond to the
mounng holes on the back of the TV. Tighten by hand rst or damage to the mounng holes can occur.
Some TVs without a at back may require the use of a spacer when aaching the brackets. If applicable,
make sure the two TV brackets are even and that they’re using the same mounng holes on the bracket.
Uneven assembly will cause the TV screen to slant.
INSTALLATION
10
NOTE: You will need at least 2 people to nish this mounng procedure. To avoid possible injury, do not
aempt to mount the TV alone.
NO!YES!
Figure 7 - Two Person Install WARNING!
STEP 7
Hang the pre-assembled TV unit on the Mounng Plate. Tighten the safety screws at the boom of each
Bracket to secure (Figure 8).
Figure 8 - Attach TV Assembly to Mounting Plate
INSTALLATION
